Snow Blowers

Sign in to follow this

143 files

  1. Free

    Snowthrower 26in Walk behind 1973 7hp 4-2652 D&A TIPL SN.pdf

    Illustrated parts list from Toro Master Parts Viewer
    4 pages 208KB

    Details only - No attachment list but there was a 5-4321 32" rear discharge mower deck
    1 page 37KB

    Named a Trailblazer 7 at Toro

    Impeller belt 6506 (4L x 31.91" or 1/2" x 31.91") [Gates 6832]
    Transmission belt 6551 (3L x 30.5" or 3/8" x 30.5") [Gates 6731]
    Reverse belt 6552 (3L x 30.07" or 3/8" x 30.07") [Gates 6730]

    Snowthrower 1973 26in model 4-2652
    1973 serial numbers that have shown up for the 4-2652
    0916406 - model 4-2652-8

    36 downloads

    Updated

  2. Free

    Snowthrower 26in Walk behind 1969 7hp 4-2633 D&A TPL sn.pdf

    Illustrated parts list from Toro Master Parts Viewer
    4 pages 219KB
    2 pages from 1968 model 4-2632 to get illustrations

    Details only - No attachment list but there was a 5-4321 32" rear discharge mower deck
    1 page 37KB

    Named a Trailblazer 7 at Toro
    Uses 5057 transmission and 7487 rotor drive

    Impeller belt 6506 (4L x 31.91" or 1/2" x 31.91") [Gates 6832]
    Transmission belt 6551 (3L x 30.5" or 3/8" x 30.5") [Gates 6731]
    Reverse belt 6552 (3L x 30.07" or 3/8" x 30.07") [Gates 6730]

    Snowthrower 1969 26in model 4-2633

    50 downloads

    Updated

  3. Free

    Snowthrower 26in Walk behind 1967 6hp 4-2631 D&A.pdf

    Details only
    1 page 37KB

    Named a model 626 at Toro
    Uses 5055 transmission

    1967 26" snowthrower model 4-2631

    17 downloads

    Updated

  4. Free

    Cab Snow 1988-1991 P6-47CC01 for 300 400 500-Series.pdf

    Operator manual
    6 pages 4.86MB
    This is a copy of original Snow Cab manual for model P-647CC from The Original Cab Company.
    This cab listed for 1988-1991 300, 400 & 500 series tractors.
    Original Tractor Cab model number 8611HTS / 4737HTS as listed on the Attachment Interchange

    Listed in the attachment list for 1988 312-8e model E1-12K801
    Full view tractor cab model P6-47CC01

    265 downloads

    Updated

  5. Free

    Snowthrower 42in 1968-1971 Toro OM.pdf

    Operator manual #331-856RevA or #331-856 RevA
    4 pages 655.02KB

    Shares manual with 32in model 59031

    1968 Snowthrower 42in Toro model 59030 - Model year a guess
    1969 Snowthrower 42in Toro model 59030 - Model year a guess
    1970 Snowthrower 42in Toro model 59030 Serial 0000001-0999999 - Model year a guess
    1971 Snowthrower 42in Toro model 59030 - Model year a guess

    Fits
    66TE8 - Springfield model?
    66TE10 - Springfield model?
    66TE12 - Springfield model?
    1967 Toro model 55200
    1967 Toro model 55300
    1967 Toro model 55400
    1968 Toro model 55301
    1968 Toro model 55401
    1969 Toro model 55302
    1969 Toro model 55402
    1970 Toro model 55302
    1970 Toro model 55402
    1971 Toro model 55302
    1971 Toro model 55402

    80 downloads

    Updated

  6. Free

    Snowthrower 42in 2001-2005 79263 OM IPL sn.pdf

    Operator manual #3326-276RevA or 3326-276 RevA
    24 pages 1.46MB

    IPL #3325-374
    8 pages 349.36KB

    Fits 260-Series tractors

    Drive belt 94-2999 (Dimensions unknown - Possibly same as 94-2879 1/2" x 131.5")

    Snowthrower 2001 42in model 79263 Serial 210000001-210999999
    2001 serial numbers that have shown up for the 79263
    210000144

    Snowthrower 2002 42in model 79263 Serial 220000001-220999999

    Snowthrower 2003 42in model 79263 Serial 230000001-230999999

    Snowthrower 2004 42in model 79263 Serial 240000001-240999999

    Snowthrower 2005 42in model 79263 Serial 250000001-250999999

    117 downloads

    Updated

  7. Free

    Snowthrower 42in 1998-1999 79263 OM IPL SN.pdf

    Operator manual #3326-276RevA or 3326-276 RevA
    24 pages 1.46MB

    IPL #3318-467
    12 pages 188.81KB

    Fits 260-Series tractors

    Drive belt 94-2879 (HA x 131.50 or 1/2" x 131.5")

    Snowthrower 1998 42in model 79263 Serial 8900001-8999999
    1998 serial numbers that have shown up for the 79263
    8900272

