90 files
-
Free
Engine Kohler Carburetor throttle shaft kit #TT321-A.pdf
By tunahead72
Instructions for throttle shaft kit
3 pages 3.8MB
95 downloads
Updated
-
Free
Engine Kohler Carburetor recording obsolete numbers.jpg
By gwest_ca-(File Mod)
Limited information available for old Kohler carburetors
Hillman bushings to repair worn throttle shaft housing Box of 10 number 58087
A-236636 replaced by 47 853 31-S Use A-237490 (Listed for K321 and M14)
211 downloads
Updated
-
Free
Engine Kohler Magnum M 8 M10 M12 M14 M16 OM.pdf
By gwest_ca-(File Mod)
Operator manual #TP-2200-A
8 pages 6158KB
Includes M10
Operator manual #TP-2200-F (Don't know why the 10hp is not included unless it was no longer produced at the time of printing)
16 pages 492.07KB
Dated 7/85 Revised 12/01
M8 (8hp or 6KW)
1986 308-8 model 21-08K801 - Using M8S-301511
1986 308-8 model 21-08K802 - Using M8S-301511
1987 308-8 model 21-08K803 - Using M8S-301511
1988 308-8 model 21-08K804 - Using M8S-301511
The following were supplied to Wheel Horse according to Kohler records
M8-301511 - 1986, 1987, 1988
M10 (10hp or 7.5KW)
1987 310-8 model 21-10K804 - Using M10S-461521
1988 310-8 model 21-10K805 - Using M10S-461521
1989 310-8 model 21-10K806 - Using M10S-461533 - (M10S-461521 at Toro)
1990 310-8 model 31-10K801 - Using M10S-461533 - (M10S-461521 at Toro)
1991 310-8 model 31-10K802 - Using M10S-461533 - (M10S-461521 at Toro)
1992 310-8 model 31-10K803 - Using M10S-461545 - (M10S-46154 at Toro is wrong)
1993 310-8 model 73320 - Using M10S-461545 - (M10S-46145 at Toro is wrong)
The following were supplied to Wheel Horse according to Kohler records
M10-461521 - 1987, 1988, 1989, 1990, 1991
M10-461533 - One found with 1989 Kohler build date and maroon hood decal.
M10-461545 - 1992, 1993, ?
M12 (12hp or 9KW)
1987 312-8 model 21-12K804 - Using M12S-471527
1987 312-A model 21-12KE03 - Using M12S-471527
1988 312-8 model 21-12K805 - Using M12S-471527
1988 312-8e model E1-12K801 - Using M12S-471546
1989 312-8 model 21-12K806 - Using M12S-471527
1989 312-8e model E1-12K802 - Using M12S-471546
1990 312-8 model 31-12K801 - Using M12S-471527
1990 312-8e model R1-12K801 - Using M12S-471546
1990 312-8e model R1-12K802 - Using M12S-471527
1990 312-H model 31-12KE01 - Using M12S-471527
1991 312-8 model 31-12K802 Serial 1000001-1999999 - Using M12S-471527
1991 312-8e model R1-12K803 Serial 1000001-1999999 - Using M12S-471527 - A guess
1991 312-H model 51-12KE01 Serial 1000001-1999999 - Using M12S-471527 (M12S-471521 wrong at Toro)
1992 312-8 model 31-12K804 Serial 2000001-2999999 - Using M12S-471527
1992 312-8e model R1-12K804 Serial 2000001-2999999 - Using M12S-471527
1992 312-H model 51-12KE02 Serial 2000001-2999999 - Using M12S-471527 (M12S-471521 wrong at Toro)
1993 312-8e model 73380 Serial 3900001-3999999 - Using M12S-471527
1994 312-8 model 73362 Serial 4900001-4999999 - Using M12S-471527
1994 312-8e model 73380 Serial 4900001-4999999 - Using M12S-471527
1995 312-8 model 73362 Serial 5900001-5999999 - Using M12S-471527
1996 312-8 model 73362 Serial 6900001-6999999 - Using M12S-471527
1996 312-8 model 73363 Serial 6900001-6999999 - Using M12S-471527
1997 312-8 model 73363 Serial 7900001-7999999 - Using M12S-471527
The following were supplied to Wheel Horse according to Kohler records
M12-471527 - 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997
M12-471546 - 1988, 1989, 1990
M14 (14hp or 10.5KW)
1987 414-8 model 31-14K802 - Uses M14S-601524
1988 414-8 model 31-14K803 - Uses M14S-601540
1989 414-8 model 31-14K804 - Uses M14S-601540
1993-1996 314-8 model 73400 - Uses M14S-601559
1993-1996 314-H model 73401 - Uses M14S-601559
1996-1997 314-8 model 73402 - Uses M14S-601559
1996-1997 314-H model 73403 - Uses M14S-601559
The following were supplied to Wheel Horse according to Kohler records
M14-601524 - 1987
M14-601540 - 1988, 1989,
