Manuals for grass gutting

659 files

  1. Free

    Mower Rotary 32in RD 1969-1973 5-3322 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    1 page 140.88KB

    Fits 1968 and older Lawn Rangers
    Suspect this was a replacement shaft driven deck for the horizontal shaft engine models
    Listed in 1974 price list
    5-3322 is listed as a 1968 model @ Toro

    Mower belt 1555 replaced by 113912 (HAx44 or 1/2" x 44")

    8777 2-blade set replaces 3719, 7760 and 7909 left blades and 3718, 7761 and 7908 right blades

    Mower Rotary 1968 32in RD model 5-3322

    Mower Rotary 1969 32in RD model 5-3322
    1969 serial numbers that have shown up for the 5-3322
    416528 - Model year a guess
    424578 - Model year a guess
    453353 - Model year a guess
    505037 - Model year a guess

    Mower Rotary 1970 32in RD model 5-3322

    Mower Rotary 1971 32in RD model 5-3322

    Mower Rotary 1972 32in RD model 5-3322

    Mower Rotary 1973 32in RD model 5-3322

    Mower Rotary 1974 32in RD model 5-3322

    70 downloads

    Updated

  2. Free

    Mower Rotary 48in SD 1979 95-48MS00 C TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    7 pages 354.52KB
    Found this IPL with 1978 model

    Fits C-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 1594 (1/2" x 107.21")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 292B

    106078 blade replaced by 106637 3-blade set (3/4" round hole)

    Mower Rotary 1979 48in SD model 95-48MS00

    1979 serial numbers that have shown up for the 95-48MS00
    013706 - Build date 1978 8306 November 02 Thursday
    024004 - Build date 1979 9010 January 10 Wednesday

    98 downloads

    Updated

  3. Free

    Mower Sickle Side 50in 1968 7-1311 OM IPL SN.pdf

    Operator manual #375
    IPL
    4 pages 283.96KB

    Fits long frame tractors

    Engine drive belt 6573 - 4L x 38" or 1/2" x 38"
    Mower drive belt 1588 - A x 59" or 1/2" x 59"

    Mower Sickle 1968 50in Side model 7-1311

    1968 serial numbers that have shown up for the 7-1311
    408030
    413557
    413568
    556513
    556578
    560746
    573616
    573656

    318 downloads

    Updated

  4. Free

    Mower Sickle Side 46in and 58in Didier Sickle-Hydra 1 OM IPL.pdf

    Operator manual
    Illustrated parts list
    9 pages 5.1MB

    The Didier Hydra-Sickle for Wheel Horse hydraulic garden tractors.   Didier Manufacturing Company of Racine, Wisconsin .   Publication from September 1973 (9/73)

    464 downloads

    Updated

  5. Free

    Mower Sickle Side 46in and 58in Didier Sickle-Hydra 2 OM IPL.pdf

    Operator manual
    Illustrated parts list
    10 pages 2.02MB
    Form 2008 Dated October 1973

    Mower Sickle 1973 46in Side model
    Mower Sickle 1973 58in Side model

    431 downloads

    Updated

  6. Free

    Mower Rotary 42in RD 1988-1989 05-42RK01 OM TIPL sn.pdf

    Operator manual #810552R1
    9 pages 5.3MB

    IPL from Toro Master Parts Viewer
    7 pages

    Fits 252-H and 257-H tractors

    Drive belt 113912 (1/2" x 44")
    Spindle belt 106516 (1/2" x 83")

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1988 42in RD model 05-42RK01
    80065 - Model year a guess

    Mower Rotary 1989 42in RD model 05-42RK01

    206 downloads

    Updated

  7. Free

    Mower Rotary 42in RD 1993-1994 78355 Recycler OM SN.pdf

    Operator manual #3315-400
    12 pages 1.93MB
    Setup
    1 page 56.02KB
    Fits 300, 400 and 500-Series tractors

    Mower Rotary 1993 42in RD model 78355 Recycler Serial 3900001-3999999
    1993 serial numbers that have shown up for the 78355
    3900430
    3900505

    Mower Rotary 1994 42in RD model 78355 Recycler Serial 4900001-4999999

    107 downloads

    Updated

  8. Free

    Mower Vacuum Lawn 42in 1980-1984 07-42VC01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    9 pages 640.72KB

    Fits C-Series tractors
    Requires 5 cu. ft. dump cart
    See PSB #296A Eaton hydro requires smaller fan # 108515

    Blower belt 1574 replaced by 517439 (A x 33.10" or 1/2" x 33.1")
    Pto belt for single cylinder models 107662 (1/2" x 116")
    Pto belt for twin cylinder models require 107813 belt (1/2" x 118")