    Snowthrower 1999 42in model 79263 Serial 9900001-9999999
    1999 serial numbers that have shown up for the 79263
    9900204

    112 downloads

    Updated

  8. Free

    Cab Snow 1985-on 79978 for 300 400 500-Series OM IPL.pdf

    Owner manual
    IPL
    13 pages 1.31MB

    209 downloads

    Updated

  9. Free

    Snowthrower 30in 1960-1961 ST-30 Manual cover.pdf

    Manual cover only
    1 page 106.40KB

    36 downloads

    Updated

  10. Free

    Snowthrower 30in 1960-1961 ST-30 ST-307 OM IPL sn.pdf

    Operator manual
    IPL

    ST-30 fits mid-engine models - Listed on belt sleeve as 1960 only
    Drive belt 1570 (4L/A x 69" or 1/2" x 69")

    ST-307 fits 1961 model 701
    Drive belt 1574 replaced by 517439 (A x 33.10" or 1/2" x 33.1")

    Snowthrower 1960 30in model ST-30

    Snowthrower 1961 30in model ST-30

    Snowthrower 1961 30in model ST-307

    182 downloads

    Updated

  11. Free

    Snowthrower Lift assist Spring kit 8-4311 OM IPL.pdf

    Operator manual #803954
    IPL
    2 pages 531.75KB
    Dated 8/74
    84311 at Toro
    Blower Lift assist spring kit. Same spring used to assist tiller lift.

    Spring Extension 90106 replaced by 4629
    7-1/2" between hooks
    .220" wire
    1-1/2" coil OD
    5-1/2" coil length
    24-1/2 coils

    428 downloads

    Updated

  12. Free

    Snowthrower 42in 1977 76-42ST01 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    4 pages 244.18KB

    Sold only in 1977
    Fits C-Series tractors

    Drive belt 9750 (5L x 69" or 5/8" x 69")

    Snowthrower 1977 42in model 76-42ST01

    116 downloads

    Updated

  13. Free

    Snowthrower 37in 1965 ST-375 OM IPL SN.pdf

    Operator manual #A-7138
    IPL
    11 pages 883.45KB

    1-stage
    Fits 953, 1054 and 1054A
    Uses # 41 chain
    Includes PSB #081 #356 #377

    Drive belt #1576 replaced by 9691 (HA x 70" or 1/2" x 70")

    Snowthrower 1965 37in model ST-375

    1965 serial numbers that have shown up for the ST-375
    029585
    029942
    030922

    90 downloads

    Updated

  14. Free

    Snowthrower 42in 1994 79360 OM IPL SN.pdf

    Operator manual #3316-425
    8 pages 2MB

    IPL #3316-887
    4 pages 868.25KB

    Fits 300 400 500-Series tractors

    Snowthrower 1994 42in model 79360 Serial 4900001-4999999

    1994 serial numbers that have shown up for the 79360
    4900274
    4900362
    4900574
    4900627
    4900677
    4900900

    141 downloads

    Updated

  15. Free

    Cab Snow 1995-2002 260-Series Details SN.pdf

    Details only
    2 pages

    Cab Snow 1995 model 79911
    1995 serial numbers that have shown up for the 79911
    5900285

    Cab Snow 1996 model 79911
    Cab Snow 1997 model 79911
    Cab Snow 1998 model 79911

    Cab Snow 1999 model 79911
    0000296 looks like a 2000 serial but would be 200000296 if it was. Would have been produced in mid-1999 likely before they figured out how to handle the new 9-digit 2000 serials.

    Cab Snow 2000 model 79970
    Cab Snow 2001 model 79970
    Cab Snow 2002 model 79970

    43 downloads

    Updated

  16. Free

    Snowthrower 44in 2000 2-stage 79361 OM IPL SN.pdf

    Operator manual #3319-675
    32 pages 781.17KB

    Illustrated Parts List #3318-459
    8 pages 146.09KB

    Fits 300 400 500-Series tractors

    Snowthrower 2000 44in model 79361 Serial 200000001-200999999
    2000 serial numbers that have shown up for the 79361
    200000131
    200000156

    530 downloads

    Updated

  17. Free

    Snowthrower 48in 1980-1981 06-48SX01 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    8 pages 415.23KB

    Fits D-250 10-Speed

    Snowthrower 1980 48in model 06-48SX01

    Snowthrower 1981 48in model 06-48SX01

    43 downloads

    Updated

  18. Free

    Snowthrower 48in 1979 96-48ST01 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    6 pages 368.59KB
    Fits 18hp Auto and D-Series Auto models
    Supplied by Haban. Basic unit also used by International Harvester and Bolens
    Drive belt is # 200170 but not in the Wheel Horse belt charts so don't know the dimensions.
    Gates replace 200170 with their 6853 and Napa with their 4L530W - 5/8" x 53"
    Stens replaces 200170 with their 248-053 - 5/8" x 53"
    We have to assume the 5/8" x 53" belt is correct.
    Owners have reported that a 5/8" x 49" belt works well in this application.
    Snowthrower 1979 48in model 96-48ST01