M14-601559 - 1993, 1994, 1995, 1996, 1997
M16 (16hp or 11.9KW)
1987 416-8 model 31-16K803 - Uses M16S-711523
1988 416-8 model 31-16K804 - Uses M16S-711523
The following were supplied to Wheel Horse according to Kohler records
M16-711523 - 1987, 1988
1,162 downloads
Updated
-
Free
Engine Kohler K 91 Spec 2650-31997 IPL #TP-392-C.pdf
By admin-(Admin)
IPL
48 pages 1.82MB
Dated 10/94
K91 (4hp or 3KW)
1958 model RJ-58 - Some used Kohler K91-31307A - Magneto ignition with points and condenser
1958 model RJ-58 - Some used Kohler K91-31388A - Magneto ignition with points and condenser
1959 model RJ-59 - Some used Kohler K91-31307A - Magneto ignition with points and condenser
1959 model RJ-59 - Some used Kohler K91-31388A - Magneto ignition with points and condenser
1960 model 400 used Kohler K91-31388A - Magneto ignition with points and condenser
1961 model 401 used Kohler K91-41437a according to Toro
The following were supplied to Wheel Horse according to Kohler records
K91-31107 - in ipl - Magneto ignition with points and condenser
K91-31290 - not in ipl
K91-31303 - not in ipl
K91-31307 - in ipl - Magneto ignition with points and condenser
K91-31388 - in ipl - Magneto ignition with points and condenser
K91-31469 - not in ipl
K91-31482 - in ipl - Magneto ignition with points and condenser
K91-31613 - not in ipl
K91-31623 - not in ipl
K91-31658 - not in ipl
254 downloads
Updated
-
Free
Updated
-
Free
Engine Kohler Courage SV470-620 OM SM.pdf
By gwest_ca-(File Mod)
Operator manual
8 pages 743.36KB
Service manual
76 pages 3.05MB
SV470 - 15hp
SV471 - 15hp
SV480 - 16hp
SV530 - 17hp
SV540-0019 - 18hp used on
2006 LX420 Lawn Tractor model 13AX60RG544 Serial 1L215B10000-
2006 LX420 Lawn Tractor model 13AX60RG744 Serial 1L215B10000-
SV541 - 18hp
SV590-0220 - 19hp used on
2009 LX423 Lawn Tractor model 13AX60RG848 Serial 1-1
2009 LX427 Lawn Tractor model 13AX61RG848 1A019H1000 Serial 1-1A309H19999 - Built Before January 31 2009
2009 LX427 Lawn Tractor model 13AX61RG848 1A319H1000 Serial 1-1L319H19999 - Built On or After January 31 2009
SV591 - 19hp
SV600-018 - 20hp used on
2006 LX460 Lawn Tractor model 13AX60RH544 Serial 1A056B50000-
2006 LX460 Lawn Tractor model 13AX60RH744 Serial 1A056B50000-
2007 LX425 Lawn Tractor model 13BX60RG544 Serial 1A087H10172-1E237H10144
2007 LX425 Lawn Tractor model 13BX60RG544 Serial 1E237H10145-
2007 LX425 Lawn Tractor model 13BX60RG744 Serial 1A087H10172-1C307H10417
2007 LX425 Lawn Tractor model 13BX60RG744 Serial 1C307H10418-
2007 LX425 Lawn Tractor model 13BX60RG748 Serial 1A087H10172-1E087H10250
2007 LX425 Lawn Tractor model 13BX60RG748 Serial 1E087H10251-
2007 LX465 Lawn Tractor model 13AX61RH544 Serial 1A117H10393-
2007 LX465 Lawn Tractor model 13AX61RH744 Serial 1A117H10393-
2007 LX465 Lawn Tractor model 13AX61RH748 Serial 1A117H10393-
SV600-??? used on
2010 LX423 Lawn Tractor model 13AX90RS848 Serial 1-1
2010 LX427 Lawn Tractor model 13AX91RS848 Serial 1-1
SV601 - 20hp
SV610 - 21hp
SV620 - 22hp
268 downloads
Updated
-
Free
Engine Kohler Command CH245-CH440 OM SM.pdf
By gwest_ca-(File Mod)
Owner manual 17 590 11 Rev B
8 pages 904KB
Service manual 17 690 01 Rev L
112 pages 10.4MB
99 downloads
Updated
-
Free
Engine Kohler Magnum MV16, MV18 & MV20 OM & SM.pdf
By gwest_ca-(File Mod)
Operator manual
16 pages 1.2MB
Service manual
105 pages 5.2MB
MV16S-56511 used on 1989 HMR-1600 RER model 55620
MV16S-56519 used on 1992-1996 Toro model 30180 Mid-Size Proline Gear Traction Unit
MV18S-58543 used on 1991-1994 Toro model 30190 Mid-Size Proline Hydro Traction Unit
148 downloads
Updated
-
Free
Engine Kohler Coil Magneto ignition with points and condenser 47 755 20-S.jpg
By gwest_ca-(File Mod)
Magneto ignition coil used with points and condenser 4775520-S
Used in the K301S-47147b with Bendix starter and 10 amp stator. Conflicting info in the Kohler parts manuals.
