659 files
-
Free
Mower Rotary 36in RD 1974 5-0602 CW TIPL sn.pdf
By admin-(Admin)
IPL from Toro Master Parts Viewer
3 pages 247.09KB
This file was found with 1974 A-90 Special model 2-4300 ipl at Toro MPV
If you search for 5-0602 the R-26 Rear Engine Rider 26" single-blade deck comes up as a 5-0602 also which must be wrong.
Suspect this 5-0602 replaced the 5-0601
Mower spindle assemblies could be B, A1, G2 or Z
For A1 see service bulletin 292B
For G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1974 36in RD model 5-0602 CW
148 downloads
Updated
-
Free
Mower Rotary 36in RD 1975 5-0622 TIPL.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 233.68KB
Fits long frame tractors
Replaced by 65-36XR01 for 1976
Clockwise spindle rotation
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for C-Series tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be D, A1, G2 or Z
For A1 and G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1975 36in RD model 5-0622
114 downloads
Updated
-
Free
Mower Rotary 36in RD 1970 5-7366 CW OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-5122
IPL
4 pages 1.13MB
Fits 10hp and 12hp long frame tractors
Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be B, A1, G2 or Z
For A1 see service bulletin 292B
For G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1970 36in RD model 5-7366
107 downloads
Updated
-
Free
Mower Rotary 36in RD 1971-1972 5-0601 OM IPL SN.pdf
By admin-(Admin)
Operator manual #A-5122
IPL
4 pages 1.13MB
Fits long frame tractors
Clockwise spindle rotation
Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be C, A1, G2 or Z
For A1 see service bulletin 292B
For G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1971 36in RD model 5-0601
1971 serial numbers that have shown up for the 5-0601
775508 - Model 5-0601-6 (Most locations listed as 1972 model only)
Mower Rotary 1972 36in RD model 5-0601
135 downloads
Updated
-
Free
Mower Rotary 36in RD 1977 75-36XR01 TIPL SN.pdf
By admin-(Admin)
IPL from Toro Master Parts Viewer
2 pages 214.38KB
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be D, A1, G2 or Z
For A1 and G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1977 36in RD model 75-36XR01
1977 serial numbers that have shown up for the 75-36XR01
009804 - Build date 1976 6348 December 13, Monday
161215 - Model 75-36XR made in Belgium
155 downloads
Updated
-
Free
Mower Rotary 36in RD 1979 95-36MR00 & 95-36MR01 IPL SN.pdf
By admin-(Admin)
IPL #810121R1 (Not for the 95-36MR00 - no ipl available)
7 pages 1.34MB
Fits B-Series and C-Series tractors
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies for 95-36MR00 could be D, A1, G2 or Z
For A1 and G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D) Last 36" RD deck to use these blades
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1979 36in RD model 95-36MR00 - IPL not available
1979 serial numbers that have shown up the the 95-36MR00
009449
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Mower spindle assemblies for 95-36MR01 could be E, A1, F or Z
For A1 see service bulletin 292B
107982 3-blade set replaces 107435 left and right blades (12-1/8") and 107436 center blade (14-1/8") (Hole 3/4" round) First 36" RD deck to use these blades
Mower Rotary 1979 36in RD model 95-36MR01
1979 serial numbers that have shown up the the 95-36MR01
041217 - Build date 1979 9200 July 19 Thursday
120 downloads
Updated
-
Free
Mower Rotary 36in RD 1973-1974 5-0621 CW TPL.pdf
By admin-(Admin)
Parts list only - no illustration
2 pages 106.36KB
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be B, A1, G2 or Z
For A1 see service bulletin 292B
For G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1973 36in RD model 5-0621
Mower Rotary 1974 36in RD model 5-0621
203 downloads
Updated
-
Free
Mower Rotary 36in SD 1980-1982 05-36MS01 OM IPL SN.pdf
By admin-(Admin)
Operator manual #810306R1 or 810306 R1
7 pages 1.29MB
IPL #810172R1
7 pages 718.42KB
Fits B-Series and C-Series tractors
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be A1, F or Z
For A1 see service bulletin 221B
107983 3-blade set replaces 107437 left and right blades (12-1/8") and 107438 center blade (14-1/8") (Hole 3/4" round)
Mower Rotary 1980 36in SD model 05-36MS01
1980 serial numbers that have shown up for the 05-36MS01
00026670 - Build date 1980 0107 April 16 Wednesday [010/]
Mower Rotary 1981 36in SD model 05-36MS01
Mower Rotary 1982 36in SD model 05-36MS01
115 downloads
Updated
-
Free
Mower Rotary 42in RD 1993 78351 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #3315-936
8 pages 1.57MB
Setup
1 page
IPL #3316-245
8 pages 1.30MB
Some manuals call this a low cut deck.
