Manuals for grass gutting

659 files

  1. Free

    Mower Sickle Side 42in 1962-64 SMS-42A OM IPL SN.pdf

    Operator manual #A-7137
    IPL
    2 pages 166.08KB - #115-A Manual only
    4 pages 1.62MB - #A-7137 Includes Kit 6051 and PSB #064 on kit 6059

    Fits short frame tractors
    Special instructions for 1045 tractor
    SMS-42A listed as SMS-42-A in the Attachment Interchange

    Engine drive belt 1572 - 4L x 34" or 1/2" x 34"
    Mower drive belt 1588 - A x 59" or 1/2" x 59"

    Mower Sickle 1962 42in Side model SMS-42A
    1962 serial numbers that have shown up for the SMS-42A
    A-06945 - May be a SMS-42
    A-11982
    A-11987
    A-19794
    A-19878
    A-19917 - May be a SMS-42

    Mower Sickle 1963 42in Side model SMS-42A
    1963 serial numbers that have shown up for the SMS-42A
    A-40113
    A-40170
    A-40378
    A-40391
    A-40719 - Located in the UK
    A-40754

    Mower Sickle 1964 42in Side model SMS-42A
    1964 serial numbers that have shown up for the SMS-42A
    A-75146
    A-75181


    274 downloads

    Updated

  2. Free

    Mower Rotary 42in RD 1978 85-42MR01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    6 pages 336.48KB

    Fits C-Series tractors

    Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
    Spindle belt 106125 (1/2" x 89.03")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1978 42in RD model 85-42MR01

    1978 serial numbers that have shown up for the 85-42MR01
    005584 - Build date 1978 8186 July 05 Wednesday - Looks wrong
    022261 - Build date 1978 8144 May 24 Wednesday
    022345 - Build date 1978 8145 May 25 Thursday
    027898
    028056 - Build date 1978 8172 June 21 Wednesday



    108 downloads

    Updated

  3. Free

    Mower Rotary 42in RD 1995-1998 78350 IPL.pdf

    IPL #3317-340
    8 pages 119.03KB

    Fits 300, 400 and 500-Series tractors

    Drive belt 108834 (1/2" x 98")
    Spindle belt 106125 (1/2" x 89.03")

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1995 42in RD model 78350 Serial 5900001-5999999

    Mower Rotary 1996 42in RD model 78350 Serial 6900001-6999999

    Mower Rotary 1997 42in RD model 78350 Serial 7900001-7999999

    Mower Rotary 1998 42in RD model 78350 Serial 8900001-8999999

    131 downloads

    Updated

  4. Free

    Edger Trimmer 34-30BC01 D TIPL.pdf

    Details
    Illustrated parts list from Toro Master Parts Viewer
    4 pages 208.68KB

    It is a rebranded McLane - CasualObserver

    1986 Edger/Trimmer model 34-30BC01 using B&S engine
    1987 Edger/Trimmer model 34-30BC01 using B&S engine
    1988 Edger/Trimmer model 34-30BC01 using B&S engine
    1989 Edger/Trimmer model 34-30BC01 using B&S engine

    There was also
    1988 Edger/Trimmer model 34-30BC02 using Kawasaki engine

    7-Blade reel mower also supplied by McLane

    39 downloads

    Updated

  5. Free

    Mower Rotary 36in RD 2000-2006 78305 IPL.pdf

    IPL #3323-801
    12 pages 104.83KB

    Fits 300-Series and 400-Series tractors
    Fits B-Series and C-Series tractors

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for C-Series tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower Rotary 2000 36in RD model 78305 Serial 200000001-200999999

    Mower Rotary 2001 36in RD model 78305 Serial 210000001-210999999

    Mower Rotary 2002 36in RD model 78305 Serial 220000001-220999999

    Mower Rotary 2003 36in RD model 78305 Serial 230000001-230999999

    Mower Rotary 2004 36in RD model 78305 Serial 240000001-240999999

    Mower Rotary 2005 36in RD model 78305 Serial 250000001-250999999

    Mower Rotary 2006 36in RD model 78305 Serial 260000001-260999999

    65 downloads

    Updated

  6. Free

    Mower Rotary 37in SD 1985 05-37MS05 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    6 pages 395.61KB

