Tillers, garden plows, harrows and such

110 files

  1. Free

    Tiller 36in 1975 7-1252 OM IPL SN.pdf

    Operator manual #803420
    IPL
    14 pages 673.66KB
    Revised 11/74
    Fits 1975 B-100 and C-Series tractors plus prior comparable 8-speed and automatic models
    Includes PSB's #180A #184 #T010 #T91-P 14

    Drive belt # 1599 (HA x 139.00in 1/2" x 139")
    If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")

    Tiller 1975 36in model 7-1252

    1975 serial numbers that have shown up for the 7-1252
    076156
    081918
    093582
    093638
    099388
    111392
    111787
    134453
    145272
    145583
    145617
    145813
    146014
    154781
    154952
    155151
    189506

    773 downloads

    Updated

  2. Free

    Tiller 36in 2001-2003 79271 260-Series OM SN.pdf

    Operator manual #3319-565RevB
    20 pages 683.34KB

    Fits 1994-1997 264-6, 264-H, 266-H Yard tractors

    Tiller 2001 36in model 79271 Serial 210000001-210999999
    2001 serial numbers that have shown up for the 79271
    210000151

    Tiller 2002 36in model 79271 Serial 220000001-220999999

    Tiller 2003 36in model 79271 Serial 230000001-230999999

    46 downloads

    Updated

  3. Free

    Tiller 24in 1964-1966 WT-244 OM IPL SN.pdf

    Operator manual #A-7139
    IPL
    2 pages 252.51KB

    Self powered by vertical shaft engine 6hp - Lauson V60-70094d
    Drive belt 1579 replaced by 1554 (4L/A x 24 or 1/2" x 24")

    Tiller 1964 24in model WT-244
    1964 serial numbers from Yahoo database range from A-50086 to A-75181 and 003301 to 049725 (There are some very early 1965 models in this group preparing for the 1965 model year so serial numbers overlap with 1965)
    1964 serial numbers that have shown up for the WT-244
    021078
    021145 - May be 021175
    021452

    Tiller 1965 24in model WT-244
    1965 serial numbers from Yahoo database range from 030922 to 147399 (There are some very early 1965 models in this group preparing for the 1965 model year so serial numbers overlap with 1964)
    040077
    040106 - Engine V60-70052C Serial 5062 04287
    040122 - Engine V60-70052C Serial 5062 04934

    Tiller 1966 24in model WT-244
    1966 serial numbers from Yahoo database range from 154770 to 293111

    144 downloads

    Updated

  4. Free

    Tiller 36in 1986-1989 07-36TL03 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    4 pages 300.95KB

    Fits all 8-speed and Automatic tractors with long frame 45-1/2" wheel base (Except 800 and 800 Automatic)

    Drive belt # 1599 (HA x 139.00in 1/2" x 139")
    If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")

    Tiller 1986 36in model 07-36TL03
    1986 serial numbers that have shown up for the 07-36TL03
    33563 - Could be a 1987 serial number
    33659 - Could be a 1987 serial number

    Tiller 1987 36in model 07-36TL03
    1987 serial numbers that have shown up for the 07-36TL03
    38041 - Build date 1986 6283 October 10 Friday
    38093 - Build date 1986 6337 December 03 Wednesday
    38213

    Tiller 1988 36in model 07-36TL03
    1988 serial numbers that have shown up for the 07-36TL03
    45310 - Build date 1988 8019 January 19 Tuesday
    45314 - Build date 1988 8019 January 19 Tuesday
    45446 - Build date 1988 8019 January 19 Tuesday
    45550 - Build date 1988 8024 January 24 Sunday
    45571 - Build date 1988 802x January 2x

    Tiller 1989 36in model 07-36TL03
    1989 serial numbers that have shown up for the 07-36TL03
    0060298 Build date 1989 923x August 18 to 27?
    0060329
    0060654

    310 downloads

    Updated

  5. Free

    Tiller 36in 1966 RT-366 OM IPL DNA sn.pdf

    Operator manual #A-5251
    IPL
    6 pages 730.79KB
    Includes PSB #083

    Fits 875, 1075, 876, 1076 and 1276
    Driven by hydro transmission pulley
    Drive belt 1586 replaced by 9714 (HA x 76" or 1/2" x 76")
    The attachment interchange states the 8-5211 speed hitch and 8-3112 pto are required but that does not sound correct.