Application unknown. Sold 1993 1994 1995 and 1996. Suspect it fits exported 300 and 400-Series tractors
Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
Spindle belt 106125 (1/2" x 89.03")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1993 42in RD model 78351 Serial 3900001-3999999
54 downloads
Updated
-
Free
Mower Rotary 42in RD 1995-1996 78351 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #3316-953
8 pages 1.35MB
Setup
1 page
IPL #3317-460RevA or 3317-460 RevA
8 pages 1.31MB
Some manuals call this a low cut deck.
Application unknown. Sold 1993 1994 1995 and 1996. Suspect it fits exported 300 and 400-Series tractors
Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
Spindle belt 106125 (1/2" x 89.03")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1995 42in RD model 78351 Serial 5900001-5999999
1995 serial numbers that have shown up for the 78351
5900241 - Located in Finland
Mower Rotary 1996 42in RD model 78351 Serial 6900001-5999999
105 downloads
Updated
-
Free
Mower Rotary 42in RD 1994 78351 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #3316-432
8 pages 1.32MB
IPL #3316-621
8 pages 1.46MB
Some manuals call this a low cut deck.
Application unknown. Sold 1993 1994 1995 and 1996. Suspect it fits exported 300 and 400-Series tractors
Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
Spindle belt 106125 (1/2" x 89.03")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1994 42in RD model 78351 Serial 4900001-4999999
41 downloads
Updated
-
Free
Mower Rotary 38in SD 1997-1998 78216 & Recycler 78225 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3319-381
8 pages 136KB
Mower drive and spindle belt 79-5980 (1/2" x 81.80")
78216 Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
78226 Recycler blades
79-3061 replaced by 79-3061-03 replaced by 14-7799 blade kit
Fits 260-Series
Mower Rotary 38in SD 1997 model 78216 Serial 7900001-7999999
Mower Rotary 38in SD 1998 model 78216 Serial 8900001-8999999
Mower Rotary 38in SD Recycler 1997 model 78226 Serial 7900001-7999999
Mower Rotary 38in SD Recycler 1998 model 78226 Serial 8900001-8999999
38 downloads
Updated
-
Free
Mower Rotary 38in SD 1998-1999 78216 & Recycler 78226 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3319-558
24 pages 804KB
Fits 260-Series
Mower Rotary 38in SD 1998 model 78216 Serial 8900001-8999999
Mower Rotary 38in SD 1999 model 78216 Serial 9900001-9999999
Mower Rotary 38in SD Recycler 1998 model 78226 Serial 8900001-8999999
112 downloads
Updated
-
Free
Mower Rotary 38in SD 1997 78216 & Recycler 78226 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3318-912
24 pages 995KB
Fits 260-Series
Mower Rotary 38in SD 1997 model 78216 Serial 7900001-7999999
Mower Rotary 38in SD Recycler 1997 model 78226 Serial 7900001-7999999
29 downloads
Updated
-
Free
Mower Rotary 38in SD 1994-1996 78216 & Recycler 78226 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3316-520
24 pages 1.8MB
Fits 260-Series
Mower Rotary 38in SD 1994 model 78216 Serial 4900001-4999999
Mower Rotary 38in SD 1995 model 78216 Serial 5900001-5999999
Mower Rotary 38in SD 1996 model 78216 Serial 6900001-6999999
Mower Rotary 38in SD Recycler 1994 model 78226 Serial 4900001-4999999
Mower Rotary 38in SD Recycler 1995 model 78226 Serial 5900001-5999999
Mower Rotary 38in SD Recycler 1996 model 78226 Serial 6900001-6999999
29 downloads
Updated
-
Free
Mower Rotary 38in SD 1993-1994 78215 240 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #3315-432
8 pages 1.7MMB
Setup instructions #3315-697
1 page 56KB
1993 Mower drive and spindle belt 79-5980 (1/2" x 81.80") $35.53 at Toro
1994 Mower drive and spindle belt 92-7066 (Aftermarket replacements listed as 1/2" x 82) $80.45 at Toro