    Fits 200-Series tractors

    Drive belt 110082 (1/2" x 48.5")
    Spindle belt 108195 (1/2" x 67")

    Mower Rotary 1985 37in SD model 05-37MS05

    1985 serial numbers that have shown up for the 05-37MS05
    53299

    76 downloads

    Updated

  7. Free

    Mower Rotary 42in SD 1994-1997 78345 3-400 IPL.pdf

    IPL #3316-619RevC or 3316-619 RevC
    8 pages 1.32MB

    Fits 300 and 400-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103") [108834 is wrong in the belt chart for 1996 and 1997]
    Spindle belt 6738 (1/2" x 86") [106125 is wrong in the belt chart for 1996 and 1997]

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1994 42in SD model 78345 Serial 4900001-4999999

    Mower Rotary 1995 42in SD model 78345 Serial 5900001-5999999


    Mower Rotary 1996 42in SD model 78345 Serial 6900001-6999999 -  [Belts wrong in the belt chart for 1996]

    Mower Rotary 1997 42in SD model 78345 Serial 7900001-7999999 -  [Belts wrong in the belt chart for 1997]

    197 downloads

    Updated

  8. Free

    Mower Rotary 32in RD 1964-1965 RM-324 OM IPL SN.pdf

    Operator manual #171
    IPL
    3 pages 1.26MB

    Fits all except Lawn Ranger and 1054
    First model to use latches to mount the mower in the frame plates.

    Drive belt 1577 replaced by 7430 (1/2" x 28")
    Spindle belts 1578 (3/8" x 37" matched pair)

    8777 2-blade set replaces 3719, 7760 and 7909 left blades and 3718, 7761 and 7908 right blades

    Mower Rotary 1964 32in RD model RM-324
    1964 serial numbers that have shown up for the RM-324
    010531 - Model and year a guess
    013129 - Model and year a guess

    Mower Rotary 1965 32in RD model RM-324
    1965 serial numbers that have shown up for the RM-324
    122333
    122336

    423 downloads

    Updated

  9. Free

    Mower Rotary 32in RD 1956-1960 RMR-32 OM IPL sn.pdf

    Includes RMR-3256
    Operator manual #A-7137
    IPL
    4 pages 1.79MB
    This contains 2 different versions of the RMR-32
    Appears to be a difference in the mower drive belt clutch but deck model numbers the same.

    1956-1960 Drive belt 1561 (1/2" x 30") - Listed on belt sleeve as 1956-1961
    Jack shaft belt 1554 (1/2" x 24") - Listed on belt sleeve as 1960 only

    Mower blade kit # 6005 - Still available from Toro July 5, 2016 April 7, 2020

    1960 model RMR-32 @ Toro possibly should be RMR-3260
    The RMR-3256 suggests it was a 32" deck introduced in 1956
    LL-60 lift required for the RJ-58 and RJ-59

    Mower Rotary 1956 32in RD model RMR-32 - Found in belt chart and on February 1, 1956 price list - Used on riding tractors

    Mower Rotary 1957 32in RD model RMR-3256 - Found in price list

    Mower Rotary 1958 32in RD model RMR-3256 - Found in price list

    Mower Rotary 1959 32in RD model RMR-32 - Found in price list
    Mower Rotary 1959 32in RD model RMR-3256 - Found in price list

    Mower Rotary 1960 32in RD model RMR-32 - Found in belt chart - Listed on belt sleeve as 1960 only

    Mulcher kit for 1958 RMR-3256 deck model MU-35
    Mulcher kit for 1959 RMR-3256 deck model MU-35
    MU-35 parts and hardware listed in November 1959 manual
    1 page 80KB

    592 downloads

    Updated

  10. Free

    Mower Rotary 48in SD 1997 78365 3-4-500 Recycler OM IPL SN.pdf

    Operator manual #3319-371RevA or 3319-371 RevA
    28 pages 811.75KB

    IPL #3319-439
    10 pages 155.58KB

    Fits 300-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 1594 (1/2" x 107.21")

