Manuals for grass gutting

659 files

  1. Free

    Mower Rotary 60in SD 1978 85-60XS01 D-10spd OM.pdf

    Owners manual  #803713R1
    4 pages 1.9MB

    Fits D-250 10-Speed

    Mower Rotary 60in SD 1978 model 85-60XS01

    46 downloads

    Updated

  2. Free

    Mower Rotary 36in RD 1995-1996 78305 OM SN.pdf

    Operator manual #3316-956
    8 pages 1.49MB
    Setup

    Fits 300-Series and 400-Series tractors
    Shipping weight 107 lbs.

    Mower Rotary 1995 36in RD model 78305 Serial 5900001-5999999

    Mower Rotary 1996 36in RD model 78305 Serial 6900001-6999999
    1996 serial numbers that have shown up for the 78305
    6900184

    79 downloads

    Updated

  3. Free

    Mower Rotary 42in SD 1975 5-1011 OM TIPL SN.pdf

    Operator manual #803975  Dated 7-74
    5 pages 1.73MB

    IPL from Toro Master Parts Viewer
    3 pages 219.39KB
    Shared with 48" deck so be careful selecting parts

    Fits C-Series tractors
    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be K, V, X or Z
    For V and X see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1975 42in SD model 5-1011

    1975 serial numbers that have shown up for the 5-1011
    091307
    099545

    348 downloads

    Updated

  4. Free

    Mower Rotary 36in RD 1979 95-36YR02 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    6 pages 420.62KB

    Fits A-81 5-Speed and A-111 5-Speed tractors

    Drive belt 107230 (1/2" x 60.1")
    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be D, A1, G2 or Z
    For A1 and G2 see service bulletin 292B

    107982 3-blade set replaces 107435 left and right blades (12-1/8") and 107436 center blade (14-1/8") (Hole 3/4" round)

    Mower Rotary 1979 36in RD model 95-36YR02

    66 downloads

    Updated

  5. Free

    Mower Rotary 36in RD 1979 95-36YR01 95-36YR02 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    6 pages 420.62KB

    Fits A-81 5-Speed and A-111 5-Speed tractors

    Drive belt 107230 (1/2" x 60.1")
    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be D, A1, G2 or Z
    For A1 and G2 see service bulletin 292B

    9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)

    Mower Rotary 1979 36in RD model 95-36YR01
    --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

    IPL from Toro Master Parts Viewer
    6 pages 328KB

    Shows blades with different center holes

    Mower Rotary 1979 36in RD model 95-36YR02

    48 downloads

    Updated

  6. Free

    Mower Rotary 36in RD 1980-1984 05-36YR01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    7 pages 400.46KB

    Fits A-81, A-111 and RR-832 tractors

    Drive belt 108492 (1/2" x 57.5")
    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be E, A1, F or Z
    For A1 see service bulletin 292B

    One of these may be incorrect. Napa replaces both with the same blades.
    107982 3-blade set replaces 107435 left and right blades (12-1/8") and 107436 center blade (14-1/8") (Hole 3/4" round) [Used 1980-81 in blade chart]
    107983 3-blade set replaces 107437 left and right blades (12-1/8") and 107438 center blade (14-1/8") (Hole 3/4" round) [Used 1983 in blade chart]

    Mower Rotary 1980 36in RD model 05-36YR01
    1980 serial numbers that have shown up for the 05-36YR01
    00024250 - Build date 1980 0094 April 03 Thursday

    Mower Rotary 1981 36in RD model 05-36YR01

    Mower Rotary 1982 36in RD model 05-36YR01

    Mower Rotary 1983 36in RD model 05-36YR01

    Mower Rotary 1984 36in RD model 05-36YR01

    49 downloads

    Updated

  7. Free

    Mower Rotary 52in SD 1998 78370 & 78375 5xi OM IPL sn.pdf

    Operator manual #3319-811
    24 pages 1MB

    Illustrated parts list #3319-731
    16 pages 720KB

    Fits 5xi tractors

    Drive belt 95-4094 (HB x 96.72" or 5/8" x 96.72")
    Spindle belt 102742 replaced by 94-2501 (1/2" x 103")