Fits 244-5, 244-H and 246-H
Can be equipped with 86032 recycliner kit
Mower Rotary 38in SD 1993 model 78215 Serial 3900001-3999999
1993 serial numbers that have shown up for the 78215
3900194
Mower Rotary 38in SD 1994 model 78215 Serial 4900001-4999999
87 downloads
Updated
-
Free
Mower Rotary 38in SD 1999 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3322-616
8 pages 339KB
Mower drive and spindle belt 92-7066 (Replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 1999 model 78216 Serial 9900001-9999999
27 downloads
Updated
-
Free
Mower Rotary 38in SD 2001-2003 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3325-540
8 pages 193KB
Mower drive and spindle belt 92-7066 (Replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 2001 model 78216 Serial 210000001-210999999
Mower Rotary 38in SD 2002 model 78216 Serial 220000001-220999999
Mower Rotary 38in SD 2003 model 78216 Serial 230000001-230999999
33 downloads
Updated
-
Free
Mower Rotary 38in SD 2000 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3323-898
8 pages 195KB
Mower drive and spindle belt 92-7066 (Replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 2000 model 78216 Serial 200000001-200999999
30 downloads
Updated
-
Free
Mower Rotary 38in SD 2001-2003 78216 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3325-539
20 pages 893KB
Fits 260-Series
Mower Rotary 38in SD 2001 model 78216 Serial 210000001-210999999
Mower Rotary 38in SD 2002 model 78216 Serial 220000001-220999999
Mower Rotary 38in SD 2003 model 78216 Serial 230000001-230999999
27 downloads
Updated
-
Free
Mower Rotary 38in SD 2000 78216 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3323-904
24 pages 815KB
Fits 260-Series
Mower Rotary 38in SD 2000 model 78216 Serial 200000001-200999999
32 downloads
Updated
-
Free
Mower Rotary 48in SD 1978 85-48MS01 C TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 354.52KB
Fits C-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 292B
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1978 48in SD model 85-48MS01
74 downloads
Updated
-
Free
Mower Rotary 36in RD 1972-1973 5-0611 CCW OM IPL SN.pdf
By admin-(Admin)
Operator manual #A5337
IPL
6 pages 1.04MB
Dated 8/72
CCW spindle rotation
Fits vertical shaft CG-7 and CG-8 tractors (1955-2000 Attachment interchange is wrong for 1972
Drive belt 8412 (1/2" x 86")
Spindle belt 8411 (1/2" x 76.94")
8393 center blade and 8394 left and right blades replaced by 9819 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1972 36in RD model 5-0611
Mower Rotary 1973 36in RD model 5-0611
1973 serial numbers that have shown up for the 5-0611
0922659 - Model 5-0611-8
Was still available in 1974 according to the price list
74 downloads
Updated
-
Free
Mower Rotary 38in SD 1993 78215 240 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3316-228
4 pages 949KB
1993 Mower drive and spindle belt 79-5980 $35.53 at Toro (1/2" x 81.80")
1994 Mower drive and spindle belt 92-7066 $80.45 at Toro (Aftermarket replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 244-5, 244-H and 246-H
Can be equipped with 86032 recycliner kit
Mower Rotary 38in SD 1993 model 78215 Serial 3900001-3999999
30 downloads
Updated
-
Free
Mower Rotary 38in SD 1994 78215 240 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3316-749
4 pages 109KB
1993 Mower drive and spindle belt 79-5980 $35.53 at Toro (1/2" x 81.80")
1994 Mower drive and spindle belt 92-7066 $80.45 at Toro (Aftermarket replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 244-5, 244-H and 246-H
Can be equipped with 86032 recycliner kit
Mower Rotary 38in SD 1994 model 78215 Serial 4900001-4999999
29 downloads
Updated