    Tiller 1966 36in model RT-366

    Tiller DNA in the order they were produced
    1966 tiller model RT-366
    [Driven by hydro transmission pulley. Drive belt 1586 replaced by 9714 (HA x 76" or 1/2" x 76")]

    1967 tiller model RT-367
    Uses tiller hitch 7340
    Rear axle hitch mounts behind rear axle
    7353 idler arm mounts to rear of tractor frame
    [Front drive belt 1586 replaced by 9714 (HA x 76" or 1/2" x 76") Rear drive belt 7358 (4L x 65.95" or 1/2" x 65.95")]

    1968-1973 tiller model 7-1211
    Uses tiller hitch 7340
    Rear axle hitch mounts behind rear axle
    7697 idler arm mounts to rear of tractor frame
    [Front drive belt for short frame models 867, 875, 876, 87 and 1075 #1576 replaced by 9691 (HA x 70" or 1/2" x 70")
    Front drive belt for long frame models #1586 replaced by 9714 (HA x 76" or 1/2" x 76")
    Rear drive belt for all #7358 (4L x 65.95" or 1/2" x 65.95")]

    1973-1974 tiller model 7-1251
    Uses tiller hitch 103629
    Rear axle hitch mounts under rear axle
    103632 idler arm pivots in hitch
    No rear shield
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1975 tiller  model 7-1252
    Uses tiller hitch 104757
    Rear axle hitch mounts under rear axle
    104660 idler arm bolted to hitch - following models welded
    104437 rear shield mounted on 104438 rear piano hinge
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1976 tiller model 67-36TL01
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    104437 rear shield mounted on 104438 rear piano hinge
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1977 tiller model 77-36TL01
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    104437 rear shield mounted on 104438 rear piano hinge
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1977 tiller model 77-36TL02
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    106092 rear shield mounted by three straps
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1978 tiller model 87-36TL01
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    106092 rear shield mounted by three straps
    No belt guard on front idler assembly
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1979 tiller model 97-36TL01
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    106092 rear shield mounted by three straps
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1980-1982 tiller model 07-36TL01
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    106092 rear shield mounted by three straps
    Belt guard on front idler assembly retained by pulley shaft nut
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1983-1985 tiller model 07-36TL02
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    First belt guard on front idler assembly to be retained by bolts to a welded-on bracket
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1986-1989 tiller model 07-36TL03
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    [Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1990-1991 tiller model 07-36TL04
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    [Drive belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1992 tiller model 07-36TL05
    Uses tiller hitch 105543
    Rear axle hitch mounts under rear axle
    [Drive belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    1993-2001 2003-2007 tiller model 79370
    Rear axle hitch mounts under rear axle
    [Drive belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")]

    199 downloads

    Updated

  6. Free

    Tiller 50in 1983 07-50TL02 TIPL sn.pdf

    Illustrated parts list from Toro Master Parts Viewer
    5 pages 312.65KB

    Includes some assembly instructions
    Fits 18hp Auto and D-Series Automatic tractors
    Fits C-195 Twin Automatic with 3-point hitch

    Tiller 1983 50in model 07-50TL02

    70 downloads

    Updated

  7. Free

    Cultivator Rear and Mid 1969-1974 7-1722 34in OM IPL SN.pdf

    Operator manual #A-5153
    IPL
    2 pages 789.3KB

    1969 Mid and rear cultivator model 7-1722
    Serial numbers that have shown up

    1970 Mid and rear cultivator model 7-1722
    1970 serial numbers that have shown up
    712547

    1971 Mid and rear cultivator model 7-1722
    Serial numbers that have shown up

    1972 Mid and rear cultivator model 7-1722
    1972 serial numbers that have shown up
    828993 - Model year a guess

    1973 Mid and rear cultivator model 7-1722
    Serial numbers that have shown up

    1974 Mid and rear cultivator model 7-1722
    1974 serial numbers that have shown up
    0982839

    155 downloads

    Updated

  8. Free

    Tiller 36in 1987 Tilling Kit 82823 TIPL.pdf

    IPL from Toro Master Parts Viewer

    Ag tractor kit
    Agricultural tractor kit
    Possibly intended for the 1987 400-Series tractors

