516H won't start unless I jump it

Recommended Posts

TheMooseIsLoose

I am having an issue with my 1988 Wheelhorse 516H Model16OE01 with an Onan 16. If I jump the relay solenoid with a screwdriver it will start. I have replaced the ignition switch & relay solenoid. Sometimes it starts without jumping relay, all that’s left is the starter/solenoid. Am I right or is there something else to look for? Thank you for any help.

  • Like 1

Share this post


Link to post
Share on other sites

rmaynard

I would start with checking ALL of your ground connections. Then if jumping the starter relay makes it start every time, and starts sometimes without jumping, my guess is that it is the relay or related wiring.

  • Like 2

Share this post


Link to post
Share on other sites

lynnmor

Page 7-129 in the Demystification Guide.

Share this post


Link to post
Share on other sites

TheMooseIsLoose

I will check wiring and grounds.



Share this post


Link to post
Share on other sites

gwest_ca

Check the condition of the 9-pin connector to the engine.



Share this post


Link to post
Share on other sites

953 nut


  • Like 1

Share this post


Link to post
Share on other sites

TheMooseIsLoose

Found one wiring issue but not the subject problem. Changed solenoid relay, no help. Next need to check solenoid.



  • Like 1

Share this post


Link to post
Share on other sites

953 nut
9 hours ago, TheMooseIsLoose said:

Next need to check solenoid.

Use a small jumper wire from the battery "+" to the small terminal (not grounded) on the solenoid and the solenoid should close. or at least click depending on how good the large cables are

Share this post


Link to post
Share on other sites

Rob R

In the winter when I have nothing to do, I actually take the solenoids apart, clean the contact bar and points and put them back together. The bar and contact points used to be made of solid copper now they are getting thinner and cheaper and they are being built with thinly copper coated steel...... real junk. Also doesn't help to NOT have a decent battery in the machine so that the draw causes the points and bar to pit and then problems starting start.... just saying..... p.s. the best solenoids I have found and use are the automotive Ford ones (purchase at any auto parts store). just saying...... p.s. can't make the show this year you guys do it up right!!!!!!

Edited by Rob R

Share this post


Link to post
Share on other sites

Lee1977
On 6/13/2022 at 2:19 PM, TheMooseIsLoose said:

I am having an issue with my 1988 Wheelhorse 516H Model16OE01 with an Onan 16. If I jump the relay solenoid with a screwdriver it will start. I have replaced the ignition switch & relay solenoid. Sometimes it starts without jumping relay, all that’s left is the starter/solenoid. Am I right or is there something else to look for? Thank you for any help.

I had to replace the seat switch on my 520 as the plastic button was so worn down that if you move on the seat it would quit running. I was having trouble starting it before I changed it. change some other things too, don't know it it affected starting.

Share this post


Link to post
Share on other sites
