Mower Rotary 38in SD 1998-1999 78216 & Recycler 78226 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3319-558
24 pages 804KB
Fits 260-Series
Mower Rotary 38in SD 1998 model 78216 Serial 8900001-8999999
Mower Rotary 38in SD 1999 model 78216 Serial 9900001-9999999
Mower Rotary 38in SD Recycler 1998 model 78226 Serial 8900001-8999999
120 downloads
Updated
-
Free
Mower Rotary 38in SD 1997 78216 & Recycler 78226 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3318-912
24 pages 995KB
Fits 260-Series
Mower Rotary 38in SD 1997 model 78216 Serial 7900001-7999999
Mower Rotary 38in SD Recycler 1997 model 78226 Serial 7900001-7999999
39 downloads
Updated
-
Free
Mower Rotary 38in SD 1994-1996 78216 & Recycler 78226 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3316-520
24 pages 1.8MB
Fits 260-Series
Mower Rotary 38in SD 1994 model 78216 Serial 4900001-4999999
Mower Rotary 38in SD 1995 model 78216 Serial 5900001-5999999
Mower Rotary 38in SD 1996 model 78216 Serial 6900001-6999999
Mower Rotary 38in SD Recycler 1994 model 78226 Serial 4900001-4999999
Mower Rotary 38in SD Recycler 1995 model 78226 Serial 5900001-5999999
Mower Rotary 38in SD Recycler 1996 model 78226 Serial 6900001-6999999
53 downloads
Updated
-
Free
Mower Rotary 38in SD 1993-1994 78215 240 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #3315-432
8 pages 1.7MMB
Setup instructions #3315-697
1 page 56KB
1993 Mower drive and spindle belt 79-5980 (1/2" x 81.80") $35.53 at Toro
1994 Mower drive and spindle belt 92-7066 (Aftermarket replacements listed as 1/2" x 82) $80.45 at Toro
Fits 244-5, 244-H and 246-H
Can be equipped with 86032 recycliner kit
Mower Rotary 38in SD 1993 model 78215 Serial 3900001-3999999
1993 serial numbers that have shown up for the 78215
3900194
Mower Rotary 38in SD 1994 model 78215 Serial 4900001-4999999
104 downloads
Updated
-
Free
Mower Rotary 38in SD 1999 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3322-616
8 pages 339KB
Mower drive and spindle belt 92-7066 (Replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 1999 model 78216 Serial 9900001-9999999
37 downloads
Updated
-
Free
Mower Rotary 38in SD 2001-2003 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3325-540
8 pages 193KB
Mower drive and spindle belt 92-7066 (Replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 2001 model 78216 Serial 210000001-210999999
Mower Rotary 38in SD 2002 model 78216 Serial 220000001-220999999
Mower Rotary 38in SD 2003 model 78216 Serial 230000001-230999999
40 downloads
Updated
-
Free
Mower Rotary 38in SD 2000 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3323-898
8 pages 195KB
Mower drive and spindle belt 92-7066 (Replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 2000 model 78216 Serial 200000001-200999999
46 downloads
Updated
-
Free
Mower Rotary 38in SD 2001-2003 78216 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3325-539
20 pages 893KB
Fits 260-Series
Mower Rotary 38in SD 2001 model 78216 Serial 210000001-210999999
Mower Rotary 38in SD 2002 model 78216 Serial 220000001-220999999
Mower Rotary 38in SD 2003 model 78216 Serial 230000001-230999999
36 downloads
Updated
-
Free
Mower Rotary 38in SD 2000 78216 260 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3323-904
24 pages 815KB
Fits 260-Series
Mower Rotary 38in SD 2000 model 78216 Serial 200000001-200999999
41 downloads
Updated
-
Free
Mower Rotary 48in SD 1978 85-48MS01 C TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 354.52KB
Fits C-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 292B
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1978 48in SD model 85-48MS01
104 downloads
Updated
-
Free
Mower Rotary 36in RD 1972-1973 5-0611 CCW OM IPL SN.pdf
By admin-(Admin)
Operator manual #A5337
IPL
6 pages 1.04MB
Dated 8/72
CCW spindle rotation
Fits vertical shaft CG-7 and CG-8 tractors (1955-2000 Attachment interchange is wrong for 1972
Drive belt 8412 (1/2" x 86")
Spindle belt 8411 (1/2" x 76.94")
8393 center blade and 8394 left and right blades replaced by 9819 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1972 36in RD model 5-0611
Mower Rotary 1973 36in RD model 5-0611
1973 serial numbers that have shown up for the 5-0611
