Snow Blowers

Sign in to follow this

144 files

  1. Free

    Snowthrower 32in 1968 6-3211 Lawn Ranger OM IPL SN.pdf

    Operator manual #A-5258
    IPL
    7 pages 1.17MB

    1-stage
    Fits Lawn Ranger Horizontal shaft
    Uses # 41 chain
    Includes PSB #356
    Formerly STR-324

    Drive belt 1589 (4L x 56.5" or 1/2" x 56.5")

    Snowthrower 1968 32in model 6-3211
    1968 serial numbers that have shown up for the 6-3211
    389036
    537859

    166 downloads

    Updated

  2. Free

    Snowthrower 42in 1978 86-42ST01 OM IPL SN.pdf

    Operator manual #803737R2
    9 pages 1.82MB

    IPL #810022R2
    5 pages 1.49MB

    Sold 1978 model year only
    Fits C-Series tractors
    OM #803737R1 not correct PSB #235 shows correction
    This R2 manual corrects the mistake

    Drive belt 9750 (5L x 69" or 5/8" x 69")

    Snowthrower 1978 42in model 86-42ST01

    1978 serial numbers that have shown up for the 86-42ST01
    004124 - Build date 1977 7199 July 18 Monday [M]
    004218 - Build date 1977 7201 July 20 Wednesday
    004253
    004904
    005347 - Build date 1977 7235 August 23 Tuesday
    005374 - Build date 1977 7235 August 23 Tuesday
    005511 - Build date 1977 7311 November 07 Monday
    005537 - Build date 1977 7311 November 07 Monday
    010720 - Build date 1977 7313 November 09 Wednesday
    010731
    010823
    010891 - Build date 1977 7314 November 10 Thursday
    011248

    949 downloads

    Updated

  3. Free

    Snowthrower 42in 1974 6-6213 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    2 pages 138.82KB

    Fits C-Series tractors
    First model to include 8-0221 extensions without the front straight return - just a flat plate
    6-6213 complete snowthrower made up of 6-6212 basic unit, 6-9113 completing package and 8-4311 lift assist spring kit

    Medium frame tractors use drive belt 102743 (B x 65.95" or 5/8" x 65.95")
    Long frame tractors use drive belt 9750 (5L x 69" or 5/8" x 69")

    Snowthrower 1974 42in model 6-6213
    1974 serial numbers that have shown up for the 6-6213
    0754579

    165 downloads

    Updated

  4. Free

    Snowthrower 32in 1963 ST-323 OM IPL DNA SN.pdf

    Operator manual #A-7138
    IPL
    2 page supplement #112-A dated 10/8/62
    4 pages 433.49KB

    ST-323 fits short frame tractors
    1961 model 701
    1962 models 502, 552 and 702
    1963 models 603, 653 and 753
    1964 model 604

    Chute belt 1590 (3L x 43" or 3/8" x 43")
    Drive belt 1589 (4L x 56.5" or 1/2" x 56.5")

    Snowthrower 1963 32in model ST-323

    1963 serial numbers that have shown up for the ST-323
    A-27183
    A-27341
    A-29674

    32" Snowthrower DNA - For tractors with horizontal shaft engines

    1963 model ST-323 - Fits 701, 502, 552, 702, 603, 653, 753, 604
    (Drive belt 1589 1/2" x 56.5") (Chute turned by belt 1590 3/8" x 43")

    1964 model ST-324 - Fits 701, 502, 552, 702, 603, 633, 653, 753, 604, 654, 704, 854, 605, 655, 855
    (Uses # 41 chain Pitch 1/2" and roller width 1/4") (Drive belt 1589 1/2" x 56.5") (First model to use cable on the chute)

    1965 model ST-325 - Fits 701, 502, 552, 702, 603, 633, 653, 753, 604, 654, 704, 854, 605, 655, 855, 1045, 1055
    (Uses # 41 chain Pitch 1/2" and roller width 1/4") (Drive belt 1589 1/2" x 56.5")

    1966-1967 model ST-326 - Fits 701, 502, 552, 702, 603, 633, 653, 753, 604, 654, 704, 854, 605, 655, 855, 1045, 1055, 606, 656, 856, 876, 607, 657, 857, 867, 877
    (Uses # 41 chain Pitch 1/2" and roller width 1/4") (Drive belt 1589 1/2" x 56.5")

    1968-1969 model 6-2211 - Fits 500 Special, Commando 6, Commando 8, WorkHorse 700
    (Formerly ST-326) (Uses # 41 chain Pitch 1/2" and roller width 1/4") (Drive belt 1589 1/2" x 56.5")

