The no-name and letter series

205 files

  1. Free

    Tractor 1975 C-120 8-Speed D&A SN.pdf

    Lube chart SS

    Details & Attachments
    4 pages 119.84KB
    1975 C-120 8-Speed model 1-0357 - Tecumseh engine  - May be a Belgium built Raider model only

    Details & Attachments
    4 pages 120.42KB
    1975 C-120 8-Speed model 1-0375 - Tecumseh engine - Decaled C-120 Special - May be a North American built model only
    1975 serial numbers that have shown up for the 1-0375
    133367
    133428
    133562
    133619
    133636
    133657
    133663
    133675

    Details & Attachments
    4 pages 120.01KB
    1975 C-120 8-Speed model 1-0395 - Kohler K301S-47421D

    Details & Attachments
    4 pages 120.53KB
    1975 C-120 8-Speed model 1-0396 - Kohler K301S-47421D

    102 downloads

    Updated

  2. Free

    Tractor 1974 Model year WH sold to American Motors

    Info
    American Motors ownership May 24, 1974-1982
    Munn Investments Group ownership 1982-1986
    Toro ownership 1986-on

    102 downloads

    Updated

  3. Free

    Tractor 1977 D-250 10-Speed TIPL.pdf

    IPL from Toro Master Parts Viewer
    71 pages 6.89MB

    Part 1
    38 pages 3.74MB

    Part 2
    33 pages 3.15MB

    Hydraulic pump belt 250106 - 9.5mm x 1175mm - 3/8" x 46-1/4" - Gates replacement 6746

    Pair of pto belts 250106 - 12.5mm x 1025mm - 1/2" x 40-3/8" - Gates replacement 6840
    (Guttbrod 000 75 734 - 1/2" x 39-7/8")

    Water pump belt 251028 -.5mm x 600mm - 3/8" x 23-5/8" - Gates replacement 6734 looks like a typo - Should be 6724
    Water pump belt 252286 replaced by 252370 - 9.5mm x 675mm - 3/8" x 26-1/2" - Gates replacement 3VX265

    1977 D-250 10-Speed model 61-20RG01

    73 downloads

    Updated

  4. Free

    Tractor 1976 D-250 10-Speed TIPL.pdf

    IPL from Toro Master Parts Viewer
    71 pages 6.89MB

    Part 1
    38 pages 3.74MB

    Part 2
    33 pages 3.15MB

    Hydraulic pump belt 250106 - 9.5mm x 1175mm - 3/8" x 46-1/4" - Gates replacement 6746

    Pair of pto belts 250106 - 12.5mm x 1025mm - 1/2" x 40-3/8" - Gates replacement 6840
    (Guttbrod 000 75 734 - 1/2" x 39-7/8")

    Water pump belt 251028 -.5mm x 600mm - 3/8" x 23-5/8" - Gates replacement 6734 looks like a typo - Should be 6724
    Water pump belt 252286 replaced by 252370 - 9.5mm x 675mm - 3/8" x 26-1/2" - Gates replacement 3VX265

    1976 D-250 10-Speed model 61-20RG01

    169 downloads

    Updated

  5. Free

    Tractor 1976 Seat Arm rest kit 8-2015 TIPL.pdf

    IPL from Toro Master Parts Viewer
    1 page 102.27KB

    52 downloads

    Updated

  6. Free

    Tractor 1977 Seat Arm rest kit 8-2015 TIPL.pdf

    IPL from Toro Master Parts Viewer
    1 page 102.27KB

    35 downloads

    Updated

  7. Free

    Tractor 1977 A- 90 36in 4-Speed D&A SN.pdf

    Uses 36" mower deck
    Uses Peerless 662 transmission
    Uses 7.5 amp unregulated charging system, electric start and magneto ignition
    Uses B&S 191707-0685
    Uses 111215 replaced by 103991 5-terminal 3-position ignition switch for magneto ignition.   There may be a 6th terminal to ground the body of the switch.

    Transmission drive belt 103522 - (HA/A x 85.0" or 1/2" x 85")

    Lube chart SS

    Details & Attachments
    2 pages 110.64KB

    1977 A-90 36in 4-Speed model 72-08BP01

    1977 serial numbers that have shown up for the 72-08BP01
    001402 - Build date 1976 6334 November 29 Monday
    001617 - Build date 1976 6335 November 30 Tuesday
    001624 - Build date 1976 6340 December 05 Sunday
    002691 - Build date 1976 6348 December 13 Monday
    005901 - Build date 1977 7143 May 23 Monday

    56 downloads

    Updated

  8. Free

    Tractor 1974 Raider 10 4-Speed OM Wiring SN.pdf

    Operator manual #A-5324

    May be only a Belgium built model.