    78370 mower blades 3 of 27-0990 - 18"
    78375 mower blades 3 of 92-7961 - 18" - Recycler

    Mower Rotary 1998 52in SD model 78370 Serial 8900001-8999999
    1998 serial numbers that have shown up for the 78370
    8901007

    Mower Rotary 1998 52in SD model 78375 Serial 8900001-8999999 - Recycler

    48 downloads

    Updated

  8. Free

    Mower Rotary 36in RD 1972 5-0620 CW TIPL DNA SN.pdf

    IPL from Toro Master Parts Viewer
    4 pages 326.42KB

    Fits Commando 800
    Clockwise spindle rotation

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed models 1-0120 and 1-0130
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be C, A1, G2 or Z
    For A1 see service bulletin 292B
    For G2 see service bulletin 292B

    9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    8969 blade set available again from Toro June 4, 2019

    Mower Rotary 1972 36in RD model 5-0620

    1972 serial numbers that have shown up for the 5-0620
    879478 - Model 5-0620-7

    Mower DNA
    1972 model 5-0620 replaced by
    1973-1974 model 5-0621
    1975 model 5-0622
    1976 model 65-36XR01
    1977 model 75-36XR01
    1977 model 75-36XR02
    1978 model 85-36MR01
    1979 model 95-36MR00 (Blades up to this point have the 5/8" x 3/4" double-D center hole unless the spindle has been upgraded)
    ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------
    (These decks used blades with a 3/4" center hole)
    1979 model 95-36MR01 replaced by
    1980-1982 model 05-36MR01 - Last year for bearings with 3/4" ID
    1983-84 model 05-36MR02 - First year for bearings with 17mm ID unless older spindles were updated.
    1985 model 05-36MR03
    1986-1990 model 05-36MR04
    1991-1993 model 05-36MR05
    1993-2006 model 78305

    Note - 17mm is .669"

    175 downloads

    Updated

  9. Free

    Mower Rotary 42in RD 1979 95-42MR02 IPL SN.pdf

    IPL #810121R1 or 810121 R1
    7 pages 367.42KB
    Dated 10/78

    Fits C-Series tractors
    Operator manual listed @ Toro is #810129R1

    Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
    Spindle belt 106125 (1/2" x 89.03")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1979 42in RD model 95-42MR02

    1979 serial numbers that have shown up for the 95-42MR02
    018514
    018998 - Build date 1979 9057 February 26, Monday
    031203
    031221 - Build date 1979 9097 April 07 Saturday
    032419 - Build date 1979 9123 May 03 Thursday
    036261 - Build date 1979 9129 May 09 Wednesday
    037812 - Build date 1979 9177 June 26 Tuesday

    240 downloads

    Updated

  10. Free

    Mower Rotary 52in SD 1999 78370 5xi OM IPL SN.pdf

    Operator manual #3322-393
    28 pages 922KB

    Illustrated parts list #3323-184
    12 pages 596KB

    Fits 5xi tractors

    Drive belt 95-4094 (HB x 96.72" or 5/8" x 96.72")
    Spindle belt 102742 replaced by 94-2501 (1/2" x 103")

    Mower blades 3 of 27-0990 - 18"

    Mower Rotary 1999 52in SD model 78370 Serial 9900001-9999999
    1999 serial numbers that have shown up for the 78370
    9900179
    9900312
    9900613

    48 downloads

    Updated

  11. Free

    Mower Rotary 42in SD 1990 15-42SC02 OM TIPL SN.pdf

    Operator manual #810657R1 or 810657 R1
    8 pages 2.40MB
    Dated 08/89

    IPL from Toro Master Parts Viewer
    This ipl is shared with 48" deck so be careful selecting parts
    6 pages 407.99KB

    Fits 300, 400 and 500-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Front idler assembly mule
    1/2" long spacer part number 101757 is on the outside between the pulley and cover.
    5/8" long spacer part number 101734 is between the pulleys.
    Spacer ID needs to slip over 3/4" shaft.

