86 files

  1. Free

    Engine Kohler Coil Magneto breakerless ignition 1.0.0

    Kohler magneto breakerless ignition coil 236826-S

    23 downloads

    Updated

  2. Free

    Engine Kohler K301 Selection Guide

    12 downloads

    Updated

  3. Free

    Engine Kohler K301 12hp Spec 4710-47835 IPL #TP-2097.pdf

    Illustrated parts lists
    88 pages 5.94MB
    Dated 11/74
    Revised 9/92

    K301 (12hp or 9KW)

    1966 model 1276 used K301S-4712b

    1967 model 1257 used K301S-4712b
    1967 model 1267 used K301S-4712b
    1967 model 1277 used K301S-4712b

    1968 Charger 12 model 1-7231 used K301S-4712b
    1968 Raider 12 model 1-6231 used K301S-4712b
    1968 Electro 12 model 1-7235 used K301S-47147b

    1969 Charger 12 model 1-7241 used K301S-47147c
    1969 Electro 12 model 1-7245 used K301S-47147c
    1969 Raider 12 model 1-6241 used K301S-47147c

    1970 Charger 12 model 1-7251 used K301S-47371c
    1970 Charger 12 model 1-7252 used K301S-47147c
    1970 Electro 12 model 1-7255 used K301S-47371c
    1970 Raider 12 model 1-6251 used K301S-47371c
    1970 Raider 12 model 1-6252 used K301S-47147c

    1971 Charger 12 model 1-0400 used K301S-47407c
    1971 Raider 12 model 1-0310 used K301S-47407c

    1972 Charger 12 model 1-0401 used K301S-47421b
    1972 Charger 12 model 1-0402 used K301S-47407c
    1972 Raider 12 model 1-0311 used K301S-47421b

    1973 Raider 12 8-Speed model 1-0350 used K301S-47421d
    1973 12hp 8-Speed model 1-0355 used K301S-47421d
    1973 12hp Automatic model 1-0460 used K301S-47421d
    1973 12hp Automatic model 1-0465 used K301S-47421d

    1974 Raider 12 4-Speed model 1-0352 used K301S-47421d
    1974 C-120  8-Speed model 1-0353 used K301S-47421d
    1974 C-120  8-Speed model 1-0354 used K301S-47421d
    1974 C-120  8-Speed model 1-0356 used K301S-47421d
    1974 C-120  Automatic model 1-0485 used K301S-47421d
    1974 C-120  Automatic model 1-0490 used K301S-47421d

    1975 C-120  8-Speed model 1-0395 used K301S-47421d
    1975 C-120  8-Speed model 1-0396 used K301S-47421d
    1975 C-120  Automatic model 1-0491 used K301S-47421d

    1976 C-120  8-Speed model 61-12K801 used K301S-47421d
    1976 C-120  8-Speed model 61-12K802 used K301S-47421d
    1976 C-120  8-Speed model 61-12K803 used K301S-47421d
    1976 C-120  8-Speed model 61-12K804 used K301S-47421d
    1976 C-120  Automatic model 61-12KS01 used K301S-47421d
    1976 C-120  Automatic model 61-12KS02 used K301S-47421d
    1976 C-120  Automatic model 61-12KS03 used K301S-47421d
    1976 C-120  Automatic model 61-12KS04 used K301S-47421d

    1977 C-120  8-Speed model 71-12K801 used K301S-47421d
    1977 C-120  Automatic model 71-12KS01 used K301S-47421d
    1977 C-120  Automatic model 71-12KS02 used K301S-47624d

    1978 C-121 8-Speed model 81-12K801 used K301AS-47648d
    1978 C-121 Automatic model 81-12KS01 used K301AS-47648d

    1979 C-121 8-Speed model 91-12K801 used K301AS-47648d
    1979 C-121 8-Speed model 91-12K802 used K301AS-47648d
    1979 C-121 Automatic model 91-12KS01 used K301AS-47648d

    1980 C-125 8-Speed model 01-12K801 used K301AS-47723d
    1980 C-125 Automatic model 01-12KE01 used K301AS-47723d
    1980 C-125 Automatic model 01-12KS01 used K301AS-47723d

    1981 C-125 8-Speed model 01-12K802 used K301AS-47742
    1981 C-125 Automatic model 01-12KE02 used K301AS-47742

    1982 C-125 8-Speed model 01-12K803 used K301AS-47742

    1983 C-125 8-Speed model 11-12K801 used K301AS-47742

    1984 C-125 8-Speed model 11-12K802 used K301AS-47742

    1985 312-8 model 21-12K801 used K301S-47812

    1986 312-8 model 21-12K802 used K301S-47828 - First with low oil switch
    1986 312-8 model 21-12K803 used K301S-47828 - First with low oil switch
    1986 312-A model 21-12KE01 used K301S-47829 - First with low oil switch
    1986 312-A model 21-12KE02 used K301S-47829 - First with low oil switch

    The following were supplied to Wheel Horse according to Kohler records
    K301-4712 - 1966, 1967, 1968
    K301-47147 - 1968,1969, 1970
    K301-47205 - ?
    K301-47340 - ? - One found on 1969-70 Charger or Raider K301S-47340C
    K301-47371 - 1970
    K301-47407 - 1971, 1972
    K301-47421 - 1972, 1973, 1974, 1975, 1976, 1977 - Listed by Kohler for Norcar
    K301-47466 - ?
    K301-47624 - 1977
    K301-47636 - ?
    K301-47637 - ?
    K301-47648 - 1978, 1979
    K301-47676 - ?
    K301-47703 - ?
    K301-47723 - 1980
    K301-47742 - 1981, 1982, 1983, 1984
    K301-47798 - ?
    K301-47807 - ?
    K301-47808 - ?
    K301-47812 - 1985
    K301-47828 - 1986 - First with low oil switch
    K301-47829 - 1986 - First with low oil switch





    408 downloads

    Updated

  4. Free

    Engine Kohler Coil Battery ignition

    Battery powered ignition coil
    Kohler 231323, 231848, 232518, 232546, 232825, 237256, 47 145 01, 41 519 21 replaced by 231281

    32 downloads

    Updated

  5. Free

    Engine Kohler Carburetor throttle shaft kit #TT321-A.pdf

    Instructions for throttle shaft kit
    3 pages 3.8MB

    27 downloads

    Updated

  6. Free

    Engine Kohler Carburetor recording obsolete numbers.jpg

    Limited information available for old Kohler carburetors

    Hillman bushings to repair worn throttle shaft housing Box of 10 number 58087

    A-236636 replaced by 47 853 31-S Use A-237490 (Listed for K321 and M14)

    60 downloads