    Lube chart SS

    1974 Raider 10 4-Speed model 1-0393
    1974 serial numbers that have shown up for the 1-0393
    0133791 - Made in Belgium Located in the England

    98 downloads

    Updated

  9. Free

    Tractor 1977 Toro General OM IPL Wiring SN.pdf

    Operator manual #3310-921
    68 pages

    p01-p08
    8 pages 4.1MB

    p09-p15
    8 pages 4.2MB

    p15-p19
    6 pages 3MB

    p19-p27
    10 pages 3.7MB

    p27-p30
    5 pages 2.5MB

    p31-p33
    4 pages 2MB

    p34-p45
    13 pages 4.9MB

    p46-p56
    12 pages 4MB

    p57-p68
    13 pages 4.4MB

    IPL #3310-922
    Wiring
    80 pages 4.1MB

    1977 General model 37027 Serial 70001-79999

    1977 serial numbers that have shown up for the 37027
    70112

    175 downloads

    Updated

  10. Free

    Tractor 1977 D-250 10-Speed Hydraulic pump SM #492-4008.pdf

    Hydraulic pump service manual #810337R1
    15 pages 1.88MB

    Tractor 1977 D-250 10-speed model 61-20RG01

    41 downloads

    Updated

  11. Free

    Tractor 1977 D-250 10-Speed D&A OM SN.pdf

    Operator manual #803485R1 or #803485 R1
    24 pages 3.78MB
    Includes Mower Rotary 60in SD model 65-60XS01 OM

    Lube chart SS
    Tractor weight 1,160 lbs.

    Details & Attachments
    4 pages 118.59KB
    1977 D-250 10-Speed model 61-20RG01

    1977 serial numbers that have shown up for the 61-20RG01
    001249
    006010

    72 downloads

    Updated

  12. Free

    Tractor 1977 D- Series Auto Brakes Disc Turning 8-1903.pdf

    Operator manual #803969
    IPL
    4 pages 934.54KB
    Dated 9/74

    1977 D-160 Auto model 71-16OS01

    1977 D-200 Auto model 71-20KS01

    101 downloads

    Updated

  13. Free

    Tractor 1977 C-185 Elec-Trak 1-0700 IPL Wiring.pdf

    IPL #803434
    Wiring
    26 pages 5.52MB
    Part 1
    14 pages 2.72MB
    Part 2
    12 pages 2.80MB

    Transmission drive belt 517433 - (3/8" x 35.5" cogged - Matched pair)

    1977 C-185 Elec-Trak model 1-0700

    45 downloads

    Updated

  14. Free

    Tractor 1977 B-145 Elec-Trak 1-0720 IPL Wiring.pdf

    IPL #803433
    Wiring
    28 pages 3.90MB

    Transmission drive belt 517431 - (Dimensions unknown)

    1977 B-145 Elec-Trak 12-speed model 1-0720

    47 downloads

    Updated

  15. Free

    Tractor 1977 A- 65 Elec-Trak 3-6000 IPL Wiring.pdf

    IPL #803432
    Wiring
    24 pages 3.65MB

    IPL #803972
    Wiring
    Part 1
    10 pages 4.16MB
    Part 2
    11 pages 3.13MB

    Transmission drive belt 517440 - (1/2" x 34")