1968 Charger 12 model 1-7231 - Late production but tractor model number stayed the same
1968 Raider 12 model 1-6231 - Late production but tractor model number stayed the same
1968 Electro 12 model 1-7235
111 downloads
Updated
-
Free
Engine Kohler Coil Magneto ignition with points and condenser 231718-S.jpg
By gwest_ca-(File Mod)
Fits K181 with magneto ignition
Kohler 231718-S
64 downloads
Updated
-
Free
Engine Kohler Coil M-Series magneto single cylinder ignition KH10321.jpg
By gwest_ca-(File Mod)
Taken from #492-4509 Electrical Manual
KH10321 Kohler magneto ignition coil
Replaced by 47 584 01 replaced by 47 584 02 replaced by 47 584 03 replaced by 47 584 03-S
Fits models M10 thru M16
122 downloads
Updated
-
Free
Engine Kohler K301S-47421d IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list
2 pages 332KB
1973 Raider 12 8-Speed model 1-0350 used K301S-47421d
1973 12hp 8-Speed model 1-0355 used K301S-47421d
1973 12hp Automatic model 1-0460 used K301S-47421d
1973 12hp Automatic model 1-0465 used K301S-47421d
1974 Raider 12 4-Speed model 1-0352 used K301S-47421d
1974 C-120 8-Speed model 1-0353 used K301S-47421d
1974 Raider 12 8-Speed model 1-0353 used K301S-47421d - This is a guess
1974 C-120 8-Speed model 1-0354 used K301S-47421d
1974 C-120 8-Speed model 1-0356 used K301S-47421d
1974 C-120 Automatic model 1-0485 used K301S-47421d
1974 C-120 Automatic model 1-0490 used K301S-47421d
1975 C-120 8-Speed model 1-0395 used K301S-47421d
1975 C-120 8-Speed model 1-0396 used K301S-47421d
1975 C-120 Automatic model 1-0491 used K301S-47421d
1976 C-120 8-Speed model 61-12K801 used K301S-47421d
1976 C-120 8-Speed model 61-12K802 used K301S-47421d
1976 C-120 8-Speed model 61-12K803 used K301S-47421d
1976 C-120 8-Speed model 61-12K804 used K301S-47421d
1976 C-120 Automatic model 61-12KS01 used K301S-47421d
1976 C-120 Automatic model 61-12KS02 used K301S-47421d
1976 C-120 Automatic model 61-12KS03 used K301S-47421d
1976 C-120 Automatic model 61-12KS04 used K301S-47421d
1977 C-120 8-Speed model 71-12K801 used K301S-47421d
1977 C-120 Automatic model 71-12KS01 used K301S-47421d
185 downloads
Updated
-
Free
Engine Kohler Command CV11-16 CV460-465 CV490-495 SM #TP-2339-D.pdf
By gwest_ca-(File Mod)
Service manual #TP-2339-D
148 pages 5.58MB
Dated 3/89 Revised 7/02
Single cylinder models
CV11
CV12.5
CV13
CV14
CV15
CV16
CV460-465
CV490-495
Kohler CV14S-1472 used on
1994 264-6 model 72042 Serial 4900001-4999999
1994 264-6e model 72062 Serial 4900001-4999999 - Export model
1994 264-H model 72043 Serial 4900001-4999999
1994 264-He model 72063 Serial 4900001-4999999 - Export model
1995 264-6 model 72042 Serial 5900001-5999999
1995 264-6e model 72062 Serial 5900001-5999999 - Export model
1995 264-H model 72043 Serial 5900001-5999999
1995 264-He model 72063 Serial 5900001-5999999 - Export model
1996 264-6 model 72042 Serial 6900001-6999999
1996 264-H model 72043 Serial 6900001-6999999
Kohler CV14S-1488 used on
1996 264-6 model 72062 Serial 6900001-6999999
Kohler CV15S-41527 used on
1996 265-6e model 72045 Serial 6900001-6999999 - Export model
1996 265-H model 72046 Serial 6900001-6999999
Kohler CV15S-41528 used on
1996 265-He model 72064 Serial 6900001-6999999 - Export model
Kohler CV15S-41550 used on
1997 265-6e model 72045 Serial 7900001-7999999 - Export model
1997 265-H model 72046 Serial 7900001-7999999
1998 265-6e model 72045 Serial 8900001-8999999 - Export model
1998 265-H model 72046 Serial 8900001-8999999
1999 265-6 model 72047 Serial 9900001-9999999
1999 265-H model 72048 Serial 9900001-9999999
2000 265-6 model 72049 Serial 200000001-200999999
2000 265-H model 72050 Serial 200000001-200999999
Kohler CV15S-41551 used on
1997 265-He model 72064 Serial 7900001-7999999 - Export model
1998 265-He model 72064 Serial 8900001-8999999 - Export model
1999 265-H model 72070 Serial 9900001-9999999
2000 265-H model 72071 Serial 200000001-200999999
Kohler CV15S-41602 used on
2001 265-H model 72051 Serial 210000001-210999999
2002 265-H model 72051 Serial 220000001-220999999
Kohler Spec 41xxx is a single cylinder engine
-----------------------------------------------------------------------------------------------------------
Kohler CV16S-61514 used on - This is a twin cylinder engine