    Model numbers found in the attachment list for the 1988 312-8e model E1-12K801 - Export model
    May be similar and supplied by a European manufacturer
    07-42VB91 - requires 42" SD deck
    17-42VB91- requires 42" SD deck

    Mower Rotary 1980 42in SD model 07-42VC01 Vacuum
    1980 serial numbers that have shown up for the 07-42VC01
    03656 - Could be 1981 or 1982
    03740 - Could be 1981 or 1982
    03758 - Could be 1981 or 1982

    Mower Rotary 1981 42in SD model 07-42VC01 Vacuum
    1981 serial numbers that have shown up for the 07-42VC01
    03656 - Could be 1980 or 1982
    03740 - Could be 1980 or 1982
    03758 - Could be 1980 or 1982

    Mower Rotary 1982 42in SD model 07-42VC01 Vacuum
    1982 serial numbers that have shown up for the 07-42VC01
    03656 - Could be 1980 or 1981
    03740 - Could be 1980 or 1981
    03758 - Could be 1980 or 1981

    Mower Rotary 1983 42in SD model 07-42VC01 Vacuum 20 bushel

    Mower Rotary 1984 42in SD model 07-42VC01 Vacuum 20 bushel

    80 downloads

    Updated

  9. Free

    Mower Rotary 38in SD 1991 05-38SL01 OM IPL SN.pdf

    Operator manual #810712R1 or 810712 R1
    8 pages 2.70MB

    IPL #3314-928
    2 pages 509.71KB

    Fits 200-Series tractors

    Drive and spindle belt 121330 (1/2" x 79.25")

    Mower blades
    Toro 2 of 57-4700 replaced by 57-4700-03 - 5/8" hole 19-5/16" long
    Napa 2 of # 7-06445
    Oregon high-lift 2 of # 94-038
    Oregon Gator Mulcher 2 of # 94-902
    Oregon Gator Mulcher 3in1 2 of # 94-602

    Mower Rotary 1991 38in SD model 05-38SL01 Serial 1000001-1999999

    1991 serial numbers that have shown up for the 05-38SL01
    1052983
    1053328

    57 downloads

    Updated

  10. Free

    Mower Rotary 42in SD 1984 05-42MS03 C OM TIPL SN.pdf

    Operator manual #810345R1 or 810345 R1
    7 pages 450.87KB

    IPL from Toro Master Parts Viewer
    6 pages 40953KB

    Fits C-Series except C-195 and GT-1600 Twin tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Drive belt with front mower carrier and single cylinder engine 109956 (1/2" x 102")
    Drive belt with front mower carrier and twin cylinder engine 102742 replaced by 94-2501 (1/2" x 103")

    Spindle belt 6738 (1/2" x 86")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106077 replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1984 42in SD model 05-42MS03

    1984 serial numbers that have shown up for the 05-42MS03
    49173
    49521

    204 downloads

    Updated

  11. Free

    Mower Rotary 42in RD 1982-1983 05-42XR02 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    7 pages 420.05KB

    Fits B-Series tractors

    Drive belt 106523 replaced by 110141 (1/2" x 41")
    Spindle belt 106516 (1/2" x 83")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1982 42in RD model 05-42XR02
    1982 serial numbers that have shown up for the 05-42XR02
    37099 - Build date 1981 1295 October 22 Thursday [295] Guess this should be 1295?
    37356 - Build date 1981 1314 November 10 Tuesday
    38069 - Build date 1981 1345 December 11 Friday [1-345]

    Mower Rotary 1983 42in RD model 05-42XR02

    76 downloads

    Updated

  12. Free

    Mower Rotary 48in SD 1969 5-1482 OM IPL SN.pdf

    Operator manual
    Illustrated parts list
    6 pages 1.2MB

    Fits 10hp 12hp long frame tractors
    5-1482 fits 1969 GT-14 and followed by 1970 model 5-0481, 1971 model 5-1200, 1972 model 5-1201 and 1972-73 model 5-1202 These decks all use blades with 5/8" x 3/4" double-D center hole unless the spindles have been upgraded.