    Mower Rotary 1990 42in SD model 15-42SC02

    1990 serial numbers that have shown up for the 15-42SC02
    0021465
    0021654
    0021746 - Build date 1989 9304 October 31 Tuesday
    0022350 - Build date 1989 9331 November 27 Monday
    0023217
    0024827 - Build date 1990 0057 February 26 Monday
    0024942
    0026020 - Build date 1990 0082 March 23 Friday [0982]
    0026172 - Build date 1990 0095 April 05 Thursday
    0027766

    381 downloads

    Updated

  12. Free

    Mower Rotary 36in SD 1972 5-0720 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    2 pages 202.82KB

    Fits Commando 800
    Clockwise spindle rotation

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for C-Series tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
    2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.
    101335 blade set available again from Toro June 4, 2019

    Mower Rotary 1972 36in SD model 5-0720

    1972 serial numbers that have shown up for the 5-0720
    064323
    893483 - Model 5-0720-7
    869224 - Model 5-0720-7
    869612 - Model 5-0720-7
    877155 - Model 5-0720-7

    91 downloads

    Updated

  13. Free

    Mower Rotary 36in SD 1976 65-36MS01 OM IPL SN.pdf

    Operator manual #803451R2 or 803451 R2
    5 pages 3.08MB

    Operator manual #803463
    IPL
    8 pages 2.61MB

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for B-Series and C-Series long frame tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be D, A1, G1 or Z
    For A1 and G1 see service bulletin 292B

    100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
    101335 blade set available again from Toro June 4, 2019

    2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.



    Mower Rotary 1976 36in SD model 65-36MS01

    1976 serial numbers that have shown up for the 65-36MS01
    04398 - Build date 1975 5310 November 06 Thursday [6310 looks wrong]
    23141 - Build date 1976 6138 May 17 Monday
    25849

    211 downloads

    Updated

  14. Free

    Mower Rotary 60in SD 1997-1998 78390 500 OM SN.pdf

    Operator manual #3318-950
    24 pages 1.89MB

    Fits 520-Series tractors with forward swept front axle

    Mower Rotary 1997 60in SD model 78390 Serial 7900001-7999999
    1997 serial numbers that have shown up for the 78390
    7900227
    7900254

    Mower Rotary 1998 60in SD model 78390 Serial 8900001-8999999

    259 downloads

    Updated

  15. Free

    Mower Rotary 42in RD 1990-1992 15-42RC02 IPL #3314-878.pdf

    IPL
    8 pages 1.09MB
    Operator manual dated 08/89 so should be 1990 also (1991 and 1992 @ Toro)

    Fits 300, 400 and 500-Series tractors

    Drive belt 108834 (1/2" x 98")
    Spindle belt 106125 (1/2" x 89.03")

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1990 42in RD model 15-42RC02
    Mower Rotary 1991 42in RD model 15-42RC02 Serial 1000001-1099999
    Mower Rotary 1992 42in RD model 15-42RC02 Serial 2000001-2099999

    387 downloads

    Updated

  16. Free

    Mower Rotary 42in SD 1975 5-1012 OM TIPL sn.pdf

    Operator manual #803881 is listed by Toro for 5-1012 - 7 pages 542.54KB
    Operator manual #803975 Dated 7-74 may be a better choice - 5 pages 1.73MB

    IPL from Toro Master Parts Viewer
    3 pages 262.28KB
    Shared with 48" deck so be careful selecting parts

    Fits C-Series tractors

    Drive belt 102742 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be J, N, U, V, X or Z
    For N and U see service bulletin 221B
    For X and V see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1975 42in SD model 5-1012