CV16-61514 - Kohler Command PRO Engine, Made for Toro, 16hp, 11.9kW
CV18-61514 - Kohler Command PRO Engine, Made for Toro, 18hp, 13.4kW
1994 266-H Twin model 72083 Serial 4900001-4999999
1994 268-H Twin model 72103 Serial 4900001-4999999 - Export model 268-He
1995 266-H Twin model 72084 Serial 5900001-5999999
1995 268-H Twin model 72103 Serial 5900001-5900600 - Export model 268-He
1996 266-H Twin model 72084 Serial 6900001-6999999
Kohler CV16S-61526 used on - This is a twin cylinder engine
CV18-61526 - Kohler Command PRO Engine, Made for Toro, 18hp, 13.4kW
1995 268-H Twin model 72103 Serial 5900601-5999999 - Export model 268-He
------------------------------------------------------------------------------------------------------------
These are single cylinder engines
Kohler CV460S-26505 used on
2001 266-H model 72052 Serial 210000001-210999999
2002 266-H model 72052 Serial 220000001-220999999
Kohler CV460S-26506 used on
2001 266-H model 72072 Serial 210000001-210999999 - Export model 266-He
2002 266-H model 72072 Serial 220000001-220999999 - Export model 266-He
Kohler CV460S-26518 used on
2003 416XT model 72200 Serial 230000001-230999999
2004 416XT model 72200 Serial 240000001-240999999
301 downloads
Updated
-
Free
Engine Kohler Command CV17-26 CV675-750 OM #2459002-A.pdf
By gwest_ca-(File Mod)
Operator manual
24 pages 474.37KB
Dated 11/04 Revised 2/07
CV17 CV18 CV20 CV22 CV23 CV25 CV26
CV675 CV680 CV730 CV740 CV750
Kohler CV16S-61514 used on - This is a twin cylinder engine
CV16-61514 - Kohler Command PRO Engine, Made for Toro, 16hp, 11.9kW
CV18-61514 - Kohler Command PRO Engine, Made for Toro, 18hp, 13.4kW
1994 266-H Twin model 72083 Serial 4900001-4999999
1994 268-H Twin model 72103 Serial 4900001-4999999 - Export model 268-He
1995 266-H Twin model 72084 Serial 5900001-5999999
1995 268-H Twin model 72103 Serial 5900001-5900600 - Export model 268-He
1996 266-H Twin model 72084 Serial 6900001-6999999
Kohler CV16S-61526 used on - This is a twin cylinder engine
CV18-61526 - Kohler Command PRO Engine, Made for Toro, 18hp, 13.4kW
1995 268-H Twin model 72103 Serial 5900601-5999999 - Export model 268-He
Kohler CV18S-61528 used on
1996 267-H model 72085 Serial 6900001-6999999
1997 267-H model 72085 Serial 7900001-7999999
1998 267-H model 72085 Serial 8900001-8999999
1999 268-H model 72086 Serial 9900001-9999999
2000 268-H model 72087 Serial 200000001-200999999
2001 268-H model 72087 Serial 210000001-210999999
2002 268-H model 72087 Serial 220000001-220999999
Kohler CV18S-61529 used on
1996 267-H model 72104 Serial 6900001-6999999 - Export model 267-He
1997 267-H model 72104 Serial 7900001-7999999 - Export model 267-He
1998 267-H model 72104 Serial 8900600-8999999 - Export model 267-He
1999 268-H model 72105 Serial 9900001-9999999 - Export model 268-He
2000 268-H model 72107 Serial 200000001-200999999 - Export model 268-He
2001 268-H model 72107 Serial 210000001-210999999 - Export model 268-He
2002 268-H model 72107 Serial 220000001-220999999 - Export model 268-He
2003 268-H model 72107 Serial 230000001-230999999 - Export model 268-He
Kohler CV19S-65531 used on
1996 269-H model 72102 Serial 6900001-6999999
1997 269-H model 72102 Serial 7900001-7999999
1998 269-H model 72102 Serial 8900001-8999999
1999 270-H model 72106 Serial 9900001-9999999
Kohler CV20S-65531 used on
2000 270-H model 72108 Serial 200000001-200999999
2001 270-H model 72108 Serial 210000001-210999999
2002 270-H model 72108 Serial 220000001-220999999
Kohler CV20S-65532 used on
1996 270-H model 72110 Serial 6900001-6999999 - Export model 270-He
1997 270-H model 72110 Serial 7900001-7999999 - Export model 270-He
1998 270-H model 72110 Serial 8900001-8999999 - Export model 270-He
1999 270-H model 72115 Serial 9900001-9999999
2000 270-H model 72116 Serial 200000001-200999999 - Export model 270-He
2001 270-H model 72116 Serial 210000001-210999999 - Export model 270-He
2002 270-H model 72116 Serial 220000001-220999999 - Export model 270-He
2003 270-H model 72116 Serial 230000001-230999999 - Export model 270-He
169 downloads
Updated
-
Free
Engine Kohler Command CV11-16 CV460-465 CV490-493 OM #1259001.pdf
By gwest_ca-(File Mod)
Operator manual
16 pages 1.95MB
Dated 11/04