    Drive belt 6771 replaced by 9783 (1/2" x 71")
    Spindle belt 1594 (1/2" x 107.21")

    Mower spindle assemblies could be J, N, U, V, Y or Z
    For N and U see service bulletin 221B
    For V and Y see service bulletin 292B

    4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)

    Mower Rotary 1969 48in SD model 5-1482

    1969 serial numbers that have shown up for the 5-1482
    554519
    554637
    565589

    569 downloads

    Updated

  13. Free

    Mower Rotary 37in SD 1997-1998 78315 OM SN.pdf

    Operator manual #3318-946RevA or 3318-946 RevA
    24 pages 1.87MB

    Fits 300-Series tractors

    Mower Rotary 1997 37in SD model 78315 Serial 7900001-7999999
    1997 serial numbers that have shown up for the 78315
    7900103

    Mower Rotary 1998 37in SD model 78315 Serial 8900001-8999999
    1998 serial numbers that have shown up for the 78315
    8900285

    83 downloads

    Updated

  14. Free

    Mower Rotary 42in SD 1990-1992 15-42SC03 OM IPL SN.pdf

    Operator manual #810735R1 or 810735 R1
    8 pages 2.48MB
    Dated 08/89 so should be 1990 also (1991 and 1992 @ Toro)

    IPL #3314-842
    8 pages 1.25MB

    Fits 300 and 400-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103")
    Spindle belt 6738 (1/2" x 86")

    106077 blade replaced by 106636 3-blade set (3/4" round hole)

    Mower Rotary 1990 42in SD model 15-42SC03

    Mower Rotary 1991 42in SD model 15-42SC03 Serial 1000001-1999999
    1991 serial numbers that have shown up for the 15-42SC03
    1050621

    Mower Rotary 1992 42in SD model 15-42SC03 Serial 2000001-2999999
    1992 serial numbers that have shown up for the 15-42SC03
    2000092
    2000304

    731 downloads

    Updated

  15. Free

    Mower Rotary 42in RD 1980-1981 05-42XR01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    8 pages 418.14KB

    Fits B-Series tractors

    Drive belt 106523 replaced by 110141 (1/2" x 41")
    Spindle belt 106516 (1/2" x 83")

    Mower spindle assemblies could be L, M, V or Z
    For V see service bulletin 207B

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 1980 42in RD model 05-42XR01
    1980 serial numbers that have shown up for the 05-42XR01
    00011864 - Build date 1979 9351 December 17 Monday
    00012146 - Build date 1979 9353 December 19 Wednesday

    Mower Rotary 1981 42in RD model 05-42XR01

    81 downloads

    Updated

  16. Free

    Mower Rotary 36in RD 1968 5-2361 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    2 pages 169.99KB

    Fits short frame tractors up to 8hp

    Drive belt 1577 replaced by 7430 (1/2" x 28") [1587 in belt chart is wrong]
    Spindle belts 1578 (3/8" x 37" matched pair)

    8014 2-blade set replaces 4116 and 7906 right blades, 4117 and 7907 left blades and 2-blade set 101522

    Mower Rotary 1968 36in RD model 5-2361

    1968 serial numbers that have shown up for the 5-2361
    399297
    399373

    131 downloads

    Updated

  17. Free

    Mower Rotary 42in RD 2000-2014 78350 IPL.pdf

    IPL #3323-802
    8 pages 121.58KB

    Fits 300, 400 and 500-Series tractors

    Drive belt 108834 (1/2" x 98")
    Spindle belt 106125 (1/2" x 89.03")

    106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)

    Mower Rotary 2000 42in RD model 78350 Serial 200000001-200999999

    Mower Rotary 2001 42in RD model 78350 Serial 210000001-210999999

    Mower Rotary 2002 42in RD model 78350 Serial 220000001-220999999

    Mower Rotary 2003 42in RD model 78350 Serial 230000001-230999999

    Mower Rotary 2004 42in RD model 78350 Serial 240000001-240999999

    Mower Rotary 2005 42in RD model 78350 Serial 250000001-250999999

    Mower Rotary 2006 42in RD model 78350 Serial 260000001-260999999

    Mower Rotary 2007 42in RD model 78350 Serial 270000001-270999999

    Mower Rotary 2008 42in RD model 78350 Serial 280000001-280999999

    Mower Rotary 2009 42in RD model 78350 Serial 290000001-290999999

    Mower Rotary 2010 42in RD model 78350 Serial 310000001-310999999

    Mower Rotary 2011 42in RD model 78350 Serial 311000001-311999999

    Mower Rotary 2012 42in RD model 78350 Serial 312000001-312999999

    Mower Rotary 2013 42in RD model 78350 - None built

    Mower Rotary 2014 42in RD model 78350 Serial 314000001-314999999

    93 downloads

    Updated

  18. Free

    Mower Rotary 36in SD 1983-1984 05-36MS02 TIPL.pdf

    IPL from Toro Master Parts Viewer
    6 pages 348.76KB

    Fits B-Series and C-Series tractors

    Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
    1972 Commando 800 model 1-0110
    1973 8hp 4-Speed model 1-0120
    1974 B-80 4-Speed models 1-0140 and 1-0145
    1974 B-100 Auto model 1-0510
    1975 B-80 4-Speed model 1-0141
    1975 B-100 Auto model 1-0511