    1971 model 6-0100 - Fits 800 Automatic, 800 Special, Bronco 14, Charger 12, Raider 10, Raider 12, WorkHorse 800
    (No record of 6-0100 at Toro. Suspect it was same as 6-0200 plus 6-9112 in one package)
    (Uses # 40 chain Pitch 1/2" and roller width 5/16") (Uses #101460 lift tube and #9750 5/8" x 69" belt)

    1972 model 6-0200 plus 6-9112 - Fits Commando 800
    (Uses # 40 chain Pitch 1/2" and roller width 5/16") (Uses #102729 lift tube and #102743 5/8" x 65.95" belt)

    1972 model 6-0200 plus 6-9112 - Fits 800 Automatic, Bronco 14, Charger 10, Charger 12, Raider 8, Raider 10, Raider 12, Raider 14
    (Uses # 40 chain Pitch 1/2" and roller width 5/16") (Uses #101460 lift tube and #9750 5/8" x 69" belt)

    1973 model 6-0200 plus  6-9131 - Fits 8hp 4-Speed
    (Uses # 40 chain Pitch 1/2" and roller width 5/16") (Use #102729 lift tube and #102743 5/8" x 65.95" belt)

    1973 model 6-0200 plus 6-9113 - Fits 8hp 8-Speed, 10hp 8-Speed, 10hp Automatic, 12hp 8-Speed, 12hp Automatic, 14hp 8-Speed, 14hp Automatic, 16hp Automatic
    (Uses # 40 chain Pitch 1/2" and roller width 5/16") (Use #101460 lift tube and #9750 5/8" x 69" belt)

    1974 model 6-0201 is a 37" model
    1975 model 6-0202 is a 37" model

    177 downloads

    Updated

  5. Free

    Snowthrower 26in Walk behind 1966 6hp 626ST & 626STE Reo D&A OM IPL.pdf

    Operator manual #A-7141
    IPL
    7 pages 688.82KB

    2-stage ST626 6hp
    Toro lists a 1965 ST-626A model - Details are all that are available

    Drive belts
    MW10366 [Gates 6836 1/2" x 36"]
    MW10367 [Gates 6833 1/2" x 33"]

    Snowthrower 1966 26in model 626ST
    1966 serial numbers that have shown up for the 626ST
    9721
    9845

    Snowthrower 1966 26in model 626STE

    206 downloads

    Updated

  6. Free

    Snowthrower 26in Walk behind 1968 6hp 4-2632 D&A TIPL SN.pdf

    Illustrated parts list from Toro Master Parts Viewer
    4 pages 206KB

    Details only
    1 page

    Named 626 model @ Toro - Used 5057 transmission and 7487 rotor drive

    Impeller belt 6506 (4L x 31.91" or 1/2" x 31.91") [Gates 6832]
    Transmission belt 6551 (3L x 30.5" or 3/8" x 30.5") [Gates 6731]
    Reverse belt 6552 (3L x 30.07" or 3/8" x 30.07") [Gates 6730]

    Snowthrower 1968 model 4-2632
    1968 serial numbers that have shown up for the 4-2632
    384658
    384970
    385673


    24 downloads

    Updated

  7. Free

    Cab Snow 1978-1981 87, 97 & 07-01CB01 OM SN.pdf

    Operator manual #810042R1

    Original Tractor Cab 7583 HT/S

    Cab Snow 1978 87-01CB01 Fits D-250 10-Speed tractors

    Cab Snow 1979 97-01CB01 Fits D-250 10-Speed tractors
    1979 serial numbers that have shown up for 97-01CB01
    002712

    Cab Snow 1980-1981 07-01CB01 Fits D-250 10-Speed tractors

    116 downloads

    Updated

  8. Free

    Snowthrower 44in 1993 2-stage 79361 OM IPL SN.pdf

    Operator manual #3315-416
    10 pages 5.26MB
    Part 1
    5 pages 2.37MB
    Part 2
    5 pages 2.89MB

    IPL #3316-107
    8 pages 1.40MB

    Fits 300 400 500-Series tractors
    79361 weight 336 lbs.