    Mower Rotary 1997 48in SD model 78365 Recycler Serial 7900001-7999999

    1997 serial numbers that have shown up for the 78365
    7900200
    7900265
    7900323

    101 downloads

    Updated

  11. Free

    Mower Rotary 48in SD 1981-1983 05-48MS02 C OM IPL SN.pdf

    Operator manual #810306R1 or 810306 R1
    7 pages 1.29MB

    Illustrated parts list removed from Work Horse tractor ipl #810286R1
    7 pages 7.8MB

    Illustrated parts list from Toro Master Parts Viewer
    7 pages 388.11KB

    Fits C-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 1594 (1/2" x 107.21")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 292B

    106078 blade replaced by 106637 3-blade set (3/4" round hole)

    Mower Rotary 1981 48in SD model 05-48MS02
    1981 serial numbers that have shown up for the 05-48MS02
    033989 - Build date 1981 1173 June 22 Wednesday
    039413 - Build date 076 looks wrong
    041789

    Mower Rotary 1982 48in SD model 05-48MS02

    Mower Rotary 1983 48in SD model 05-48MS02

    [M]

    226 downloads

    Updated

  12. Free

    Mower Rotary 42in SD 1981-1983 05-42MS02 OM TIPL SN.pdf

    Operator manual #810306R1 or 810306 R1
    7 pages 1.29MB

    Illustrated parts list removed from Work Horse tractor ipl #810286R1
    7 pages 7.8MB

    Illustrated parts list from Toro Master Parts Viewer
    7 pages 388.11KB
    This IPL includes the 48" deck so be careful selecting part numbers.

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Drive belt with front mower carrier and single cylinder engine 109956 (1/2" x 102")
    Drive belt with front mower carrier and twin cylinder engine 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1981 42in SD model 05-42MS02 - fits C-Series and GT-2500 tractors
    1981 serial numbers that have shown up for the 05-42MS02
    036011
    038387 - Build date 1981 11xx
    041637 - Could also be 1982 or 1983
    043140 - Could also be 1982 or 1983

    Mower Rotary 1982 42in SD model 05-42MS02 - fits C-Series, GT-1642 and GT-1848 tractors
    1982 serial numbers that have shown up for the 05-42MS02
    33225 - Build date 1981 x256 September 13 Sunday - Model year a guess
    39008 - Build date 1982 2048 February 17 Wednesday

    Mower Rotary 1983 42in SD model 05-42MS02 - fits C-Series, GT-1142, GT-1642 and GT-1848 tractors
    1983 serial numbers that have shown up for the 05-42MS02
    42472 - Build date 1982 2355 December 21 Tuesday

    442 downloads

    Updated

  13. Free

    Mower Rotary 36in SD 1971 5-0711 OM IPL SN.pdf

    Operator manual #A-5122
    IPL
    4 pages 1.13MB
    Dated 7/69 Revised 1/22/71

    This is a 1972 model @ Toro
    Fits 800 models, Raider, Charger, Bronco tractors - long frame 45-1/2" wheel base
    Clockwise spindle rotation

    Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be C, A1, G1 or Z
    For A1 see service bulletin 292B
    For G1 see service bulletin 292B

    100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
    2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.
    101335 blade set available again from Toro June 4, 2019

    Mower Rotary 1971 36in SD model 5-0711

    1971 serial numbers that have shown up for the 5-0711
    791664 - Model 5-0711-6
    813210 - Model 5-0711-6

    91 downloads

    Updated

  14. Free

    Mower Sickle Side 48in Haban 414 OM SM IPL.pdf

    This is my original Haban 414 Sickle bar mower Operation and Service Manual with repair parts list. I removed it from my GT 14.

