Misc. Items

Calendars and more

65 files

  1. Free

    Pulley Idler Flat

    Banta Saw Stens pulley catalog
    22 pages 1.1MB

    Some flat idlers have short flanges on each side of the OD to help keep the belt on the pulley. For some of the following dimensions it is not clear if the OD is the flat diameter or the flange diameter.

    Flat idler pulley - 1.875" OD - 1-7/8" - WH 25-5880 or 255880 (Stens 280-487 Std bearing Width 15/16" ID 3/8" No flanges)

    Flat idler pulley - 2.000" OD - 2" -  WH 3542 with Nice 7206 bearing - No picture
    Flat idler pulley - 2.000" OD - 2" -  WH 7-0056 or 70056 (Napa 7-05202 with flanges, Rotary 718, Stens 280-016 Std bearing Flat OD 1.875" Width 7/8" Flat width 11/16" ID 3/8" - Stens Std picture
    Flat idler pulley - 2.031" OD - 2-1/32" - WH 7-0056 or 70056 (Napa 7-05202 with flanges, Rotary 718, Stens 280-206 HD bearing Flat OD 1.875" Width 13/16" Flat width 11/16" ID 3/8") - Stens HD picture
    Flat idler pulley - 2.250" OD - 2-1/4" - WH 5942 (Stens 280-479 Std bearing Width 1-1/4" Flat width 3/4" ID 3/8" No flanges) - Stens picture
    Flat idler pulley - 2.469" OD - 2-15/32" - WH 4794 replaced by MW8821 (Napa 7-05203 with flanges, Stens 280-032 Std bearing Flat OD 2.250" Width 3/4" ID 3/8")
    Flat idler pulley - 2.469" OD - 2-15/32" - WH 7-0136 replaced by 3-4244 or 34244 (Napa 7-05203 with flanges, Stens 280-032 Std bearing Flat OD 2.250" Width 3/4" ID 3/8", Rotary 719)
    Flat idler pulley - 2.500" OD - 2-1/2" WH 7-0448 replaced by 12-6700 or 126700 (Stens 280-024 Std bearing Flat OD 2.000" Width 1" Flat width 13/16" ID 3/8") - Stens picture (25-5880 or 255880 and 54-9790 or 549790)

    Flat idler pulley - 3.094" OD - 3-3/32" - WH 6719, 112425 and 519537 replaced by 92-7101 or 927101 (Stens 280-222 HD bearing Flat OD 2.750" Width 7/8" ID 3/8" with flanges)
    Flat idler pulley - 3.094" OD - 3-3/32" - WH 105874 replaced by 92-7104 or 927104 May replace 6704 (Stens 280-222 HD bearing Flat OD 2.750" Width 7/8" ID 3/8" with flanges, Napa 7-05205 with flanges)
    Flat idler pulley - 3.187" OD - 3-3/16" - WH 7-4660 replaced by 62-4540 (Napa 7-05434 may work) - No picture
    Flat idler pulley - 3.219" OD - 3-7/32" - WH 51-4810 or 514810 (Stens 280-081 Std Flat OD 3.000" Width 7/8" Flat width 3/4" ID 3/8") No picture
    Flat idler pulley - 3.219" OD - 3-7/32" - WH 51-4810 or 514810 (Stens 280-586 HD bearing Flat OD 3.000" Width 7/8" ID 3/8") No picture
    Flat idler pulley - 3.219" OD - 3-7/32" - WH 2-4463 or 24463, 7434, 112426 replaced by 244-63 (Napa 7-05206 with flanges, Napa 7-05434 with flanges, Rotary 722, Stens 280-081 Std Flat OD 3.000" Width 7/8" Flat width 3/4" ID 3/8") No picture
    Flat idler pulley - 3.219" OD - 3-7/32" - WH 2-4463 or 24463, 7434, 112426 replaced by 244-63 (Napa 7-05206 with flanges, Napa 7-05434 with flanges, Rotary 722, Stens 280-586 HD bearing Flat OD 3.000" Width 7/8" ID 3/8") No picture
    Flat idler pulley - 3.219" OD - 3-7/32" - WH 51-3660 or 513660 (Stens 280-586 HD, Napa 7-05435 with flanges) No picture
    Flat idler pulley - 3.219" OD - 3-7/32" - WH 51-3660 or 513660 (Stens 280-586 HD bearing Flat OD 3.000" Width 7/8" ID 3/8") No picture
    Flat idler pulley - 3.250" OD - 3-1/4" - WH 56-9870 (Napa 7-05429 with flanges) Flat OD 2.750" No picture
    Flat idler pulley - 3.250" OD - 3-1/4" - WH 7437 replaced by 112426 (Stens 280-081 Std Flat OD 3.000", Stens 280-586 HD Flat OD 3.000", Napa 7-05434, Rotary 722)
    Flat idler pulley - 3.500" OD - 3-1/2" - WH 88-5680 replaced by 104-4180 (Napa 7-05430 with flanges) No picture
    Flat idler pulley - 3.500" OD - 3-1/2" - WH 109828 (Stens 280-529 HD Flat OD 2.750", 1-3/8" wide, 3/8" ID) No picture
    Flat idler pulley - 3.563" OD - 3-9/16" - WH 43-1040 (Stens 280-107 Std Flat OD 3.250") No picture
    Flat idler pulley - 3.750" OD - 3-3/4" - WH 6719, 112425, 519567 replaced by 92-7101 (Napa 7-05207 with flanges, Stens 280-099 Std Flat OD 3.250", Stens 280-578 replaced by 280-114 HD Flat OD 3.250") No picture