    Drive belt 116332 (HB x 64.50" or 5/8" x 64.5")

    Snowthrower 1993 44in model 79361 Serial 3900001-3999999
    1993 serial numbers that have shown up for the 79361
    3900245



    246 downloads

    Updated

  9. Free

    Snowthrower 32in 1966-1967 ST-326 OM IPL SN.pdf

    Operator manual #A-5258
    IPL
    7 pages 1.13MB

    ST-326 fits short frame tractors and was replaced by 6-2211
    1961 model 701
    1962 models 502, 552 and 702
    1963 models 603, 633, 653 and 753
    1964 models 604, 654, 704, 754, 854 and 1045
    1965 models 605, 655, 855, 875, 1055 and 1075
    1966 models 606, 656, 856 and 876
    1967 models 607, 657, 857, 867 and 877

    Drive belt 1589 (4L x 56.5" or 1/2" x 56.5")

    Should also fit
    1968 500 Special model 1-3631
    1968 Commando 6 model 1-4631
    1968 Commando 8 model 1-4831
    1969 WorkHorse 700 model 1-3741
    1969 WorkHorse 700 model 1-3745

    Snowthrower 1966 32in model ST-326
    1966 serial numbers that have shown up for the ST-326
    165634
    165720
    165992
    166491

    Snowthrower 1967 32in model ST-326
    1967 serial numbers that have shown up for the ST-326
    274250
    274936
    288934
    289315

    267 downloads

    Updated

  10. Free

    Snowthrower 44in 2003-2007 2-stage 79366 5xi OM IPL SN.pdf

    Operator manual #3325-481RevA or 3325-481 RevA
    24 pages 865.59KB

    IPL #3327-881
    12 pages 257.87KB

    Fits 5xi
    Drive belt 100-4164 replaces 95-3917 which was 5/8" x 104.35"

    Snowthrower 2003 44in model 79366 Serial 230000001-230999999

    Snowthrower 2004 44in model 79366 Serial 240000001-240999999
    2004 serial numbers that have shown up for the 79366
    240000178

    Snowthrower 2005 44in model 79366 Serial 250000001-250999999
    2005 serial numbers that have shown up for the 79366
    250000101
    250000171

    Snowthrower 2006 44in model 79366 Serial 260000001-260999999

    Snowthrower 2007 44in model 79366 Serial 270000001-270999999

    110 downloads

    Updated

  11. Free

    Snowthrower 38in 1987-1988 W0238 Ber-Vac 2-stage SM IPL.pdf

    Service manual
    Illustrated parts list
    20 pages 2.97MB
    Dated 01/87 PM0029

    Bervac model W0238 WO238 similar to W0246D WO246D
    Wheel Horse model P6-38ST01

    Fits 300, 400, 500-Series tractors Supplied by Ber-Vac

    Drive belt B-62 with part number 657644 which does not show up in any interchange
    Suspect the belt is 5/8" x 65"
    Gates 6965
    Napa 5L650W

    Snowthrower 1987 38in model P6-38ST01
    Snowthrower 1988 38in model P6-38ST01

    445 downloads

    Updated

  12. Free

    Snowthrower 46in 1988-1989 W0246D Ber-Vac 2-stage SM IPL.pdf

    Service manual
    IPL
    20 pages 1.7MB
    Dated 11/88

    Pages 14-16 missing which includes the subframe. Added pages 14, 15 and 16 from older W0238 manual November 28, 2020
    Bervac W0246D
    Wheel Horse P6-46ST01
    Fits 300, 400, 500-Series tractors Supplied by Ber-Vac

    Snowthrower 1988 46in model P6-46ST01
    Snowthrower 1989 46in model P6-46ST01

    Listed in the attachment list for 1988 312-8e model E1-12K801
    42" Single Stage Snowthrower model P6-46ST01 but it is not a single-stage

    377 downloads

    Updated

  13. Free

    Snowthrower 38in 1989 W0238 Ber-Vac 2-stage IPL SN.pdf

    Illustrated parts list
    17 pages 426.48KB
    Dated 11/88 PM0038

    Bervac W0238 WO238 similar to W0246D WO246D
    Wheel Horse P6-38ST01
    Fits 300, 400, 500-Series tractors Supplied by Ber-Vac

    Drive belt B-62 with part number 657644 which does not show up in any interchange
    Suspect the belt is 5/8" x 65"
    Gates 6965
    Napa 5L650W

    Snowthrower 1989 38in model P6-38ST01

    1989 serial numbers that have shown up for the W0238
    1030

    453 downloads

    Updated

  14. Free

    Snowthrower 32in 1964-1967 STR-324 OM IPL sn.pdf

    Operator manual
    IPL
    7 pages 1.17MB

    Fits Lawn Ranger

    Drive belt 1589 (4L x 56.5" or 1/2" x 56.5") [Gates 6857]