    30 downloads

    Updated

  19. Free

    Snowthrower 48in 1980-1982 06-48ST01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    6 pages 318.66KB
    Fits 18hp Auto and D-Series Auto models
    Supplied by Haban. Basic unit also used by International Harvester and Bolens
    Drive belt is # 200170 but not in the Wheel Horse belt charts so don't know the dimensions.
    Gates replace 200170 with their 6853 and Napa with their 4L530W - 5/8" x 53"
    Stens replaces 200170 with their 248-053 - 5/8" x 53"
    We have to assume the 5/8" x 53" belt is correct.
    Owners have reported that a 5/8" x 49" belt works well in this application.
    Snowthrower 1980 48in model 06-48ST01
    1980 serial numbers that have shown up for the 06-48ST01
    00001290 - May be a 1981 or 1982 model
    Snowthrower 1981 48in model 06-48ST01
    1981 serial numbers that have shown up for the 06-48ST01
    00001290 - May be a 1980 or 1982 model
    Snowthrower 1982 48in model 06-48ST01
    1982 serial numbers that have shown up for the 06-48ST01
    00001290 - May be a 1980 or 1981 model

    72 downloads

    Updated

  20. Free

    Snowthrower 48in 1977 76-48SX01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    5 pages 324.22KB

    Fits D-250 10-Speed

    Snowthrower 1977 48in model 76-48SX01

    1977 serial numbers that have shown up for the 76-48SX01
    009546

    42 downloads

    Updated

  21. Free

    Snowthrower 37in 1989 06-37SK02 TIPL sn.pdf

    IPL from Toro master Parts Viewer
    5 pages 392.00KB

    Original operator manual #810606R1
    Fits 252-H 257-H

    Drive belt 115192 (HA x 127" or 1/2" x 127")

    Snowthrower 1989 37in model 06-37SK02

    52 downloads

    Updated

  22. Free

    Snowthrower 42in 1983 06-42ST03 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    4 pages 243.28KB

    Sold 1983 only
    First model to use skids instead of wheels
    Drive belt 9750 (5L x 69" or 5/8" x 69")

    Snowthrower 1983 42in model 06-42ST03

    86 downloads

    Updated

  23. Free

    Snowthrower 48in 1977 76-48ST01 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    4 pages 257.92KB

    Fits D-Series Auto models
    Supplied by Haban. Basic unit also used by International Harvester and Bolens
    Drive belt is # 200170 but not in the Wheel Horse belt charts so don't know the dimensions.
    Gates replace 200170 with their 6853 and Napa with their 4L530W - 5/8" x 53"
    Stens replaces 200170 with their 248-053 - 5/8" x 53"
    We have to assume the 5/8" x 53" belt is correct.
    Owners have reported that a 5/8" x 49" belt works well in this application.

    Snowthrower 1977 48in model 76-48ST01

    51 downloads

    Updated

  24. Free

    Snowthrower 48in 1975 6-7452 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    4 pages 281.15KB

    Fits 18hp Auto and D-Series Auto models
    Supplied by Haban. Basic unit also used by International Harvester and Bolens
    Drive belt is # 200170 but not in the Wheel Horse belt charts so don't know the dimensions.
    Gates replace 200170 with their 6853 and Napa with their 4L530W - 5/8" x 53"
    Stens replaces 200170 with their 248-053 - 5/8" x 53"
    We have to assume the 5/8" x 53" belt is correct.
    Owners have reported that a 5/8" x 49" belt works well in this application.

    Snowthrower 1975 48in model 6-7452
    1975 serial numbers that have shown up for the 6-7452
    0983056 - This is a 1974 serial number - At the Toro MPV using model 66-48ST01 the 6-7452 model shown with 983056 and up serial number. May be 1st serial number for 6-7451 as listed in OM

    132 downloads

    Updated

  25. Free

    Snowthrower 48in 1976 66-48ST01 TIPL sn.pdf

    IPL from Toro Master Parts Viewer
    4 pages 260.87KB

    Fits 18hp Auto and D-Series Auto models
    Supplied by Haban. Basic unit also used by International Harvester and Bolens

    Drive belt is # 200170 but not in the Wheel Horse belt charts so don't know the dimensions.
    Gates replace 200170 with their 6853 and Napa with their 4L530W - 5/8" x 53"
    Stens replaces 200170 with their 248-053 - 5/8" x 53"
    We have to assume the 5/8" x 53" belt is correct.
    Owners have reported that a 5/8" x 49" belt works well in this application.

    Snowthrower 1976 48in model 66-48ST01

    44 downloads

    Updated

Sign in to follow this



×
×
  • Create New...