0922659 - Model 5-0611-8
Was still available in 1974 according to the price list
100 downloads
Updated
-
Free
Mower Rotary 38in SD 1993 78215 240 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3316-228
4 pages 949KB
1993 Mower drive and spindle belt 79-5980 $35.53 at Toro (1/2" x 81.80")
1994 Mower drive and spindle belt 92-7066 $80.45 at Toro (Aftermarket replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 244-5, 244-H and 246-H
Can be equipped with 86032 recycliner kit
Mower Rotary 38in SD 1993 model 78215 Serial 3900001-3999999
39 downloads
Updated
-
Free
Mower Rotary 38in SD 1994 78215 240 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3316-749
4 pages 109KB
1993 Mower drive and spindle belt 79-5980 $35.53 at Toro (1/2" x 81.80")
1994 Mower drive and spindle belt 92-7066 $80.45 at Toro (Aftermarket replacements listed as 1/2" x 82")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 244-5, 244-H and 246-H
Can be equipped with 86032 recycliner kit
Mower Rotary 38in SD 1994 model 78215 Serial 4900001-4999999
38 downloads
Updated
-
Free
Mower Rotary 38in SD 1995-1996 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3317-276
8 pages 1.9MB
Mower drive and spindle belt 79-5980 (1/2" x 81.80")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 1995 model 78216 Serial 5900001-5999999
Mower Rotary 38in SD 1996 model 78216 Serial 6900001-6999999
42 downloads
Updated
-
Free
Mower Rotary 38in SD 1994 78216 260 IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3316-730
4 pages 871KB
Mower drive and spindle belt 79-5980 (1/2" x 81.80")
Blades
Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
Napa 2 of # 7-06445
Oregon high-lift 2 of # 94-038
Oregon Gator Mulcher 2 of # 94-902
Oregon Gator Mulcher 3in1 2 of # 94-602
Fits 260-Series
Mower Rotary 38in SD 1994 model 78216 Serial 4900001-4999999
62 downloads
Updated
-
Free
Mower Rotary 42in RD 1980-1983 05-42MR01 OM IPL SN.pdf
By admin-(Admin)
Operator manual #810306R1 or 810306 R1
7 pages 1.29MB
IPL #810172R1 or 810172 R1
7 pages 692.32KB
Dated 12/79
Fits C-Series tractors
Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
Spindle belt 106125 (1/2" x 89.03")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1980 42in RD model 05-42MR01
1980 serial numbers that have shown up for the 05-42MR01 (Samples 77 to 196487)
00003479
00003549 - Build date 1979 9274 October 01 Monday
00004358
00004381 - Build date 1980 0087 March 27 Thursday [087]
Mower Rotary 1981 42in RD model 05-42MR01
1981 serial numbers that have shown up for the 05-42MR01 (Samples 175 to 267746)
033664 - Build date 1980 0256 September 12 Friday - Serial looks wrong Build date is clear
034957
035059 - Could be 1983 model
035240 - Build date 1981 1148 May 28 Thursday - Build date looks wrong
Mower Rotary 1982 42in RD model 05-42MR01
1982 serial numbers that have shown up for the 05-42MR01 (Samples 1292 to 39008)
37597 - Build date 1981 1345 December 11 Friday
Mower Rotary 1983 42in RD model 05-42MR01
1983 serial numbers that have shown up for the 05-42MR01 (Samples 2335 to 61160)
484 downloads
Updated
-
Free
Mower Rotary Gauge wheel.pdf
By gwest_ca-(File Mod)
2877 replaced by
5305 replaced by
110506 (PartsTree $23.03 on May 12, 2019) - 6" x 1.75"
Stens replacement 210-013
110506 is an alternate wheel for 6749
6749 (PartsTree $84.92 on May 12, 2019)
59 downloads
Updated
-
Free
Mower Rotary 52in SD 2000-2001 78452 5xie OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #3323-500
28 pages 923KB
Illustrated parts list #3323-799
12 pages 372KB
Fits 5xi tractors - Low cut mower
Drive belt 95-4094 (HB x 96.72" or 5/8" x 96.72")
Spindle belt 102742 replaced by 94-2501 (1/2" x 103") [Napa 6378 (1/2" x 103.25")]
Mower blades 3 of 27-0990 - 18"
Mower Rotary 2000 52in SD model 78452 Serial 200000001-200999999 - Export model
2000 serial numbers that have shown up for the 78452
200000250 - Located in Bavaria
55 downloads
Updated
-
Free
Mower Rotary 42in RD 1998-2001 78442 Low cut 5xi OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3323-497
24 pages 1.00MB
Low cut mower
78442 fits 520xie tractor model 73541
Toro lists the 78442 (Export model) for 1998 only but shows up in the 2001 attachment lists.