    20 x 8.00-10 front wheels and tires used only with this tilling kit
    27 x 8.50-15 6-stud rear wheels and ag tires used only with this tilling kit
    Heavy duty 107124 front wheel bearings as used on HD front spindle kits and 1980-83 E-141 8-speed tractors
    Rear axle 6-stud hubs 102372 used on D-Series Auto models and C-195 Twin Auto
    Left and right foot rests used only with this tilling kit
    Idler plate 111868 used only with this tilling kit
    Spring anchor 100047 also used on 5-0600 style mower deck for front pto idler pulley tension
    Eight cotter pins 908026 are not cotter pins but are 5/16"-18 x 2-3/4" bolts so part number must be wrong (8 cotter pins with 16 flat washers and 8 tube spacers shown in the illustration)
    Eight tube spacers 106574 are also used on B-81 and B-111 4-speed tractors for the pto clutch tension

    What tractor was this 1987 kit intended for?

    Tiller 1987 36in model 82823 kit
    Tiller 1987 36in model 8-2823 kit

    125 downloads

    Updated

  9. Free

    Tiller 50in 1974 7-1260 OM IPL SN.pdf

    Operator manual #803873
    IPL
    4 pages 320.35KB
    Dated 8/73

    Fits 18hp Auto and D-Series Auto tractors
    Requires 8-5421 3ph and 8-3222 pto Standard on the D-200
    38" w/o extensions

    Tiller 1974 50in model 7-1260

    1974 serial numbers that have shown up for the 7-1260
    1007904
    1033171

    181 downloads

    Updated

  10. Free

    Tiller 36in 2001 & 2003-2007 79370 IPL.pdf

    IPL #3325-784
    8 pages 169.61KB

    Fits 300, 400 and 500-Series tractors

    Drive belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")

    Tiller 2001 36in model 79370 Serial 210000001-210999999
    Tiller 2003 36in model 79370 Serial 230000001-230999999
    Tiller 2004 36in model 79370 Serial ?
    Tiller 2005 36in model 79370 Serial ?
    Tiller 2007 36in model 79370 Serial ?

    132 downloads

    Updated

  11. Free

    Cultivator Rear 1968 7-1711 34in OM IPL sn.pdf

    Operator manual #105
    IPL

    Cultivator Rear 34in 1968 model 7-1711 - Formerly AC-7

    90 downloads

    Updated

  12. Free

    Tiller 36in 1973-1974 7-1251 OM IPL SN.pdf

    Operator manual #526
    IPL
    14 pages 659.74KB
    Dated 7-73 Revised 9/73

    Fits all 8-speed and Automatic tractors with long frame 45-1/2" wheel base (Except 800 and 800 Automatic)
    Includes PSB's #143 #145 #T010 #T91-P 14

    Drive belt # 1599 (HA x 139.00in 1/2" x 139")
    If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")


    Tiller 1973 36in model 7-1251
    1973 serial numbers that have shown up for the 7-1251
    0955731 - Model 7-1251-8
    0982420 - Could be a 1974 model

    Tiller 1974 36in model 7-1251
    1974 serial numbers that have shown up for the 7-1251
    0050827 - Model 7-1251-9
    0051049 - Model 7-1251-9
    0051106 - Model 7-1251-9
    0991821 - Model 7-1251-9
    1032231 - Model 7-1251-9

    474 downloads

    Updated

  13. Free

    Tiller 36in 1998-2000 79271 260-Series OM SN.pdf

    Operator manual #3319-565RevB
    20 pages 683.34KB

    79271 Fits 1994-1997 264-6, 264-H, 266-H Yard tractors

    Tiller 1998 36in model 79271 Serial 8900001-8999999
    1998 serial numbers that have shown up for the 79271
    8900177