    Includes
    Mower Rotary 1975 36in SD model 5-1780 CW

    1977 A-65 Elec-Trak model 3-6000

    38 downloads

    Updated

  16. Free

    Tractor 1976 D-250 10-Speed Hydraulic pump SM #492-4008.pdf

    Hydraulic pump service manual #810337R1
    15 pages 1.88MB

    Tractor 1976 D-250 10-speed model 61-20RG01

    85 downloads

    Updated

  17. Free

    Tractor 1976 D -Series Auto OM.pdf

    Operator manual #803450R2 or #803450 R2
    32 pages 25.83MB

    Part 1 of 6
    5 of 32 pages 4.26MB
    Cover to page 4

    Part 2 of 6
    5 of 32 pages 4.11MB
    Pages 5-9

    Part 3 of 6
    6 of 32 pages 4.64MB
    Pages 10-15

    Part 4 of 6
    5 of 32 pages 4.45MB
    Pages 16-20

    Part 5 of 6
    6 of 32 pages 4.73MB
    Pages 21-26

    Part 6 of 6
    5 of 32 pages 3.63MB
    Pages 27-28 and 37-38 and 42

    Lube chart SS

    1976 D-160 Auto model 61-16OS01
    1976 D-160 Auto model 61-16OS02 - OM listed @ Toro as not available?

    1976 D-200 Auto model 61-20KS01
    1976 D-200 Auto model 61-20KS02 - OM listed @ Toro as not available?

    1,280 downloads

    Updated

  18. Free

    Tractor 1976 D -Series Auto Brakes Disc Turning 8-1903.pdf

    Operator manual #803969
    IPL
    4 pages 934.54KB
    Dated 9/74

    1976 D-160 Auto model 61-16OS01
    1976 D-160 Auto model 61-16OS02

    1976 D-200 Auto model 61-20KS01
    1976 D-200 Auto model 61-20KS02

    82 downloads

    Updated

  19. Free

    Tractor 1976 C-185 Elec-Trak 1-0700 IPL Wiring.pdf

    IPL #803434
    Wiring
    26 pages 5.52MB

    Part 1
    14 pages 2.72MB

    Part 2
    12 pages 2.80MB

    Transmission drive belt 517433 - (3/8" x 35.5" cogged - Matched pair)

    1976 C-185 Elec-Trak model 1-0700

    17 downloads

    Updated

  20. Free

    Tractor 1976 B-145 Elec-Trak 1-0720 IPL Wiring.pdf

    IPL #803433
    Wiring
    28 pages 3.90MB

    Transmission drive belt 517431 - (Dimensions unknown)

    1976 B-145 Elec-Trak 12-speed model 1-0720

    29 downloads

    Updated

  21. Free

    Tractor 1976 B-145 Elec-Trak 1-0720 D&A OM Wiring sn.pdf

    Operator manual #803439
    Wiring
    21 pages 10.72MB

    Part 1 OM Battery wiring
    8 pages 3.90MB

    Part 2 OM
    6 pages 3.49MB

    Part 3 OM Wiring
    7 pages 3.33MB

    Lube chart SS

    Details & Attachments
    3 pages 116.24KB
    1976 B-145 Elec-Trak 12-speed model 1-0720
    Mower Rotary 1975 42in RD model 5-1700 has been removed from this file and posted with the mowers.

    76 downloads

    Updated

  22. Free

    Tractor 1976 B -Series 8-speed OM.pdf

    Operator manual #803451R2
    24 pages 13.01MB

    Part 1 of 3
    8 of 24 pages 4.55MB

    Part 2 of 3
    8 of 24 pages 4.35MB

    Part 3 of 3
    8 of 24 pages 4.10MB

    Lube chart SS

    1976 B-60 8-speed model 61-07K801
    1976 B-60 8-speed model 61-07K802

    1976 B-80 8-speed model 61-08K801 - This is incorrectly identified at Toro as a B-60
    1976 B-80 8-speed model 61-08K802 - This is incorrectly identified at Toro as a B-60
    1976 B-80 8-speed model 61-08K803
    1976 B-80 8-speed model 61-08K804 - This is incorrectly identified at Toro as a B-60

    1976 B-100 8-speed model 61-10K801
    1976 B-100 8-speed model 61-10K802
    1976 B-100 8-speed model 61-10K803
    1976 B-100 8-speed model 61-10K804

    1,385 downloads

    Updated

  23. Free

    Tractor 1976 A-65 Elec-Trak D&A OM Wiring sn.pdf

    Operator manual #803408
    Wiring
    19 pages 10.48MB

    Part 1
    7 pages 2.85MB

    Part 2
    6 pages 3.89MB

    Part 3
    6 pages 3.73MB

    Lube chart SS

    Details & Attachments
    2 pages 107.28KB
    1976 A-65 Elec-Trak model 3-6000

    50 downloads

    Updated

  24. Free

    Tractor 1976 A-65 Elec-Trak 3-6000 IPL Wiring.pdf

    IPL
    Wiring
    45 pages 10.94MB
    #803432
    24 pages 3.65MB
    #803972

    Part 1
    10 pages 4.16MB

    Part 2
    11 pages 3.13MB


    Includes
    Mower Rotary 1975 36in SD model 5-1780 CW

    Transmission drive belt 517440 - (1/2" x 34")

    1975 A-65 Elec-Trak model 3-6000

    39 downloads

    Updated

  25. Free

    Tractor 1975 Seat Arm rest kit 8-2010 IPL.pdf

    IPL #803437
    1 page 38.33KB

    82010 at Toro
    Sold 1974-1975

    66 downloads

    Updated