1998 Mower Rotary 42" RD model 78442 Serial 8900001-8999999 - Export model
1999 Mower Rotary 42" RD model 78442 Serial 9900001-9999999 - Export model
2000 Mower Rotary 42" RD model 78442 Serial 200000001-200999999 - Export model
2001 Mower Rotary 42" RD model 78442 Serial 210000001-210999999 - Export model
77 downloads
Updated
-
Free
Mower Rotary 44in SD 1998 78444 Low cut 5xi OM IPL.pdf
By gwest_ca-(File Mod)
Operator manual #3322-624
28 pages 956KB
Illustrated parts list #3319-729
16 pages 713KB
Fits 73541 520xie tractors
Drive belt 95-4094 (HB x 96.72" or 5/8" x 96.72")
Spindle belt 95-4228 (HA x 82.04" or 1/2" x 82.04")
Low cut mower blades 3 of 54-0010
1998 44" SD mower model 78444 Serial 8900001-8999999 - Export model
47 downloads
Updated
-
Free
Mower Rotary 42in RD 1998-2001 78353 & 78442 5xi IPL.pdf
By gwest_ca-(File Mod)
IPL #3319-728
12 pages 753.29KB
Drive belt 95-4093 replaced by 105-1491 (HB x 93.98" or 5/8" x 93.98")
Spindle belt 95-4230 (HA x 88.85" or 1/2" x 88.85")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Toro lists the 78353 for 1998 only but shows up in the 2001 attachment lists.
Suspect the 78442 is the same.
78353 fits
518xi models 73470 and 73471 tractors
520xi models 73540 and 73542 tractors
1998 Mower Rotary 42" RD model 78353 Serial 8900001-8999999
1999 Mower Rotary 42" RD model 78353 Serial 9900001-9999999
2000 Mower Rotary 42" RD model 78353 Serial 200000001-200999999
2001 Mower Rotary 42" RD model 78353 Serial 210000001-210999999
78442 fits
520xi tractor model 73570
1998 Mower Rotary 42" RD model 78442 Serial 8900001-8999999 - Export model
1999 Mower Rotary 42" RD model 78442 Serial 9900001-9999999 - Export model
2000 Mower Rotary 42" RD model 78442 Serial 200000001-200999999 - Export model
2001 Mower Rotary 42" RD model 78442 Serial 210000001-210999999 - Export model
109 downloads
Updated
-
Free
Mower Rotary 48in SD 1983 A5-48MS02 C & GT OM TIPL SN.pdf
By admin-(Admin)
Operator manual #810249R2 or 810249 R2
8pages 7.73MB
IPL from Toro Master Parts Viewer
7 pages 389.40KB
Fits GT-1848 Twin Auto
48in SD mower model A5-48MS02 was standard equipment on 1983 GT-1848 Twin Automatic model D1-184801
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 292B
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1983 48in SD model A5-48MS02
1983 serial numbers that have shown up for the A5-48MS02
41873 - Build date 1983 3094 April 04 Monday
42873 - Build date 1983 3094 April 04 Monday
43106 - Build date 1983 3098 April 08 Friday
199 downloads
Updated
-
Free
Mower Rotary 21in 1966-1967 Reo Walking Push 3.5hp LC-2147 D&A sn.pdf
By gwest_ca-(File Mod)
Custom IV
Details only
1 page 39KB
1966 21" walking mower 3.5hp model LC-2147
1967 21" walking mower 3.5hp model LC-2147
35 downloads
Updated
-
Free
Mower Rotary 26in SD 1974 5-0101 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
3 pages 213.86KB
Fits R-26 rear engine rider tractors
Uses 8-6612 grass catcher
There was also a model 5-0100 in 1974 according to the 1974 price list
Mower Rotary 1974 26in SD model 5-0101
53 downloads
Updated
-
Free
Mower Rotary 21in 1986-1987 RD Walking D&A TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
8 pages 602KB
Details only
1 page 39KB
1986 - 1987 21" rear bagger walking mower 3.5hp model 04-35BR01
Details only
1 page 38KB
1986 - 1987 21" rear bagger walking mower 4.0hp model 04-40BR01
30 downloads
Updated