    Tiller 1999 36in model 79271 Serial 9900001-9999999

    Tiller 2000 36in model 79271 Serial 200000001-200999999

    53 downloads

    Updated

  14. Free

    Tiller 36in 1968-1973 7-1211 OM IPL SN.pdf

    Operator manual #A-5144
    IPL
    6 pages 837.56KB
    Dated 10/69

    Fits 6-speed and Wheel-A-Matic models

    Front drive belt for short frame models 867, 875, 876, 87 and 1075 #1576 replaced by 9691 (HA x 70" or 1/2" x 70")
    Front drive belt for long frame models #1586 replaced by 9714 (HA x 76" or 1/2" x 76")
    Rear drive belt for all #7358 (4L x 65.95" or 1/2" x 65.95")

    Tiller 1968 36in model 7-1211

    Tiller 1969 36in model 7-1211

    Tiller 1970 36in model 7-1211
    1970 serial numbers that have shown up for the 7-1211
    712390 - Model year a guess

    Tiller 1971 36in model 7-1211
    1971 serial numbers that have shown up for the 7-1211
    808989 - Model 7-1211-6
    809170 - Model 7-1211-6

    Tiller 1972 36in model 7-1211
    1972 serial numbers that have shown up for the 7-1211
    873419 - Model 7-1211-7
    873629 - Model 7-1211-7

    Tiller 1973 36in model 7-1211
    1973 serial numbers that have shown up for the 7-1211
    0897986 - Model 7-1211-8



    797 downloads

    Updated

  15. Free

    Cultivator Rear and Mid 1976 67-34CM01 OM IPL SN.pdf

    Operator manual #803463
    IPL
    4 pages 455.4KB

    1976 Cultivator 34" mid and rear mount model 67-34CM01
    Formerly model 7-1722

    1976 serial numbers that have shown up for the 67-34CM01
    013198 - Build date 1976 6050 February 19 Thursday
    013204 - Build date 1976 6051 February 20 Friday
    013246
    013364 - Build date 1976 6061 March 01 Monday

    187 downloads

    Updated

  16. Free

    Tiller 32in 1969-1973 7-1221 OM IPL sn.pdf

    Operator manual #A-5198
    IPL
    6 pages 671.92KB
    Dated 7/69

    Fits Charger and Commando V7 and V8 tractors, CG-7 and CG-8 tractors, 8hp 4-speed tractors with vertical engine crankshafts

    Tiller drive belt for hydro transmission models 9430 (4L x 36.31" or 1/2" x 36.31")
    Tiller drive belt for gear transmission models 9431 (4L x 39.6" or 1/2" x 39.6")

    Tiller 1969 32in model 7-1221

    Tiller 1970 32in model 7-1221

    Tiller 1971 32in model 7-1221

    Tiller 1972 32in model 7-1221

    Tiller 1973 32in model 7-1221

    118 downloads

    Updated

  17. Free

    Tiller 50in 1975 7-1261 OM IPL SN.pdf

    Operator manual #803873
    IPL
    4 pages 304.02KB
    Dated 9/74

    Formerly 7-1260
    Fits 18hp Auto and D-Series Auto tractors
    Requires 8-5422 3ph and 8-3222 pto Standard on the D-200
    38" w/o extensions

    Tiller 1975 50in model 7-1261

    1975 serial numbers that have shown up for the 7-1261
    098934
    140452


    191 downloads

    Updated

  18. Free

    Tiller 30in 1987-1989 07-30TL03 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    4 pages 624.95KB

    Model years a guess

    Front drive belt 108971 (HA x 49.5" or 1/2" x 49.5")
    Rear drive belt 108960 (HA x 88.5 or 1/2" x 88.5")

    Tiller 1987 30in model 07-30TL03

    Tiller 1988 30in model 07-30TL03

    Tiller 1989 30in model 07-30TL03

    105 downloads

    Updated

  19. Free

    Tiller 30in 1960 WT-30 OM IPL sn.pdf

    Operator manual #A-7139
    IPL
    3 pages 340.16KB

    Belt sleeve pdf
    1 page 168KB

    Self powered by horizontal shaft engine
    1957-1959 tractor models require CC-60 idler conversion assembly
    RJ-58 and RJ-59 require CC-60 clutch conversion
    WT-30 Tiller for Suburban tractors used K91 Kohler engine

    Info from tiller illustrated parts list
    Item #45 Tiller drive belt 1571 - (4L x 32 or 1/2" x 32")
    Item #52 Speed reduction drive belt 1572 - (4L x 34" or 1/2" x 34")

