Manuals for grass gutting

662 files

  1. Free

    Mower Rotary 42in RD 1995-1998 78350 IPL.pdf

    By gwest_ca-(File Mod)

    IPL #3317-340
    8 pages 119.03KB

    Fits 300, 400 and 500-Series tractors

    Drive belt 108834 (1/2" x 98")
    Spindle belt 106125 (1/2" x 89.03")

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1995 42in RD model 78350 Serial 5900001-5999999

    Mower Rotary 1996 42in RD model 78350 Serial 6900001-6999999

    Mower Rotary 1997 42in RD model 78350 Serial 7900001-7999999

    Mower Rotary 1998 42in RD model 78350 Serial 8900001-8999999

    147 downloads

    Updated

  2. Free

    Edger Trimmer 34-30BC01 D TIPL.pdf

    By gwest_ca-(File Mod)

    Details
    Illustrated parts list from Toro Master Parts Viewer
    4 pages 208.68KB

    It is a rebranded McLane - CasualObserver

    1986 Edger/Trimmer model 34-30BC01 using B&S engine
    1987 Edger/Trimmer model 34-30BC01 using B&S engine
    1988 Edger/Trimmer model 34-30BC01 using B&S engine
    1989 Edger/Trimmer model 34-30BC01 using B&S engine

    There was also
    1988 Edger/Trimmer model 34-30BC02 using Kawasaki engine

    7-Blade reel mower also supplied by McLane

    51 downloads

    Updated

  3. Free

    Mower Rotary 36in RD 2000-2006 78305 IPL.pdf

    By gwest_ca-(File Mod)

    IPL #3323-801
    12 pages 104.83KB

    Fits 300-Series and 400-Series tractors
    Fits B-Series and C-Series tractors

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for C-Series tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower Rotary 2000 36in RD model 78305 Serial 200000001-200999999

    Mower Rotary 2001 36in RD model 78305 Serial 210000001-210999999

    Mower Rotary 2002 36in RD model 78305 Serial 220000001-220999999

    Mower Rotary 2003 36in RD model 78305 Serial 230000001-230999999

    Mower Rotary 2004 36in RD model 78305 Serial 240000001-240999999

    Mower Rotary 2005 36in RD model 78305 Serial 250000001-250999999

    Mower Rotary 2006 36in RD model 78305 Serial 260000001-260999999

    152 downloads

    Updated

  4. Free

    Mower Rotary 37in SD 1985 05-37MS05 TIPL SN.pdf

    By gwest_ca-(File Mod)

    IPL from Toro Master Parts Viewer
    6 pages 395.61KB

    Fits 200-Series tractors

    Drive belt 110082 (1/2" x 48.5")
    Spindle belt 108195 (1/2" x 67")

    Mower Rotary 1985 37in SD model 05-37MS05

    1985 serial numbers that have shown up for the 05-37MS05
    53299

    96 downloads

    Updated

  5. Free

    Mower Rotary 42in SD 1994-1997 78345 3-400 IPL.pdf

    By gwest_ca-(File Mod)

    IPL #3316-619RevC or 3316-619 RevC
    8 pages 1.32MB

    Fits 300 and 400-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103") [108834 is wrong in the belt chart for 1996 and 1997]
    Spindle belt 6738 (1/2" x 86") [106125 is wrong in the belt chart for 1996 and 1997]

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1994 42in SD model 78345 Serial 4900001-4999999

    Mower Rotary 1995 42in SD model 78345 Serial 5900001-5999999


    Mower Rotary 1996 42in SD model 78345 Serial 6900001-6999999 -  [Belts wrong in the belt chart for 1996]

    Mower Rotary 1997 42in SD model 78345 Serial 7900001-7999999 -  [Belts wrong in the belt chart for 1997]

    216 downloads

    Updated

  6. Free

    Mower Rotary 32in RD 1964-1965 RM-324 OM IPL SN.pdf

    By admin-(Admin)

    Operator manual #171
    IPL
    3 pages 1.26MB

    Fits all except Lawn Ranger and 1054
    First model to use latches to mount the mower in the frame plates.