    Snowthrower 1964 32in model STR-324

    Snowthrower 1965 32in model STR-324

    Snowthrower 1966 32in model STR-324

    Snowthrower 1967 32in model STR-324
    1967 serial numbers that have shown up for the STR-367
    267346 - Model year a best guess

    151 downloads

    Updated

  15. Free

    Cab Snow 1994-2000 79943 OM IPL sn.pdf

    Operator manual  #102801
    IPL
    9 pages 4.45MB

    Snow Cab assembly instructions and parts list
    Wheel Horse 79943 for 300, 400, and 500 series tractors

    387 downloads

    Updated

  16. Free

    Cab Snow 1990-1993 P6-50CC01 OM IPL.pdf

    Operator manual #9060
    IPL
    10 pages 2.0MB

    Supplied by Original Tractor Cab

    Fits 500-Series tractors

    212 downloads

    Updated

  17. Free

    Snowthrower 37in 1975 6-0202 OM IPL SN.pdf

    Operator manual #803957
    IPL
    PSB #356 and #377
    11 pages 519.31KB

    1-stage
    Fits B-80 4-speed and B-100 Auto tractors
    First model to have a cable spool on chute rotating crank handle

    Drive belt 102743 (B x 65.95" or 5/8" x 65.95")

    Snowthrower 1975 37in model 6-0202
    1975 serial numbers that have shown up for the 6-0202
    081218
    094637

    168 downloads

    Updated

  18. Free

    Snowthrower 30in 1962 ST-302 ST-3072 OM IPL SN.pdf

    Operator manual #A-7138
    IPL
    2 pages 242.19KB

    ST-302 fits 400 550 401 551 tractors
    Chute belt 1581 (3L x 45" or 3/8" x 45")
    Drive belt 1582 (4L x 74" or 1/2" x 74")

    Snowthrower 1962 30in model ST-302
    1962 serial numbers that have shown up for the ST-302
    A-01387
    A-01905
    A-02221
    A-02291
    A-10123
    A-10680 - May be a ST-3072
    A-26241 - May be a ST-3072
    A-26964 - May be a ST-3072

    ----------------------------------------------------------------------

    ST-3072 fits short frame tractors
    1961 model 701
    1962 models 502, 552 and 702
    1963 models 603, 653 and 753
    1964 model 604
    Chute belt 1581 (3L x 45" or 3/8" x 45")
    Drive belts matched pair of 1580 (4L x 31" or 1/2" x 31")

    Snowthrower 1962 30in model ST-3072
    1962 serial numbers that have shown up for the ST-3072
    A-01314
    A-01861
    A-02452
    A-10226
    A-10680 - May be a ST-302
    A-10897
    A-10965
    A-26241 - May be a ST-302
    A-26964 - May be a ST-302


    292 downloads

    Updated

  19. Free

    Snowthrower 44in 1991-1998 2000 2-stage 79361 Tensioner.jpg

    108959 wooden tensioner block replaced by 95-7699 nylon block
    Suggested idler sprocket replacement

    Used on
    1991-1992 model 06-44SC01
    1993-1998 and 2000 model 79361


    59 downloads

    Updated

  20. Free

    Snowthrower 48in 1979 96-48SX01 TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    8 pages 443.17KB

    Fits D-250 10-Speed

    Snowthrower 1979 48in model 96-48SX01
    1979 serial numbers that have shown up for the 96-48SX01
    001584

    64 downloads

    Updated

  21. Free

    Snowthrower Single-stage chain & belt routing.jpg

    1 picture 62KB

    Snowthrower DNA
    All have 2 idler sprockets for the drive chain. Started out as 37" wide and the added wings make them 42" wide.
    1966-67 model ST-376
    1968 model 6-1211
    1969 6-6211 plus 6-9111
    1970-72 model 6-6212 plus 6-9112
    All without front quick hitch so not a direct fit for 1973 and later tractors. Snowthrower rear frame mounts in the front of the tractor frame using 2 bushings and a long 3/8-16 x 8-1/2" bolt.
    ------------------------------------------------------------------------------------------------------------
    Front quick hitch introduced. Snowthrower rear frame has a 5/8" diameter round bar.
    1973-74 model 6-6212 plus 6-9113
    1974 model 6-6213 - (First model to include 8-0221 extensions without the front straight return - just a flat plate)
    1975 model 6-6214 - (First model to include 8-0221 [103552 replaced by 93-1617 and 93-1617-01] side extensions with the front straight return. First model to have a cable spool on chute rotating crank)
    1976 model 6-6215 - This one -
    1976 model 66-42ST01 - and this one are likely identical. The model number format changed.
    1977 model 76-42ST01 - This one
    1978 model 86-42ST01 - and this one
    1979 model 96-42ST01 - and this one plus 1980 may be all the same. They started using a different model number for each model year.
    1980 model 06-42ST01 - (Last 42" model to use 4 grooved rollers for the chute)
    1981-82 model 06-42ST02 - (First model to use plastic collar for the chute but was a retrofit for older models. Last model to use wheels)
    1983 model 06-42ST03 - (First model to use skids)
    1984-87 model 06-42ST04 - (Last model to use a 3/4" diameter driveshaft)
    1987-89 model 06-42ST05 - (First model to use a 7/8" diameter driveshaft)
    1990 model 06-42ST06
    1991-93 model 06-42ST07 - (First model with tall chute retained by 3 individual grooved retainers)
    1993-2001 model 79360
    2002-2007 model 79362