    127 downloads

    Updated

  17. Free

    Mower Rotary 42in SD 1971-1972 5-1001 OM IPL SN.pdf

    Operator manual
    IPL
    10 pages 1.15MB
    Dated 7-69 and Rev3/71

    Includes Includes PSB's #120 #221B
    Fits Raider, Charger and Electro long frame models
    Listed as 1972 only at Toro

    Drive belt 9782 (1/2" x 69")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be J, N, U, V, X or Z
    For N and U see service bulletin 221B
    For X and V see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1971 42in SD model 5-1001
    1971 serial numbers that have shown up for the 5-1001
    827110 - Model 5-1001-6

    Mower Rotary 1972 42in SD model 5-1001
    1972 serial numbers that have shown up for the 5-1001
    861057 - Model 5-1001-7
    876359

    389 downloads

    Updated

  18. Free

    Mower Rotary 42in SD 1976 65-42MS01 OM TIPL SN.pdf

    Operator manual #803451R2 or 803451 R2
    4 pages 3.52MB

    IPL from Toro Master Parts Viewer
    3 pages 201.74KB
    Shared with 48" deck so be careful selecting parts

    Fits C-Series tractors

    Drive belt 102742 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be K, V, X or Z
    For V and X see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1976 42in SD model 65-42MS01

    1976 serial numbers that have shown up for the 65-42MS01
    020599
    020828 - Build date 1976 6174 June 22 Tuesday - Looks wrong
    020987 - Build date 1976 6173 June 21 Monday - Looks wrong

    211 downloads

    Updated

  19. Free

    Mower Rotary 42in SD 1971 5-1000 OM IPL sn.pdf

    Operator manual
    IPL
    10 pages 1.15MB
    Dated 7-69 and Rev3/71

    Includes Includes PSB's #120 #221B
    Fits Raider, Charger and Electro long frame models

    Mower spindle assemblies could be J, N, U, V, X or Z
    For N and U see service bulletin 221B
    For X and V see service bulletin 207B

    Drive belt 9782 (1/2" x 69") [9783 in belt chart is wrong]
    Spindle belt 6738 (1/2" x 86")

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1971 42in SD model 5-1000

    93 downloads

    Updated

  20. Free

    Mower Rotary 42in SD 1968 5-1421 OM IPL SN.pdf

    Operator manual #A-5252
    IPL
    10 pages 1.75MB
    Dated 5/1/67

    Includes PSB's #094 #097 #221B
    5-1421 42" Side discharge mower deck. Commonly used on mid-late 60s models using 10 or 12 Hp.
    Fits Raider, Charger and Electro long frame models

    Drive belt 7041 (1/2" x 72")
    Spindle belt 6738 (1/2" X 86")

    Mower spindle assemblies could be J, N, U, V, X or Z
    For N and U see service bulletin 221B
    For X and V see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1968 42in SD model 5-1421

    1968 serial numbers that have shown up for the 5-1421
    406134
    406214
    418777
    430023
    460100
    465646

    386 downloads

    Updated

  21. Free

    Mower Rotary 42in SD 1977 75-42MS01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    6 pages 333.10KB
    Shared with 48" deck so be careful selecting parts

    Fits C-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be K, V, X or Z
    For V and X see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D) Last 42" side discharge deck to use blades with 5/8" x 3/4" double-D center hole unless the spindles have been upgraded
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1977 42in SD model 75-42MS01

    1977 serial numbers that have shown up for the 75-42MS01
    006174
    012852 - Build date 1977 7014 January 14 Friday
    157493 - Could be a 75-42MS02 - Possibly made in Belgium - Located in Sweden

    172 downloads

    Updated

  22. Free

    Mower Rotary 42in SD 1966-1967 RL-426 OM IPL DNA SN.pdf

    Operator manual #298
    IPL
    9 pages 1.37MB
    Dated 10/08/65

    Includes PSB's #075 #094 #221B
    Fits 10hp and 12hp tractors
    Requires 8-5211 85211 speed hitch

    Drive belt 9782 (1/2" x 69")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be J, N, U, V, X or Z
    For N and U see service bulletin 221B
    For X and V see service bulletin 207B