    Drive belt 102741 (1/2" x 96.6") for C-Series long frame tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")

    Spindle belt 8411 (1/2" x 76.94")

    Mower spindle assembly H

    107983 3-blade set replaces 107437 left and right blades (12-1/8") and 107438 center blade (14-1/8") (Hole 3/4" round)

    Mower Rotary 1983 36in SD model 05-36MS02

    Mower Rotary 1984 36in SD model 05-36MS02

    81 downloads

    Updated

  19. Free

    Mower Rotary 42in RD 1994 78355 Recycler IPL.pdf

    IPL #3316-663
    8 pages 1.42MB

    Fits 300, 400 and 500-Series tractors

    Drive belt 108834 - HA x 98in
    Spindle belt 106125 - HA x 89.03in

    Toro 3-blade kit 14-4879 replaces 116840 79-2920 79-3070
    Napa 3 of # 7-06767
    Hole 3/4in. round
    14.500in. 14-1/2" long

    Mower Rotary 1994 42in RD model 78355 Recycler Serial 4900001-4999999

    85 downloads

    Updated

  20. Free

    Mower Rotary 60in SD 1991 C5-60SC03 500 OM IPL SN.pdf

    OM #810685R1
    8 pages 1.63MB

    IPL #3314-908
    8 pages 1.24MB

    Fits 520-Series tractors with forward swept front axle
    For C5-60SC02 Mower - Service Assembly 14-4799 Retrofit
    See service bulletin Toro91-presGT #GT04 Anti-Scalp Rollers 60in Mower

    Drive belt 113072 (1/2" x 103")
    Spindle belt 112449 (5/8" x 131.25")

    Blade 112947 (x3) (5/8" round hole)
    Blade for wet grass 78-2480 replaced by 78-2480-03 (x3)

    Mower Rotary 1991 60in SD model C5-60SC03 Serial 1000001-1099999

    1991 serial numbers that have shown up for the C5-60SC03
    1050498
    1050603
    1050647

    137 downloads

    Updated

  21. Free

    Mower Rotary 48in RD 1990 55665 HMR OM IPL sn.pdf

    Operator manual #3314-153
    16 pages 2.3MB

    IPL #3314-131
    6 pages 801KB

    Used on HMR-1600 rear engine rider

    Drive belt 49-6950 (Dimensions unknown and still available from Toro) - May be 1/2" x 58"
    Spindle belt 72-7770 (Dimensions unknown and no longer available from Toro)

    Mower Rotary 1990 48in rear discharge model 55665 Serial 0000001-0999999

    65 downloads

    Updated

  22. Free

    Mower Rotary 42in SD 1999 78345 3-400 IPL.pdf

    IPL #3323-183
    8 pages 147.35KB

    Fits 300 and 400-Series tractors

    Drive belt 102742 replaced by 94-2501 (1/2" x 103") [108834 is wrong in the belt chart for 1999]
    Spindle belt 6738 (1/2" x 86") [106125 is wrong in the belt chart for 1999]

    106077 replaced by 106636 3-blade set (3/4" round hole) [14-4879 recycler 3-blade set in blade chart is wrong]

    Mower Rotary 1999 42in SD model 78345 Serial 9900001-9999999 -  [Belts wrong in the belt chart for 1999]

    73 downloads

    Updated

  23. Free

    Mower Rotary 36in RD 1967 RL-367 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    1 page 158.19KB

    Fits long frame tractors
    Toro incorrectly lists the RL-367 as a 1966 model

    Drive belt 1563 (1/2" x 39") [1587 in belt chart is wrong]
    Spindle belts 1578 (3/8" x 37" matched pair)

    8014 2-blade set replaces 4116 and 7906 right blades, 4117 and 7907 left blades and 2-blade set 101522