    Info on belt sleeve
    WT-30 - 1960 tiller drive belt 1573 replaced by 1561 - (4Lx30" or 1/2" x 30")
    WT-30 - Speed reduction drive belt 1574 replaced by 517439 - (A x 33.10" or 1/2" x 33.1")

    Tiller 1960 30in model WT-30

    111 downloads

    Updated

  20. Free

    Tiller 36in 1976 67-36TL01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    5 pages 367.09KB

    Fits B-Series and C-Series tractors

    Drive belt # 1599 (HA x 139.00in 1/2" x 139")
    If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")

    Tiller 1976 36in model 67-36TL01

    1976 serial numbers that have shown up for the 67-36TL01
    014098 - Build date 1976 6083 March 23 Tuesday
    014155 - Build date 1976 6084 March 24 Wednesday
    015357

    164 downloads

    Updated

  21. Free

    Tiller 36in 1969 7-1231 OM IPL SN.pdf

    Operator manual #A-5251
    IPL
    4 pages 408.46KB

    Fits GT-14 with 3ph

    Drive belt 9151 (5L x 90 or 5/8" x 90")

    Supplement #A-5251
    Mower deck and dozer blade support hooks for GT-14
    2 pages 218.31KB

    Tiller 1969 36in model 7-1231

    1969 serial numbers that have shown up for the 7-1231
    608052

    264 downloads

    Updated

  22. Free

    Tiller 36in 1977 77-36TL02 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    4 pages 235.36KB

    Drive belt # 1599 (HA x 139.00in 1/2" x 139")
    If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")

    Tiller 1977 36in model 77-36TL02

    1977 serial numbers that have shown up for the 77-36TL02
    004233 - Build date 1977 7066 March 07 Monday - Located in Sweden
    004299 - Build date 1977 707x March
    004634 - Build date 1977 7068 March 09 Wednesday - Located in the UK

    104 downloads

    Updated

  23. Free

    Tiller 36in 1992 07-36TL05 OM IPL SN.pdf

    Operator manual #3314-767
    12 pages 2.27MB

    IPL #3315-210
    8 pages 1.12MB

    Fits 300, 400 and 500-Series tractors

    Drive belt # 103635 which has been replaced by # 110265 (1/2" x 141.00")


    Tiller 1992 36in model 07-36TL05 Serial 2000001-2999999

    1992 serial numbers that have shown up for the 07-36TL05
    2000007
    2000397

    457 downloads

    Updated

  24. Free

    Tiller 30in 1982-1986 07-30TL02 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    4 pages 327.75KB

    Front drive belt 108971 (HA x 49.5" or 1/2" x 49.5")
    Rear drive belt 108960 (HA x 88.5 or 1/2" x 88.5")

    Fits
    1982 B-85 5-Speed model 02-08BX01
    1982 B-115 5-Speed model 02-11BP05
    1982 B-115 Automatic model 02-11BE01
    1982 B-165 Twin 5-Speed model 02-16BP04
    1982 B-165 Twin Automatic model 02-16BE01
    1982 LT-1137 5-Speed model A2-113701
    1982 LT-1637 Twin 5-Speed model A2-163701
    1982 LT-1642 Twin 5-Speed model A2-164201

    Tiller 1982 30in model 07-30TL02
    1982 serial numbers that have shown up for the 07-30TL02
    22110
    22255
    22370
    22403
    22563 - Build date 1982 2064 March 05 Friday
    22652 - Build date 1982 2064 March 05 Friday
    22656 - Build date 1982 2064 March 05 Friday
    22706 - Build date 1982 2068 March 09 Tuesday
    22709 - Build date 1982 2068 March 09 Tuesday [206x]

    Tiller 1983 30in model 07-30TL02

    Tiller 1984 30in model 07-30TL02

    Tiller 1985 30in model 07-30TL02

    Tiller 1986 30in model 07-30TL02

    92 downloads

    Updated

  25. Free

    Cultivator Rear and Mid 1963-1964 AC-673 OM IPL sn.pdf

    Operator manual #128
    IPL

    Lift link is # 3777

    Cultivator Rear and Mid 1963 AC-673

    Cultivator Rear and Mid 1964 AC-673

    178 downloads

    Updated

Sign in to follow this



×
×
  • Create New...
