toddr

New to Wheel Horse, pics of my 1st and mule drive question

Recommended Posts

I just picked up my first Wheel Horse, a 1996 or 97 520H with 356 hours.  It runs great, but looks like it was stored outside from the surface rust I'm going to need to work on.  It came with the 2 stage snowblower, but no mower deck.  I'm really looking forward to using the snowblower on my 500 ft driveway come winter.  In the mean time, I want to set it up for mowing, so I'm looking for a 42 or 48 inch deck.  This brings up my question on the mule drive, from the picture can anyone tell if this is the drive for the 60 inch deck or will I be able to use it with the smaller one I want?



Oh, lurking on this forum already cost me $250.  After seeing it, there is no way I can live without the pedal mod.  :)



Thanks in advance for the help










  • Like 7

Share this post


Link to post
Share on other sites

:WRS:  Your horse looks mighty fine.  That's very low hours.  The 22 stage snow thrower ought to do the job on your long driveway.  I can't answer your question on the pulley support box, I have no experience with the 60" deck, but it looks like the ones I have for the 36" and 42" decks.  You will need the correct length belt to correspond with the deck.



  • Like 1

Share this post


Link to post
Share on other sites

The 48" deck is great. Wide enough to get a lot of mowing done quickly and efficiently, but not so big and heavy it's hard on the tractor frame like the 60" deck. The 520H has plenty of power to mow through tough grass even with a big deck. Just keep the blades sharpened.



One drawback with a big, efficient deck though. Less seat time...:lol:



Welcome to the :wh: addiction!

  • Like 4

Share this post


Link to post
Share on other sites

:WRS:

  • Like 1

Share this post


Link to post
Share on other sites

That mule is for a 42 or 48" deck.



You can not mount a 42" side discharge deck to that machine as it will hit the rear tires (trust me, I tried).



However, a 48" deck will work perfect.

You can also fit the monster 60" deck on your 520.





  • Like 1

Share this post


Link to post
Share on other sites
1 hour ago, cleat said:

That mule is for a 42 or 48" deck.



You can not mount a 42" side discharge deck to that machine as it will hit the rear tires (trust me, I tried).



However, a 48" deck will work perfect.

You can also fit the monster 60" deck on your 520.





Thank you for this information. I think you just saved me a lot of aggravation. I was going to look at a 42 side discharge tomorrow. What part of the deck hits?

Share this post


Link to post
Share on other sites

The rear wheels on the deck hit the rear wheels of the tractor.



Other models of Wheel Horse and also the older 520 used smaller 23 x 9.5-12 tires.

Your 520 uses 23 x 10.5-12 rear tires.



They are just wide enough to rub the rear wheels of the deck.



48" deck is wider so the tires clear.



42" rear discharge deck fits I believe but have never tried.

  • Like 3

Share this post


Link to post
Share on other sites

Learned another thing new today!  The 520 is a quirky beast in some ways.

  • Like 1

Share this post


Link to post
Share on other sites

:think:  Humm...in what ways???

inquiring :wh: minds will want to know.  :dunno:

Share this post


Link to post
Share on other sites

WH kind of "pushed the envelope" with the 520 series... Had to redesign the front axle when they wanted to fit the 60" deck, then the plow frame had to be changed since the front wheels would get in the way with the swept axle... Larger rear wheels to work better with the big Onan's power output and expected heavy uses... but then the mower deck selection gets limited. BIgger, heavier parts here and there, like the tie rods... Zerks, zerks, and still more zerks... everything that can be made grease-able is, to hold up to harsh use. :D Like I said somewhere else, it's a lot like what happens when the engineers get turned loose on a common family car platform and turn it into a muscle car version. Interesting things happen in the details.

  • Like 2

Share this post


Link to post
Share on other sites

:dunno: Well yeah...               :scratchead:

how much does that 60" deck weigh?

Share this post


Link to post
Share on other sites
3 hours ago, AMC RULES said:

:dunno: Well yeah...               :scratchead:

how much does that 60" deck weigh?



about 315 lbs. its not fun trying to put it on, but it does mow like no one elses business.




but yes, you have the correct mule drive. the one for the 60" deck has a goofy spring on it which no others do.

Edited by stratostar250
  • Like 4

Share this post


Link to post
Share on other sites