    Mower Rotary 1967 36in RD model RL-367

    1967 serial numbers that have shown up for the RL-367
    383029

    126 downloads

    Updated

  24. Free

    Mower Rotary 48in SD 1993-1997 79190 Recycler kit OM IPL sn.pdf

    Installation instructions #3319-480
    12 pages 1.57MB

    Installation instructions #3319-542
    12 pages 169.12KB

    IPL #3328-216
    2 pages 63.54KB

    Recycler blade set 94-9719

    Early 1997 models use 79190 Recycler kit
    Mower Rotary 1993 48in SD model 78260 Serial 3900001-3999999 for 260-Series tractors
    Mower Rotary 1994 48in SD model 78260 Serial 4900001-4999999 for 260-Series tractors
    Mower Rotary 1995 48in SD model 78260 Serial 5900001-5999999 for 260-Series tractors
    Mower Rotary 1996 48in SD model 78260 Serial 6900001-6999999 for 260-Series tractors
    Mower Rotary 1997 48in SD model 78260 Serial numbers below 7904310 for 260-Series tractors

    Mower Rotary 1996 48in SD model 78268 Serial 6900001-6999999 for Export 260-Series tractors
    Mower Rotary 1997 48in SD model 78268 Serial numbers below 7902555 for Export 260-Series tractors

    Mower Rotary 1993 48in SD model 78360 Serial 3900001-3999999 for 300-Series tractors
    Mower Rotary 1994 48in SD model 78360 Serial 4900001-4999999 for 300-Series tractors
    Mower Rotary 1995 48in SD model 78360 Serial 5900001-5999999 for 300-Series tractors
    Mower Rotary 1996 48in SD model 78360 Serial 6900001-6999999 for 300-Series tractors
    Mower Rotary 1997 48in SD model 78360 Serial numbers below 7904083 for 300-Series tractors

    Mower Rotary 1996 48in SD model 78368 Serial 6900001-6999999 for Export 300-Series tractors
    Mower Rotary 1997 48in SD model 78368 Serial numbers below 7901140 for Export 300-Series tractors

    Late 1997 models use 79195 Recycler kit

    96 downloads

    Updated

  25. Free

    Mower Reel Rear 30in Toro Spartan OM IPL SN.pdf

    Toro Spartan towed reel mowers

    Illustrated parts list #3310-746 (1976-1979)
    8 pages 1.61MB

    Operator manual #3310-461 (1974-1975)
    16 pages 4.28Mb

    Operator manual #3310-755 (1976-1977)
    20 pages 5.31Mb

    Operator manual #3311-130 (1978-1979)
    20 pages 7.14Mb

    TIPL = Illustrated parts list from Toro Master Parts Viewer

    1964-1967 4-blade model 01173 - TIPL 3 pages
    1968 4-blade model 01173 - TIPL 5 pages
    1969-1971 4-blade model 01174 - TIPL 6 pages

    1972-1973 5-blade model 01175 - TIPL 8 pages
    1973-1974 5-blade model 01065 - TIPL 7 pages
    1974 5-blade model 01065 - Operator manual 3310-461
    1974-1975 5-blade riveted model 01066 - Operator manual 3310-461
    1974-1975 5-blade riveted model 01066 - TIPL 8 pages
    1976 5-blade riveted model 01066 - Operator manual 3310-755 - TIPL 7 pages
    1976-1977 5-blade welded model 01075 - Operator manual 3310-755 - Illustrated parts list 3310-746
    1978-1979 5-blade welded model 01075 - Operator manual 3311-130 - Illustrated parts list 3310-746

    The model 01133 may go back before 1964 because Toro lists this model without a serial number (none) - TIPL 2 pages
    1964-1967 6-blade model 01133 - TIPL 3 pages
    1968 6-blade model 01133 - TIPL 5 pages
    1969-1971 6-blade model 01134 - TIPL 6 pages
    20845 may be a 1962 serial number for the model 01133

    1971 7-blade model 01177 - TIPL 6 pages
    1972-1973 7-blade model 01177 - TIPL 8 pages
    1973-1975 7-blade model 01067 - TIPL 8 pages
    1974-1975 7-blade riveted model 01067 - Operator manual 3310-461
    1976 7-blade riveted model 01067 - Operator manual 3310-755 - TIPL 7 pages
    1976-1977 7-blade welded model 01077 - Operator manual 3310-755 - Illustrated parts list 3310-746
    1978-1979 7-blade welded model 01077 - Operator manual 3311-130 - Illustrated parts list 3310-746

    The model 01193 may go back before 1964 because Toro lists this model without a serial number (none) - TIPL 2 pages
    1964-1967 8-blade model 01193 - TIPL 3 pages
    1968 8-blade model 01193 - TIPL 5 pages
    1969-1971 8-blade model 01194 - TIPL 6 pages

    1972-1973 9-blade model 01196 - TIPL 8 pages
    1973-1975 9-blade model 01069 - TIPL 8 pages
    1974-1975 9-blade model 01069 - Operator manual 3310-461


    503 downloads

    Updated

Sign in to follow this



×
×
  • Create New...