CV11
CV12.5
CV13
CV14
CV15
CV16
CV460-465
CV490-493
Kohler CV14S-1472 used on
1994 264-6 model 72042 Serial 4900001-4999999
1994 264-6e model 72062 Serial 4900001-4999999 - Export model
1994 264-H model 72043 Serial 4900001-4999999
1994 264-He model 72063 Serial 4900001-4999999 - Export model
1995 264-6 model 72042 Serial 5900001-5999999
1995 264-6e model 72062 Serial 5900001-5999999 - Export model
1995 264-H model 72043 Serial 5900001-5999999
1995 264-He model 72063 Serial 5900001-5999999 - Export model
1996 264-6 model 72042 Serial 6900001-6999999
1996 264-H model 72043 Serial 6900001-6999999
Kohler CV14S-1488 used on
1996 264-6 model 72062 Serial 6900001-6999999
Kohler CV15S-41527 used on
1996 265-6e model 72045 Serial 6900001-6999999 - Export model
1996 265-H model 72046 Serial 6900001-6999999
Kohler CV15S-41528 used on
1996 265-He model 72064 Serial 6900001-6999999 - Export model
Kohler CV15S-41550 used on
1997 265-6e model 72045 Serial 7900001-7999999 - Export model
1997 265-H model 72046 Serial 7900001-7999999
1998 265-6e model 72045 Serial 8900001-8999999 - Export model
1998 265-H model 72046 Serial 8900001-8999999
1999 265-6 model 72047 Serial 9900001-9999999
1999 265-H model 72048 Serial 9900001-9999999
2000 265-6 model 72049 Serial 200000001-200999999
2000 265-H model 72050 Serial 200000001-200999999
Kohler CV15S-41551 used on
1997 265-He model 72064 Serial 7900001-7999999 - Export model
1998 265-He model 72064 Serial 8900001-8999999 - Export model
1999 265-H model 72070 Serial 9900001-9999999
2000 265-H model 72071 Serial 200000001-200999999
Kohler CV15S-41602 used on
2001 265-H model 72051 Serial 210000001-210999999
2002 265-H model 72051 Serial 220000001-220999999
--------------------------------------------------------------------------------------------------
Kohler CV16S-61514 Twin used on
1994 266-H Twin model 72083 Serial 4900001-4999999
1994 268-He Twin model 72103 Serial 4900001-4999999 - Export model
1995 266-H Twin model 72084 Serial 5900001-5999999
1995 268-He Twin model 72103 Serial 5900001-5900600 - Export model
1996 266-HTwin model 72084 Serial 6900001-6999999
Kohler CV16S-61526 Twin used on
1995 268-He Twin model 72103 Serial 5900601-5999999 - Export model
-------------------------------------------------------------------------------------------------
Kohler CV460S-26505 used on
2001 266-H model 72052 Serial 210000001-210999999
2002 266-H model 72052 Serial 220000001-220999999
Kohler CV460S-26506 used on
2001 266-He model 72072 Serial 210000001-210999999 - Export model
2002 266-He model 72072 Serial 220000001-220999999 - Export model
Kohler CV460S-26518 used on
2003 416XT model 72200 Serial 230000001-230999999
2004 416XT model 72200 Serial 240000001-240999999
122 downloads
Updated
-
Free
Engine Kohler Command CV17-25 CV620-730 CV740 CV750 SM #2469007.pdf
By gwest_ca-(File Mod)
Service manual
88 pages 2.91MB
CV17 CV18 CV20 CV22 CV23 CV25
CV620 CV640 CV670 CV680 CV730 CV740 CV750
Kohler CV16S-61514 used on - This is a twin cylinder engine
CV16-61514 - Kohler Command PRO Engine, Made for Toro, 16hp, 11.9kW
CV18-61514 - Kohler Command PRO Engine, Made for Toro, 18hp, 13.4kW
1994 266-H Twin model 72083 Serial 4900001-4999999
1994 268-H Twin model 72103 Serial 4900001-4999999 - Export model 268-He
1995 266-H Twin model 72084 Serial 5900001-5999999
1995 268-H Twin model 72103 Serial 5900001-5900600 - Export model 268-He
1996 266-H Twin model 72084 Serial 6900001-6999999
Kohler CV16S-61526 used on - This is a twin cylinder engine
CV18-61526 - Kohler Command PRO Engine, Made for Toro, 18hp, 13.4kW
1995 268-H Twin model 72103 Serial 5900601-5999999 - Export model 268-He
Kohler CV18S-61528 used on
1996 267-H model 72085 Serial 6900001-6999999
1997 267-H model 72085 Serial 7900001-7999999
1998 267-H model 72085 Serial 8900001-8999999
1999 268-H model 72086 Serial 9900001-9999999
2000 268-H model 72087 Serial 200000001-200999999
2001 268-H model 72087 Serial 210000001-210999999
2002 268-H model 72087 Serial 220000001-220999999
Kohler CV18S-61529 used on
1996 267-H model 72104 Serial 6900001-6999999 - Export model 267-He
1997 267-H model 72104 Serial 7900001-7999999 - Export model 267-He