    75 downloads

    Updated

  22. Free

    Snowthrower 32in 1972-1973 6-0200 LF MF Basic unit TIPL SN.pdf

    IPL from Toro Master Parts Viewer
    2 pages 128.52KB

    1-stage
    Basic unit

    Requires 6-9113 completing kit
    Fits long frame 8-speeds and autos except GT-14 tractors

    Requires 6-9131 completing kit
    Fits medium frame 4-speed tractors

    Snowthrower 1972 32in model 6-0200 - Basic unit
    1972 serial numbers that have shown up for the 6-0200
    030632
    834049 - Model 6-0200-7

    Snowthrower 1973 32in model 6-0200 - Basic unit
    1973 serial numbers that have shown up for the 6-0200
    910252- Model 6-0200-8

    157 downloads

    Updated

  23. Free

    Snowthrower 37in 1970-1973 6-6212 LF Basic unit OM IPL SN.pdf

    Operator manual #A-5190
    IPL
    10 pages 794.00KB

    1-stage
    Basic unit Requires 6-9111, 6-9112 or 6-9113 completing pkg for long frame tractors
    6-9113 First model to use the front 8-5551 quick hitch
    Includes PSB #114, 356, 377 and 431
    Requires 6-9122 completing package for the GT-14

    Snowthrower 1970 37in model 6-6212

    Snowthrower 1971 37in model 6-6212
    1971 serial numbers that have shown up for the 6-6212
    754718 - Model 6-6212-6
    754832
    755116 - Model 6-6212-6
    755400
    755444
    755732
    788899

    Snowthrower 1972 37in model 6-6212
    1972 serial numbers that have shown up for the 6-6212
    834766 - Model 6-6212-7
    842858
    842894
    842979
    844051 - Model 6-6212-7
    844519 - Model 6-6212-7
    844549 - Model 6-6212-7
    844798

    Snowthrower 1973 37in model 6-6212
    1973 serial numbers that have shown up for the 6-6212
    908957
    909989 - Model 6-6212-8

    304 downloads

    Updated

  24. Free

    Snowthrower 42in 1999-2000 79365 5xi OM IPL sn.pdf

    Operator manual #3321-238
    20 pages 943.40KB

    IPL #3323-638
    8 pages 499.05KB

    Fits 5xi tractors

    Drive belt 95-3918 (B x 76.5" or 5/8" x 76.5")

    Snowthrower 1999 42in model 79365 Serial 9900001-9999999

    Snowthrower 2000 42in model 79365 Serial 200000001-200999999

    62 downloads

    Updated

  25. Free

    Snowthrower 36in 1989 06-36SL01 200 TIPL SN.pdf

    IPL from Toro master Parts Viewer
    7 pages 378.70KB

    Fits 208-4, 208-4SB, 211-4, 211-5SB, 212-5 and 212-H

    Drive belt 115192 (HA x 127.0" or 1/2" x 127")

    Snowthrower 1989 36in model 06-36SL01

    1989 serial numbers that have shown up for the 06-36SL01
    0050020 - Build date 1988 8231 August 18 Thursday
    0050417 - Build date 1988 8236 August 23 Tuesday
    0050517 - Build date 1988 8237 August 24 Wednesday
    0050742 - Build date 1988 8238 August 25 Thursday
    0050841 - Build date 1988 8239 August 26 Friday
    0050895 - Build date 1988 8239 August 26 Friday
    0050904 - Build date 1988 8239 August 26 Friday
    0051017
    0051113

    118 downloads

    Updated

Sign in to follow this



×
×
  • Create New...
