  • Demystification Guide 1985-2001 #492-4509.pdf By nylyon-(Admin)

    • 5,267
    This is a GREAT Wheel Horse Electrical helper. 523 pages   260-Series electrical manual 492-4404 replaced by 492-4509 according to Toro and listed in the 5xi service manual   There are mistakes in this manual. Will list what they are as I come across them.   Diagrams that have been revised to correct mistakes. Do not use this complete manual for these models. Go to the files for the individual tractor model and look for "Wiring Detailed Revised"
  • Transmission Gear Uni-Drive 1958-1982 SM HR #A-1392.pdf By admin-(Admin)

    • 1,811
    Service manual High resolution Form No. A-1392 P/N 492-4004   Section I Models 5003-5010  16 pages 14.3MB   Section II Models 5053-5058 3-Speed 18 pages 18.3MB   Section III Model 5060 6-Speed 16 pages 12MB   Section IV 4-Speed 14 pages 8.3MB   Section V 8-Speed 16 pages 9.5MB   1" axles used in Uni-Drive transmissions 3-Speed transmission models - 5003 (1958-1959), 5
  • Tractor 1993 520-He OM English.pdf By gwest_ca-(File Mod)

    • 400
    English operator manual #3315-395EN or #3315-395 EN 28 pages 3.63MB Export model   Also available in Dutch, French and German   Note - Spark plug RH14YC is a typo and should be RS14YC   1993 520-H model 73520 Serial 3900001-3999999 (Serial number at Toro incorrectly requires 8 digits) - Export model 1993 520-He model 73520 Serial 3900001-3999999 (Serial number at Toro incorrectly requires 8 digits) - Export model