1998 267-H model 72104 Serial 8900600-8999999 - Export model 267-He
1999 268-H model 72105 Serial 9900001-9999999 - Export model 268-He
2000 268-H model 72107 Serial 200000001-200999999 - Export model 268-He
2001 268-H model 72107 Serial 210000001-210999999 - Export model 268-He
2002 268-H model 72107 Serial 220000001-220999999 - Export model 268-He
2003 268-H model 72107 Serial 230000001-230999999 - Export model 268-He
Kohler CV19S-65531 used on
CV20-65531 - Kohler Command PRO Engine, Made for Toro, 20hp, 14.9kW
1996 269-H model 72102 Serial 6900001-6999999
1997 269-H model 72102 Serial 7900001-7999999
1998 269-H model 72102 Serial 8900001-8999999
1999 270-H model 72106 Serial 9900001-9999999
Kohler CV20S-65531 used on
2000 270-H model 72108 Serial 200000001-200999999
2001 270-H model 72108 Serial 210000001-210999999
2002 270-H model 72108 Serial 220000001-220999999
Kohler CV20S-65532 used on
1996 270-H model 72110 Serial 6900001-6999999 - Export model 270-He
1997 270-H model 72110 Serial 7900001-7999999 - Export model 270-He
1998 270-H model 72110 Serial 8900001-8999999 - Export model 270-He
1999 270-H model 72115 Serial 9900001-9999999 - Export model 270-He
2000 270-H model 72116 Serial 200000001-200999999 - Export model 270-He
2001 270-H model 72116 Serial 210000001-210999999 - Export model 270-He
2002 270-H model 72116 Serial 220000001-220999999 - Export model 270-He
2003 270-H model 72116 Serial 230000001-230999999 - Export model 270-He
227 downloads
Updated
-
Free
Engine Kohler K241 10hp Spec 4600-46858 IPL #TP-404-C.pdf
By tunahead72
Illustrated parts lists
68 pages 2.34MB
Issued 3/82 Revised 7/93
The following engines have the spark advance camshaft
K241, Suffix prior to “D”
K241 (10hp or 7.5KW)
1963 model 953 - Uses K241S-46135A
1964 model 1045 - Uses K241AS-46219A
1964 model 1054 - Uses K241S-46215A
1965 model 1054A - Uses ? K241S-47176 - Looks wrong and K301-47176 is a 12hp service engine
1965 model 1055 - Uses K241AS-46219A
1965 model 1075 - Uses K241AS-46219A
1966 model 1046 - Uses K241S-46219A
1966 model 1056 - Uses K241AS-46333D - Should be K241S?
1966 model 1076 - Uses K241AS-46333D - Should be K241S?
1967 model 1057 - Uses K241S-46333D
1967 model 1067 - Uses K241S-46333D
1967 model 1077 - Uses K241S-46333D
1972 Charger 10 model 1-0410 - Uses K241S-46636D
1972 Raider 10 model 1-0301 - Uses K241S-46636D
1973 10hp 8-Speed model 1-0360 - Uses K241S-46636D
1973 10hp 8-Speed model 1-0365 - Uses K241S-46636D
1973 10hp Automatic model 1-0470 - Uses K241S-46636D
1973 10hp Automatic model 1-0475 - Uses K241S-46636D
1973 Raider 10 8-Speed model 1-0360 - Uses K241S-46636D - Made in Belgium
1974 B-100 Automatic model 1-0510 - Uses K241S-46636D
1974 C-100 8-Speed model 1-0390 - Uses K241S-46636D
1974 Raider 10 4-Speed model 1-0393 - Uses K241S-46636D - Made in Belgium
1974 Raider 10 8-Speed model 1-0390 - Uses K241S-46636D - Made in Belgium
1975 B-100 Automatic model 1-0511 - Uses K241S-46636D
1975 C-100 4-Speed model 1-0394 Uses ?
1975 C-100 8-Speed model 1-0391 - Uses K241S-46636D
1975 Raider 10 4-Speed model 1-0394 - Uses K241S-46636D - Made in Belgium
1976 B-100 8-Speed model 61-10K801 - Uses K241S-46636D
1976 B-100 8-Speed model 61-10K802 - Uses K241S-46636D
1976 B-100 8-Speed model 61-10K803 - Uses K241S-46636D
1976 B-100 8-Speed model 61-10K804 - Uses K241S-46636D
1977 B-100 8-Speed model 71-10K801 - Uses K241S-46756D
1977 C-100 8-Speed model 71-10K8 - Uses ? - Made in Belgium
1978 C-101 8-Speed model 81-10K801 - Uses K241AS-46766D
1979 C-101 8-Speed model 91-10K801 - Uses K241AS-46766D
1979 C-101 8-Speed model 91-10K802 - Uses K241AS-46766D
1979 C-101 8-Speed model 91-10K892 - Uses ? - Made in Belgium
1980 C-105 8-Speed model 01-10K801 - Uses K241AS-46805D
1981 C-105 8-Speed model 01-10K802 - Uses K241AS-46812D
1982 C-105 8-Speed model 01-10K803 - Uses K241AS-46812D
1983 C-105 8-Speed model 11-10K801 - Uses K241AS-46812
1984 C-105 8-Speed model 11-10K802 - Uses K241AS-46812
1985 310-8 model 21-10K801 - Uses K241S-46849 according to Toro
1986 310-8 model 21-10K802 - Uses K241-46863 - First with low oil switch
The following were supplied to Wheel Horse according to Kohler records
K241-46135 - 1963
K241-46215 - 1964
K241-46219 - 1964, 1965, 1966
K241-46323 - ?