    Flat idler pulley - 4.125" OD - 101762 and 104144 replaced by WH 104975 (Stens 280-743 Flat OD 3.500" x .750" wide Overall width 1-1/8" ID 3/4" , Oregon 34-039, Rotary 8373)  No picture
    Flat idler pulley - 4.125" OD - 115119 replaced by WH 92-7084 (Napa 7-05443 with flanges) No picture
    Flat idler pulley - 4.438" OD - WH 103241 No picture
    Flat idler pulley - 4.500" OD - 6769 replaced by WH 93-1622 (Napa 7-05207 with flanges, Stens 280-131 Std, 280-826 HD Flat OD 4.125") No picture
    Flat idler pulley - 4.500" OD - 55-2860, 62-4520 and 62-4520-03 replaced by WH 36-3220 (Stens 280-826 HD Flat OD 4.125", Stens 280-131 Std) No picture
    Flat idler pulley - 4.500" OD - WH 26-1840 (Napa 7-05445 with flanges, Stens 280-890 HD) No picture
    Flat idler pulley - 4.500" OD - WH 112791 Can replace with 93-1622 by swapping the bushings in the bearing or adding shims washers to the mounting bolt
    Flat idler pulley - 4.500" OD - 6769, 106144 and 112895 replaced by WH 93-1622 (Stens 280-123 Std, Napa 7-05211 with flanges, Stens 280-495 HD) No picture

    Flat idler pulley - 5.000" OD - 51-4480 and 95-2800 replaced by WH 99-5879 (Stens 280-711 No flanges) No picture
    Flat idler pulley - 5.500" OD - WH 106107 No picture
    Flat idler pulley - 5.750" OD - WH95-2800 (Stens 280-713 HD Flat OD 5.125" with flanges, 280-711 = 5.000" OD x .500" ID x 1.1875" W no flanges) No picture
    Flat idler pulley - 5.750" OD - 51-4480 replaced by WH 99-5879 (Stens 280-713 HD Flat OD 5.125" with flanges) No picture

    Flat idler pulley - 6.250" OD - WH 105169 and 105613 replaced by 106023 No picture



    62 downloads

    Updated

  2. Free

    Price list 1975.pdf

    1975 tractor prices
    2 pages 242KB

    Odd the four C-120 8-Speed models are not included





    32 downloads

    Updated

  3. Free

    Price list 1976.pdf

    1976 List Proce booklet that has information on Tractors, accessories and attachments. Includes Model Numbers and cross reference tables for compatibility.
    1976 Wheel Horse Suggested List Prices For Tractors-Attachments-Accessories.pdf
    1976 Wheel Horse List Prices for Tractors-Attachments-Accessories

    77 downloads

    Updated

  4. Free

    Dual Wheel Adapter

    Drawing for the dual wheel adapter.

    112 downloads

    Submitted

  5. Free

    Clevis Hitch Drawing

    Drawing for the Wheel Horse clevis hitch.

    104 downloads

    Submitted

  6. Free

    Chart Belts Gates BladeRunner sizes.pdf

    Gates BladeRunner belt sizes sorted by belt length
    4 pages 56.66KB

    157 downloads

    Updated

  7. Free

    Tooling

    A view of the tools used to make the final Horses

    261 downloads

    Updated

  8. Free

    Price List 1972

    1972 Price List from Curry Power Equipment, Monroe, CT

    75 downloads

    Submitted

  9. Free

    Article - Todays Compact Tractor

    "Today's Compact Tractor" is a 1969 article about the genealogy of the compact tractor, originally published in Lawn/Garden/Outdoor Living Magazine in 1969. Reader needs to keep in mind as the article is read that the present day is 1969.

    72 downloads

    Submitted

  10. Free

    Loader FEL Plans part1 & 2

    Basic FEL Plans

    1,017 downloads

    Updated

  11. Free

    Ford 6.0L Powerstroke Cooling System Flush

    The 6.0 is a great engine, BUT the coolant Ford used may be causing a lot of problems. This document gives great insight into a proper cooling system flush.

    120 downloads

    Updated

  12. Free

    Wheel Horse Jingle

    Crank it up!

    1,191 downloads

    Updated

  13. Free

    SKF Industrial seal self study guide

    good document to get familiar with seals

    92 downloads

    Updated

  14. Free

    SKF Bearing self study guide

    good document to get familiar with bearings.

    83 downloads

    Updated

  15. Free

    STEERING WHEEL REMOVAL

    STEERING WHEEL REMOVAL

    433 downloads

    Submitted




×
×