    447 downloads

    Updated

  15. Free

    Mower Rotary 36in RD 1983-1984 05-36MR02 OM TIPL sn.pdf

    Operator manuals
    7 pages 1.29MB #810306R1 or 810306 R1
    7 pages 450.87KB #810345R1 or 810345 R1

    IPL from Toro Master Parts Viewer
    6 pages 348.78KB

    Fits GT-1100, GT-1600 and C-Series except C-195 Twin tractors
    Fits B-Series tractors

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for C-Series long frame tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assembly H

    107983 3-blade set replaces 107437 left and right blades (12-1/8") and 107438 center blade (14-1/8") (Hole 3/4" round)

    Mower Rotary 1983 36in RD model 05-36MR02

    Mower Rotary 1984 36in RD model 05-36MR02

    176 downloads

    Updated

  16. Free

    Mower Rotary 38in SD 1992 R5-38SL02 Recycler OM IPL sn.pdf

    Operator manual #3314-786
    9 pages 2.4MB

    IPL
    4 pages 841KB

    Fits model 212-5 and 212-H

    Drive and spindle belt 121330 (1/2" x 79.25")

    Mower Rotary 1992 38in SD Recycler model R5-38SL02 Serial 2000001-2999999

    43 downloads

    Updated

  17. Free

    Mower Reel Gang 1960 GM-60 OM IPL.pdf

    Operator manual
    Illustrated parts list
    4 pages 522KB including hitch page from November 1959 manual

    Three 21" reels ganged make 60" cut
    Pennsylvania
    American Chain and Cable

    GM-60



    58 downloads

    Updated

  18. Free

    Mower Reel Front 30in 1958-1960 LMR-30 OM IPL sn.pdf

    Operator manual #A-7137
    IPL
    4 pages 1.54MB

    Drive belt 1562 (4Lx88" or 1/2" x 88") - Listed on belt sleeve as 1956-1960)
    Drive belt 1570 (4L/A x 69" or 1/2" x 69") - Listed on belt sleeve as late 1960. Possibly referring to the 1961 model 701 with engine at the front.

    Mower Reel 1958 30in Front model LMR-30

    Mower Reel 1959 30in Front model LMR-30

    Mower Reel 1960 30in Front model LMR-30

    206 downloads

    Updated

  19. Free

    Mower Sickle Front 32in 1955 - 1961 OM IPL sn.pdf

    Operator manual #A-7137
    IPL
    2 pages 565.98KB
    2 pages 784.23KB
    2 pages 250KB from manual dated November 1959 for 1960 models

    Drive belt 1563 (4L x 39" or 1/2" x 39") - Listed on belt sleeve as 1956-1960

    Mower Sickle 1955 32in Front model CBR-32 - Fits riding tractors

    Mower Sickle 1956 32in Front model CBR-32 - Fits riding tractors

    Mower Sickle 1957 32in Front model CBR-32

    Mower Sickle 1958 32in Front model CBR-32

    Mower Sickle 1959 32in Front model CBR-32

    Mower Sickle 1960 32in Front model CBR-32

    Mower Sickle 1961 32in Front model CBR-32 - Fits all except the 701

    449 downloads

    Updated

  20. Free

    Mower Rotary 32in RD 1965 RM-115 PL SN.pdf

    IPL from Toro Master Parts Viewer
    2 pages 202.11KB

    Fits Lawn Ranger

    Mower belt 1555 replaced by 113912 (1/2" x 44")

    8777 2-blade set replaces 3719, 7760 and 7909 left blades and 3718, 7761 and 7908 right blades

    Mower Rotary 1965 32in RD model RM-115

    1965 serial numbers that have shown up for the RM-115
    113404
    113781

    109 downloads

    Updated

  21. Free

    Mower Rotary 36in SD 1970 5-2365 CCW TIPL SN DNA.pdf

    IPL from Toro Master Parts Viewer
    2 pages 231.68KB

    CCW spindle rotation with left side discharge
    Fits Commando V7, Charger V7, Commando V8 and Charger V8 tractors

    Drive belt 8412 (1/2" x 86")
    Spindle belt 8411 (1/2" x 76.94")

    100460 center blade and 100459 left and right blades replaced by 101093 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)

    Mower Rotary 1970 36in SD model 5-2365 CCW

    1970 serial numbers that have shown up for the 5-2365
    708941
    728558
    728660

    36in side discharge decks with CCW rotation blades DNA
    1970 side discharge model 5-2365
    1971 side discharge model 5-0700
    1972 side discharge model 5-0701
    1973 side discharge model 5-0702