K241-46333 - 1966, 1967
K241-46416 - ?
K241-46552 - ?
K241-46586 - ?
K241-46636 - 1972, 1973, 1974, 1975, 1976
K241-46643 - ?
K241-46756 - 1977
K241-46766 - 1978, 1979
K241-46805 - 1980
K241-46812 - 1981, 1982, 1983, 1984
K241-46849 - 1985 - Not in this ipl and may be a mistake at Toro but listed in PSB #301g
K241-46863 - 1986 - First with low-oil switch
726 downloads
Updated
-
Free
Engine Kohler K181 8hp Spec 301000-301045 IPL #TP-2137-A.pdf
By gwest_ca-(File Mod)
Wheel Horse original engine spec numbers did not go this high 301000-301045
Illustrated parts list
24 pages 646KB
165 downloads
Updated
-
Free
Updated
-
Free
Engine Kohler Starter Generator System SM.pdf
By gwest_ca-(File Mod)
From 4-72 Kohler service manual
Starter Generator Regulator
7 pages 3.6MB
214 downloads
Updated
-
Free
Engine Kohler K241 K301 K321 K341 OM #TP-1346-C LR .pdf
By George Gadach
Kohler engine owner's manual for Models K241 (10hp), K301 (12 hp). k321 (14 HP) & K341 (16hp). Operating and maintenance instructions.
16 pages 1.65MB
Issued 10/87 Revised 8/97
Kohler Engines.pdf
408 downloads
Updated
-
Free
Engine Kohler oil.pdf
By gwest_ca-(File Mod)
Kohler engine oil spec sheet
Dated October 2015
2 pages 738KB
104 downloads
Updated
-
Free
Engine Kohler K181 8hp Spec 30100-30848 IPL #TP-2045-B.pdf
By gwest_ca-(File Mod)
Illustrated parts lists
Covers Spec No's 30100-30848
88 pages 5.84MB
The following engines have the spark advance camshaft
K181, Suffix prior to “D”
K181 (8 HP or 6KW)
1964 model 854 - Uses K181S-30108a
1965 model 855 - Uses K181S-30108a
1965 model 875 - Uses K181S-30108a
1966 model 856 - Uses K181S-30108d
1966 model 876 - Uses K181S-30108d
1967 model 857 - Uses K181S-30108d
1967 model 867 - Uses K181S-30108d
1967 model 877 - Uses K181S-30108d
1968 Commando 8 model 1-4831 - Uses K181S-30108d
1969 Commando V8 model 1-4841 - Uses KV181S-37108b - not in ipl
1969 Charger V8 model 1-7841 - Uses KV181S-37108b - not in ipl
1970 Commando V8 model 1-4851 - Uses KV181S-37116b - not in ipl
1972 Commando 800 4-Speed model 1-0110 - Uses K181S-30461d
1972 Raider 8 model 1-0330 - Uses K181S-30461d
1973 8hp 4-Speed model 1-0120 - Uses K181S-30461d
1973 8hp 4-Speed model 1-0130 - Uses K181S-30461d
1973 8hp 8-Speed model 1-0370 - Uses K181S-30461d
1974 B-80 4-Speed model 1-0140 - Uses K181S-30461d
1974 B-80 4-Speed model 1-0145 - Uses K181S-30461d
1975 B-80 4-Speed model 1-0141 - Uses K181S-30629d
1976 B-80 8-Speed model 61-08K801 - Uses K181S-30629d - Incorrectly named a B-60 @ Toro
1976 B-80 8-Speed model 61-08K802 - Uses K181S-30629d - Incorrectly named a B-60 @ Toro
1976 B-80 8-Speed model 61-08K803 - Uses K181S-30629d
1976 B-80 8-Speed model 61-08K804 - Uses K181S-30629d - Incorrectly named a B-60 @ Toro
1977 B-80 8-Speed model 71-08K801 - Uses K181S-30629d
1978 C-81 8-Speed model 81-08K801 - Uses K181S-30700d
1979 C-81 8-Speed model 91-08K801 - Uses K181S-30700d
1979 C-81 8-Speed model 91-08K802 - Uses K181S-30700d
1980 C-85 8-Speed model 01-08K801 - Uses K181S-30743d - Incorrectly named a C-81 @ Toro
1981 C-85 8-Speed model 01-08K802 - Uses K181S-30743d - Incorrectly named a C-81 @ Toro
1982 C-85 8-Speed model 01-08K803 - Uses K181S-30743d
1983 C-85 8-Speed model 11-08K801 - Uses K181S-30803
The following were supplied to Wheel Horse according to Kohler records
K181-301046 - ? - 30104 is in the ipl
K181-30108 - 1965, 1962, 1963, 1964, 1965, 1966, 1967, 1968
K181-30461 - 1972, 1973, 1974
K181-30518 - ? - Is in the ipl
K181-30584 - ? - Is in the ipl
K181-30629 - 1975, 1976, 1977
K181-30700 - 1978, 1979 - Not listed by Kohler for Wheel Horse but is in the ipl
K181-30743 - 1980, 1981, 1982
K181-30803 - 1983
1,089 downloads
Updated
-
Free
Engine Kohler K 91 K161 K181 OM #ENS-593-F.pdf
By tunahead72
Operating & Maintenance Instructions
Low resolution 16 pages 3.09MB
High resolution 16 pages 4.16MB
Dated 3/84
Revised 7/97
The following engines have the spark advance camshaft
K161, Suffix prior to “J”
K181, Suffix prior to “D”
K91 (4 HP)
1960 model 400 - Uses K91-31388a
1961 model 401 - Uses K91-41437a according to Toro. No other record found.