    Drive belt 1577 replaced by 7430 (1/2" x 28")
    Spindle belts 1578 (3/8" x 37" matched pair)

    8777 2-blade set replaces 3719, 7760 and 7909 left blades and 3718, 7761 and 7908 right blades

    Mower Rotary 1964 32in RD model RM-324
    1964 serial numbers that have shown up for the RM-324
    010531 - Model and year a guess
    013129 - Model and year a guess

    Mower Rotary 1965 32in RD model RM-324
    1965 serial numbers that have shown up for the RM-324
    122333
    122336

    469 downloads

    Updated

  7. Free

    Mower Rotary 48in SD 1997 78365 3-4-500 Recycler OM IPL SN.pdf

    By gwest_ca-(File Mod)

    Operator manual #3319-371RevA or 3319-371 RevA
    28 pages 811.75KB

    IPL #3319-439
    10 pages 155.58KB

    Fits 300-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 1594 (1/2" x 107.21")

    Mower Rotary 1997 48in SD model 78365 Recycler Serial 7900001-7999999

    1997 serial numbers that have shown up for the 78365
    7900200
    7900265
    7900323

    111 downloads

    Updated

  8. Free

    Mower Rotary 42in SD 1981-1983 05-42MS02 OM TIPL SN.pdf

    By gwest_ca-(File Mod)

    Operator manual #810306R1 or 810306 R1
    7 pages 1.29MB

    Illustrated parts list removed from Work Horse tractor ipl #810286R1
    7 pages 7.8MB

    Illustrated parts list from Toro Master Parts Viewer
    7 pages 388.11KB
    This IPL includes the 48" deck so be careful selecting part numbers.

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Drive belt with front mower carrier and single cylinder engine 109956 (1/2" x 102")
    Drive belt with front mower carrier and twin cylinder engine 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1981 42in SD model 05-42MS02 - fits C-Series and GT-2500 tractors
    1981 serial numbers that have shown up for the 05-42MS02
    036011
    038387 - Build date 1981 11xx
    041637 - Could also be 1982 or 1983
    043140 - Could also be 1982 or 1983

    Mower Rotary 1982 42in SD model 05-42MS02 - fits C-Series, GT-1642 and GT-1848 tractors
    1982 serial numbers that have shown up for the 05-42MS02
    33225 - Build date 1981 x256 September 13 Sunday - Model year a guess
    39008 - Build date 1982 2048 February 17 Wednesday

    Mower Rotary 1983 42in SD model 05-42MS02 - fits C-Series, GT-1142, GT-1642 and GT-1848 tractors
    1983 serial numbers that have shown up for the 05-42MS02
    42472 - Build date 1982 2355 December 21 Tuesday

    511 downloads

    Updated

  9. Free

    Mower Rotary 36in SD 1971 5-0711 OM IPL SN.pdf

    By admin-(Admin)

    Operator manual #A-5122
    IPL
    4 pages 1.13MB
    Dated 7/69 Revised 1/22/71

    This is a 1972 model @ Toro
    Fits 800 models, Raider, Charger, Bronco tractors - long frame 45-1/2" wheel base
    Clockwise spindle rotation

    Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be C, A1, G1 or Z
    For A1 see service bulletin 292B
    For G1 see service bulletin 292B

    100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
    2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.
    101335 blade set available again from Toro June 4, 2019

    Mower Rotary 1971 36in SD model 5-0711

    1971 serial numbers that have shown up for the 5-0711
    791664 - Model 5-0711-6
    813210 - Model 5-0711-6

    113 downloads

    Updated

  10. Free

    Mower Sickle Side 48in Haban 414 OM SM IPL.pdf

    By ChaplainManny

    This is my original Haban 414 Sickle bar mower Operation and Service Manual with repair parts list. I removed it from my GT 14.

    593 downloads

    Updated

  11. Free

    Mower Rotary 36in RD 1983-1984 05-36MR02 OM TIPL sn.pdf

    By admin-(Admin)

    Operator manuals
    7 pages 1.29MB #810306R1 or 810306 R1
    7 pages 450.87KB #810345R1 or 810345 R1

    IPL from Toro Master Parts Viewer
    6 pages 348.78KB

    Fits GT-1100, GT-1600 and C-Series except C-195 Twin tractors
    Fits B-Series tractors

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for C-Series long frame tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assembly H

    107983 3-blade set replaces 107437 left and right blades (12-1/8") and 107438 center blade (14-1/8") (Hole 3/4" round)

    Mower Rotary 1983 36in RD model 05-36MR02

    Mower Rotary 1984 36in RD model 05-36MR02

    181 downloads

    Updated

  12. Free

    Mower Rotary 38in SD 1992 R5-38SL02 Recycler OM IPL sn.pdf

    By gwest_ca-(File Mod)