    6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    Stens replacement - 3 of 350-041 still available March 6, 2021

    Mower Rotary 1966 42in SD model RL-426
    1966 serial numbers that have shown up for the RL-426
    186226
    186334
    229709
    246612
    285776

    Mower Rotary 1967 42in SD model RL-426
    1967 serial numbers that have shown up for the RL-426
    349931

    Mower DNA
    1966-1967 model RL-426 replaced by
    1968 model 5-1421
    1969 model 5-1422
    1970 model 5-1423
    1971 model 5-1000
    1971-1972 model 5-1001
    1973-1974 model 5-1010
    1975 model 5-1011
    1975 model 5-1012
    1976 model 65-42MS01 - Online Toro parts illustration is the 48" SD deck
    1976 model 65-42MS02 - Online Toro parts illustration is the 48" SD deck
    1977 model 75-42MS01 - These 42" side discharge decks all use blades with 5/8" x 3/4" double-D center hole unless the spindles have been upgraded (Do not have operator manual)
    --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
    These decks all use blades with a 3/4" center hole.
    1977 model 75-42MS02 replaced by (Do not have operator manual)
    1978 model 85-42MS01 (Do not have operator manual)
    1979 model 95-42MS00 (Do not have operator manual)
    1979 model 95-42MS01 (Do not have operator manual)
    1980 model 05-42MS01 (Have operator manual)
    1981-1983 model 05-42MS02
    1984 model 05-42MS03 - Last year for bearings with 3/4" ID
    1985 model 05-42MS04 - First year for bearings with 17mm ID unless older spindles were updated.
    1986-1988 model 05-42MS05
    1989 model 15-42SC01
    1990 model 15-42SC02
    1990-1992 model 15-42SC03
    1993-2007 and 2009-2012 model 78345 - These decks all use blades with a 3/4" center hole.

    Note - 17mm is .669"

    381 downloads

    Updated

  23. Free

    Mower Rotary 42in SD 1977 75-42MS02 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    7 pages 331.82KB
    Shared with 48" deck so be careful selecting parts

    Fits C-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1977 42in SD model 75-42MS02
    1975 serial numbers that have shown up for the 75-42MS02
    157493 - Could be a 75-42MS01 - Possibly made in Belgium - Located in Sweden

    89 downloads

    Updated

  24. Free

    Mower Rotary 48in SD 1998 78363 5xi OM IPL SN.pdf

    Operator manual #3319-585
    24 pages 904.23KB

    IPL #3319-730
    16 pages 362.86KB

    Fits 5xi tractors

    Drive belt 95-4095 (HB x 97.54" or 5/8" x 97.54") - Used with adjustment knob on the front of the idler assembly
    Spindle belt 95-3878 (HA x 102.44" or 1/2" x 102.44")

    106078 blade replaced by 106637 3-blade set (3/4" round hole)

    Mower Rotary 1998 48in SD model 78363 Serial 8900001-8999999

    1998 serial numbers that have shown up for the 78363
    8900333
    8901581
    8901838
    8902032
    8902081
    8902248
    8902958

    113 downloads

    Updated

  25. Free

    Mower Rotary 36in RD 1969 5-7365 CW OM IPL sn.pdf

    Operator manual #A-5122
    IPL
    4 pages 539.46KB
    Dated 7/69 Revised 11/9/70

    CW rotation
    Fits 10hp 12hp tractors
    Listed in 1974 price list as a 1973 attachment for 1969 long frame tractors but there was a 5-7366 in 1970.

    Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assemblies could be B, A1, G2 or Z
    For A1 see service bulletin 292B
    For G2 see service bulletin 292B

    9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
    (101093 3-blade kit in blade chart is not correct)
    8969 blade set available again from Toro June 4, 2019 - Still available January 23, 2021

    Mower Rotary 1969 36in RD model 5-7365

    184 downloads

    Updated

Sign in to follow this



×
×
  • Create New...
