Transmission Hydro Sundstrand Wheel-a-Matic 1969 SM #A-5179.pdf

Sign in to follow this

1 Screenshot

About This File

Service manual

19 pages 1.70MB

Dated 9/69

Wheel-a-Matic Supplement 1

Includes 5062 IPL

Includes PSB #068 #083 #084 #101 #104

Sundstrand 3100077 used in

1965 model 875

1965 model 1075

1966 model 876

1966 model 1076 - Not listed @ Toro

1966 model 1276

1967 model 877

1967 model 1077 - Not listed @ Toro

1967 model 1277

Sundstrand 90-2046 used in

1968 Charger 9 model 1-7931

1968 Charger 9 model 1-7932

1968 Charger 12 model 1-7231

1968 Electro 12 model 1-7235

1969 Charger 10 model 1-7041

1969 Charger 12 model 1-7241

1969 Electro 12 model 1-7245

1970 Charger 12 model 1-7251

1970 Charger 12 model 1-7252

1970 Charger 12 model 1-7253

1970 Electro 12 model 1-7255

1971 Bronco 14 model 1-0420

1971 Bronco 14 model 1-0421

1971 Charger 12 model 1-0400

1972 Bronco 14 model 1-0422

1972 Bronco 14 model 1-0423

1972 Charger 10 model 1-0410

1972 Charger 12 model 1-0401

1972 Charger 12 model 1-0402

1973 10hp Automatic model 1-0470

1973 12hp Automatic model 1-0460

1973 14hp Automatic model 1-0430

1973 16hp Automatic model 1-0440




×