    Operator manual #3314-786
    9 pages 2.4MB

    IPL
    4 pages 841KB

    Fits model 212-5 and 212-H

    Drive and spindle belt 121330 (1/2" x 79.25")

    Mower Rotary 1992 38in SD Recycler model R5-38SL02 Serial 2000001-2999999

    76 downloads

    Updated

  13. Free

    Mower Reel Gang 1960 GM-60 OM IPL.pdf

    By Lane Ranger

    Operator manual
    Illustrated parts list
    4 pages 522KB including hitch page from November 1959 manual

    Three 21" reels ganged make 60" cut
    Pennsylvania
    American Chain and Cable

    GM-60



    87 downloads

    Updated

  14. Free

    Mower Reel Front 30in 1958-1960 LMR-30 OM IPL sn.pdf

    By admin-(Admin)

    Operator manual #A-7137
    IPL
    4 pages 1.54MB

    Drive belt 1562 (4Lx88" or 1/2" x 88") - Listed on belt sleeve as 1956-1960)
    Drive belt 1570 (4L/A x 69" or 1/2" x 69") - Listed on belt sleeve as late 1960. Possibly referring to the 1961 model 701 with engine at the front.

    Mower Reel 1958 30in Front model LMR-30

    Mower Reel 1959 30in Front model LMR-30

    Mower Reel 1960 30in Front model LMR-30

    223 downloads

    Updated

  15. Free

    Mower Sickle Front 32in 1955 - 1961 OM IPL sn.pdf

    By admin-(Admin)

    Operator manual #A-7137
    IPL
    2 pages 565.98KB
    2 pages 784.23KB
    2 pages 250KB from manual dated November 1959 for 1960 models

    Drive belt 1563 (4L x 39" or 1/2" x 39") - Listed on belt sleeve as 1956-1960

    Mower Sickle 1955 32in Front model CBR-32 - Fits riding tractors

    Mower Sickle 1956 32in Front model CBR-32 - Fits riding tractors

    Mower Sickle 1957 32in Front model CBR-32

    Mower Sickle 1958 32in Front model CBR-32

    Mower Sickle 1959 32in Front model CBR-32

    Mower Sickle 1960 32in Front model CBR-32

    Mower Sickle 1961 32in Front model CBR-32 - Fits all except the 701

    524 downloads

    Updated

  16. Free

    Mower Rotary 32in RD 1965 RM-115 PL SN.pdf

    By admin-(Admin)

    IPL from Toro Master Parts Viewer
    2 pages 202.11KB

    Fits Lawn Ranger

    Mower belt 1555 replaced by 113912 (1/2" x 44")

    8777 2-blade set replaces 3719, 7760 and 7909 left blades and 3718, 7761 and 7908 right blades

    Mower Rotary 1965 32in RD model RM-115

    1965 serial numbers that have shown up for the RM-115
    113404
    113781

    136 downloads

    Updated

  17. Free

    Mower Rotary 36in SD 1970 5-2365 CCW TIPL SN DNA.pdf

    By gwest_ca-(File Mod)

    IPL from Toro Master Parts Viewer
    2 pages 231.68KB

    CCW spindle rotation with left side discharge
    Fits Commando V7, Charger V7, Commando V8 and Charger V8 tractors

    Drive belt 8412 (1/2" x 86")
    Spindle belt 8411 (1/2" x 76.94")

    100460 center blade and 100459 left and right blades replaced by 101093 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)

    Mower Rotary 1970 36in SD model 5-2365 CCW

    1970 serial numbers that have shown up for the 5-2365
    708941
    728558
    728660

    36in side discharge decks with CCW rotation blades DNA
    1970 side discharge model 5-2365
    1971 side discharge model 5-0700
    1972 side discharge model 5-0701
    1973 side discharge model 5-0702

    108 downloads

    Updated

  18. Free

    Mower Rotary 48in SD 2006 79310 5xi Vacuum bagger OM IPL sn.pdf

    By gwest_ca-(File Mod)

    Operator manual #3323-317
    24 pages 871KB

    IPL #3353-405
    12 pages 150KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    2006 11 cu. ft. 48in vac bagger model 79310 Serial 260000001-260999999

