Husband wants some advice… lol. So we did an engine swap today on two suburbans because we could not get the one engine to spark all the time to get it running! The engine ran last year before parking for the winter sleep…. Points were changed out for new the engine was cleaned to make good contact has new spark plug new coil condenser we even switched out the fly wheel today thinking maybe the magnet was weak…. Advice??? It would where are you out yanking on the recoil five or so times and maybe only get the points to fire twice if you’re lucky.. checked the gap and pull again… same thing over and over! Thanks in advance!
Well got my new weight yesterday! My valentines gift from my husband now has the front weight less likely to pop those wheelies!!!! There might be enough power still but doubt it…. He bought me the RJ from David in Arkansas a few years back we posted on the trip! The moment we saw the ad on here about the front weight we had to have it! Seize the moment, don’t know when ever come across another for sell…! So here I just wanted to share pictures of it! My tractor is a bit dirty from winter setting but i wipped it down just a little for the photo opt!!
Well my husband got new grownup toys! Lol. Just wanted to post them on here to share! Sure most seen for sale but they arrived yesterday at our back door glad we found them before it rained again! Not sure why delivery person made the effort to go to the back of the house…. 🤔🤯
Illustrated parts list
6 pages 3.73MB
Illustrated parts list #A-7136
Includes PSB #023 #052 #058 #060 #080
10 pages 938.48KB
Engines used according to Toro
Electric start kit
Electric starter kit model EC-35 for Clinton engine - Listed for 1958 and 1959
Electric starter kit model EK-35 for Kohler engine - Listed for 1958 and 1959
6-12 tire chains model TC-12 - Listed for 1958 and 1959
Seat cushion Foam rubber with imitation leather cover model FC-24 - Listed for 1958 and 1959
Transmission drive belt 1567 - (4L x 29" or 1/2" x 29")
Details & Attachments
2 pages 107.33KB
1958 model RJ-58
1958 serial numbers that have shown up for the RJ-58
Early models used Kohler K90T-27107D equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter.
01099 - No casting date on trans. Leather gearshift boot, large, round rear wheel hubs, "slab" hitch, replacement engine
01188 - Has round rear wheel hubs
01789 - No casting date on trans. Leather gearshift boot, 3-ear triangular rear wheel hubs, "slab" hitch, Clinton engine with Schnacke recoil
03501 - Located in UK
03796 - Kohler K90T-27107D with serial 364044 equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter.
06528 - May be 16528
07649 - Transmission J12-8 October 12, 1958
09337 - Hard to read
11628 - # 3521 spline gear with 10 splines changed to 11 splines in 5003 and 5010 transmissions at serial # 11628 PSB #023
12221 - B3-9 trans casting date - Kohler K91 engine with Schnacke recoil
16528 - May be 06528
16868 - F4-9 trans casting date - Kohler K91 engine with Fairbanks recoil, solid pan seat without holes
18500 and lower
Late 1958 units came with a Kohler K-91T-31307A equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter.
Details & Attachments
2 pages 106.94KB
1959 model RJ-59
1959 serial numbers that have shown up for the RJ-59
Early 1959 units came with a Kohler K-91T-31307A equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter.
18501 and up - Possible 1100 units built
20078 - Located in UK
21900 - 1960 Suburban 400 began production at serial #21900 somewhere around Aug-Oct 1959.
Late model RJ-59 tractors with a Kohler would have a K-91T-31388A with the Fairbanks recoil starter and paper air filter element. The 31388A was also used on the 1960 Suburban 400.
K91T-31388A Serial 425251 found on RJ-59
New to this forum, Let’s see what other wheelhorse’s are in the UK, I’m in South Wales.
