About This File
IPL from Toro Master Parts Viewer
9 pages 519.13KB
Fits B-Series and LT-Series tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1984 42in RD model 05-42XR03