K161 (7 HP)
1961 model 701 - Uses K161S-28522e - Only model to use two starter/generator belts
1962 model 702 - Uses K161S-28626e
1963 model 753 - Uses K161S-28626e
1964 model 704 - Uses K161T-28937e
1964 model 754 - Uses K161S-28626e
1976 B-60 8-Speed model 61-07K801 - Uses K161T-281269j
1976 B-60 8-Speed model 61-07K802 - Uses K161T-281269j
1977 B-60 8-Speed model 71-07K801 - Uses K161T-281269j
K181 (8 HP)
1964 model 854 - Uses K181S-30108a
1965 model 855 - Uses K181S-30108a
1965 model 875 - Uses K181S-30108a
1966 model 856 - Uses K181S-30108d
1966 model 876 - Uses K181S-30108d
1967 model 857 - Uses K181S-30108d
1967 model 867 - Uses K181S-30108d
1967 model 877 - Uses K181S-30108d
1968 Commando 8 model 1-4831 - Uses K181S-30108d
1972 Commando 800 4-Speed model 1-0110 - Uses K181S-30461d
1972 Raider 8 model 1-0330 - Uses K181S-30461d
1973 8hp 4-Speed model 1-0120 - Uses K181S-30461d
1973 8hp 4-Speed model 1-0130 - Uses K181S-30461d
1973 8hp 8-Speed model 1-0370 - Uses K181S-30461d
1974 B-80 4-Speed model 1-0140 - Uses K181S-30461d
1974 B-80 4-Speed model 1-0145 - Uses K181S-30461d
1975 B-80 4-Speed model 1-0141 - Uses K181S-30629d
1976 B-80 8-Speed model 61-08K801 - Uses K181S-30629d - Incorrectly named a B-60 @ Toro
1976 B-80 8-Speed model 61-08K802 - Uses K181S-30629d - Incorrectly named a B-60 @ Toro
1976 B-80 8-Speed model 61-08K803 - Uses K181S-30629d
1976 B-80 8-Speed model 61-08K804 - Uses K181S-30629d - Incorrectly named a B-60 @ Toro
1977 B-80 8-Speed model 71-08K801 - Uses K181S-30629d
1978 C-81 8-Speed model 81-08K801 - Uses K181S-30700d
1979 C-81 8-Speed model 91-08K801 - Uses K181S-30700d
1979 C-81 8-Speed model 91-08K802 - Uses K181S-30700d
1980 C-85 8-Speed model 01-08K801 - Uses K181S-30743d - Incorrectly named a C-81 @ Toro
1980 C-85 8-Speed model 01-08K802 - Uses K181S-30743d - Incorrectly named a C-81 @ Toro
1981 C-85 8-Speed model 01-08K802 - Uses K181S-30743d - Incorrectly named a C-81 @ Toro
1982 C-85 8-Speed model 01-08K803 - Uses K181S-30743d
1983 C-85 8-Speed model 11-08K801 - Uses K181S-30803
860 downloads
Updated
-
Free
Engine Kohler K161 7hp Spec 2801-281298 IPL #287.7.pdf
By tunahead72
Illustrated parts lists
76 pages 4.26MB
The following engines have the spark advance camshaft
K161, Suffix prior to “J”
K161 (7 HP or 5.2KW)
1961 model 701 used K161S-28522E - 1961 was the only year 2 belts were used to drive the starter generator.
1962 model 702 used K161S-28626E - Found on a 702 in Spain
1963 model 753 used K161S-28626E
1964 model 704 used K161T-28937E
1964 model 754 used K161S-28626E
1966 model 706 used ?
1976 B-60 8-Speed model 61-07K801 used K161T-281269J
1976 B-60 8-Speed model 61-07K802 used K161T-281269J
1977 B-60 8-Speed model 71-07K801 used K161T-281269J
The following were supplied to Wheel Horse according to Kohler records
K161S-28522 - 1961 model 701
K161S-28626 - 1962 model 702, 1963 model 753, 1964 model 754
K161S-28701e - ? - Found on a 1962 model 702 in Finland
K161T-28937 - 1964 model 704
K161-281097 - ?
K161-281194 - ?
K161T-281269 - 1976 model B-60, 1977 model B60
415 downloads
Updated