    75 downloads

    Updated

  22. Free

    Mower Rotary 48in SD 1966-1967 RL-486 TIPL DNA SN.pdf

    IPL from Toro Master Parts Viewer
    2 pages 234.87KB

    Fits 10hp and larger long frame tractors
    Requires 8-5211 85211 speed hitch

    Drive belt 6771 replaced by 9783 (1/2" x 71")
    Spindle belt 1594 (1/2" x 107.21")

    Mower spindle assemblies could be J, N, U, V, Y or Z
    For N and U see service bulletin 221B
    For V and Y see service bulletin 292B

    4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)

    Mower Rotary 1966 48in SD model RL-486

    Mower Rotary 1967 48in SD model RL-486
    1967 serial numbers that have shown up for the RL-486
    354753

    Mower DNA 48" side discharge
    1966-1967 model RL-486 replaced by
    1968 model 5-1481
    1969 model 5-1482
    1970 model 5-1483
    1971 model 5-1200
    1972 model 5-1201
    1973 model 5-1202
    1973-1974 model 5-1210
    1975 model 5-1211
    1976 model 65-48MS01
    1976 model 65-48MS02
    1977 model 75-48MS01 - These all used blades with 5/8" x 3/4" double-D center hole unless the spindles have been upgraded.
    -------------------------------------------------------------------------------------------------------------------------------------------------------------------------
    Note - 3/4" or .750" is 19.05mm
    1977 model 75-48MS02 - Uses 6203 bearings with 3/4" ID - (First deck to use blades with 3/4" center hole) - Originally had a nylon-insert nut holding spindle pulley on.
    1978 model 85-48MS01 - Uses 6203 bearings with 3/4" ID - Originally had a nylon-insert nut holding spindle pulley on.
    1979 model 95-48MS00 - Uses 6203 bearings with 3/4" ID - Originally had a nylon-insert nut holding spindle pulley on.
    1979 model 95-48MS01 - Uses 6203 bearings with 3/4" ID - Originally had a nylon-insert nut holding spindle pulley on.
    1980 model 05-48MS01 - Uses 6203 bearings with 3/4" ID - Originally had a nylon-insert nut holding spindle pulley on.
    1981-1983 model 05-48MS02 - Uses 6203 bearings with 3/4" ID - Originally had a nylon-insert nut holding spindle pulley on.
    1984 model 05-48MS03 - Uses 6203 bearings with 3/4" ID - Originally had a nylon-insert nut holding spindle pulley on.

    Note - 17mm is .669"
    1985 model 05-48MS04 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1986-1988 model 05-48MS05 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1987-1988 model 05-48SC01 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1989 model 15-48SC01 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1990 model 15-48SC02 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1991-1992 model 15-48SC03 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1993-1997 model 78360 - Uses 6203 bearings with 17mm ID - Originally had a standard nut and lockwasher holding spindle pulley on.
    1998-2007 and 2009-12 model 78361 - Uses 6203 bearings with 17mm ID - (These all use blades with 3/4" center hole) - Originally had a standard nut and lockwasher holding spindle pulley on.

    231 downloads

    Updated

  23. Free

    Mower Rotary 48in SD 2006 79310 5xi Vacuum bagger OM IPL sn.pdf

    Operator manual #3323-317
    24 pages 871KB

    IPL #3353-405
    12 pages 150KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    2006 11 cu. ft. 48in vac bagger model 79310 Serial 260000001-260999999

    41 downloads

    Updated

  24. Free

    Mower Rotary 48in SD 2003-2004 79310 5xi Vacuum bagger OM IPL sn.pdf

    Operator manual #3323-317
    24 pages 871KB

    IPL #3324-731
    8 pages 164KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    2003 11 cu. ft. 48in vac bagger model 79310 Serial 230000001-230999999
    2004 11 cu. ft. 48in vac bagger model 79310 Serial 240000001-240999999

    41 downloads

    Updated

  25. Free

    Mower Rotary 48in SD 2001 79310 5xi Vacuum bagger OM IPL sn.pdf

    Operator manual #3323-317
    24 pages 871KB

    IPL #3324-731
    8 pages 164KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    2001 11 cu. ft. 48in vac bagger model 79310 Serial 210000001-210999999

    20 downloads

    Updated

Sign in to follow this



×
×
  • Create New...