    41 downloads

    Updated

  19. Free

    Mower Rotary 48in SD 2003-2004 79310 5xi Vacuum bagger OM IPL sn.pdf

    By gwest_ca-(File Mod)

    Operator manual #3323-317
    24 pages 871KB

    IPL #3324-731
    8 pages 164KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    2003 11 cu. ft. 48in vac bagger model 79310 Serial 230000001-230999999
    2004 11 cu. ft. 48in vac bagger model 79310 Serial 240000001-240999999

    44 downloads

    Updated

  20. Free

    Mower Rotary 48in SD 2001 79310 5xi Vacuum bagger OM IPL sn.pdf

    By gwest_ca-(File Mod)

    Operator manual #3323-317
    24 pages 871KB

    IPL #3324-731
    8 pages 164KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    2001 11 cu. ft. 48in vac bagger model 79310 Serial 210000001-210999999

    22 downloads

    Updated

  21. Free

    Mower Rotary 48in SD 1999 79310 5xi Vacuum bagger OM IPL sn.pdf

    By gwest_ca-(File Mod)

    Operator manual #3323-317
    24 pages 871KB

    IPL #3319-734
    12 pages 225KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    1999 11 cu. ft. 48in vac bagger model 79310 Serial 9900001-9999999

    35 downloads

    Updated

  22. Free

    Mower Rotary 48in SD 1998 79310 5xi Vacuum bagger OM IPL sn.pdf

    By gwest_ca-(File Mod)

    Operator manual #3319-580
    28 pages 4MB

    IPL #3319-734
    12 pages 225KB

    Fits 5xi tractors

    Drive belt 79-7490 (HA x 73.75" or 1/2" x 73.75")

    1998 11 cu. ft. 48in vac bagger model 79310 Serial 8900001-8999999


    56 downloads

    Updated

  23. Free

    Mower Vacuum Quiet collector 5xi 1998-1999 2002-2004 52in Drive Kit 79452 OM IPL.pdf

    By gwest_ca-(File Mod)

    Operator manual #3321-485GB for years 1998, 1999, 2002
    12 pages 265KB

    Operator manual #3329-499 for years 2003, 2004
    8 pages 197KB

    Illustrated parts list #3321-486
    1 page 41KB

    For use with 52" side discharge mower deck model 78370

    Drive belt 98-3674 (A x 100.1" or 1/2" x 100.1")

    1998 Drive Kit 14.0 cu. ft. Quiet Collector Vac Bagger 52" model 79452 Serial 8900001-8999999
    1999 Drive Kit 14.0 cu. ft. Quiet Collector Vac Bagger 52" model 79452 Serial 9900001-9999999
    2002 Drive Kit 14.0 cu. ft. Quiet Collector Vac Bagger 52" model 79452 Serial 220000001-220999999
    2003 Drive Kit 14.0 cu. ft. Quiet Collector Vac Bagger 52" model 79452 Serial 230000001-230999999
    2004 Drive Kit 14.0 cu. ft. Quiet Collector Vac Bagger 52" model 79452 Serial 240000001-240999999

    54 downloads

    Updated

  24. Free

    Mower Rotary 48in SD 1964 RM-484 OM IPL SN.pdf

    By admin-(Admin)

    Operator manual
    IPL
    8 pages 2.22MB - #182
    5 pages 2.32MB - #A-7137

    Fits 953, 1054 and 1054A tractors

    Drive belt 1595 (1/2" x 66.95")
    Spindle belt 1594 (1/2" x 107.21")

    Mower spindle assemblies could be Q, P, V, Y or Z
    For P see service bulletin 221B
    For V and Y see service bulletin 292B

    4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)

    Mower Rotary 1964 48in SD model RM-484

    1964 serial numbers that have shown up for the RM-484
    A-69485
    A-69613

    222 downloads

    Updated

  25. Free

    Mower Rotary 48in SD 1985 05-48MS04 3-400 IPL SN.pdf

    By gwest_ca-(File Mod)

    IPL #810388R1 or 810388 R1
    7 pages 3.72MB

    Fits 300-Series and 400-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 1594 (1/2" x 107.21")

    Uses Z spindle assembly

    106078 blade replaced by 106637 3-blade set (3/4" round hole)

    Mower Rotary 1985 48in SD model 05-48MS04

    1985 serial numbers that have shown up for the 05-48MS04
    52646
    52843
    53895

    171 downloads

    Updated

Sign in to follow this
Followers 0


×
×
  • Create New...
