Transmission Hydro Sundstrand SM #492-4206.pdf


1 Screenshot

About This File

Service manual

69 pages 16.46MB



Formerly #A-1391 and 803402

Hydrogear and Piston-Piston 1965 - 1982 (4 parts)



Part 1 - 34 pages 4.85MB

Pages 1 to 31



Part 2 - 7 pages 4.47MB

Pages 32 to 38 (Note - pages are not in order - 36 37 38 32 33 34 35)



Part 3 - 6 pages 3.85MB

Pages 39 to 44 (Note - pages are not in order - 42 43 44 39 40 41)



Part 4 - 19 pages 3.29MB

Pages 45 to 63



Sundstrand 90-1136 used on

1973 10hp Automatic model 1-0475

1973 12hp Automatic model 1-0465

1973 14hp Automatic model 1-0435

1974 B-100 Automatic model 1-0510

1974 C-120 Automatic model 1-0485

1974 C-120 Automatic model 1-0490

1974 C-120 Automatic model 1-0495

1975 B-100 Automatic model 1-0511

1975 C-120 Automatic model 1-0491

1976 C-120 Automatic model 61-12KS01

1976 C-120 Automatic model 61-12KS02

1976 C-120 Automatic model 61-12KS03

1976 C-120 Automatic model 61-12KS04

1977 C-120 Automatic model 71-12KS01

1977 C-120 Automatic model 71-12KS02



Sundstrand 90-1137 used on

1973 18hp Automatic model 1-0600

1973 18hp Automatic model 1-0601

1973 18hp Automatic model 1-0610

1973 18hp Automatic model 1-0620

1974 D-160 Automatic model 1-0650

1974 D-180 Automatic model 1-0611

1974 D-200 Automatic model 1-0630

1975 D-160 Automatic model 1-0651

1975 D-180 Automatic model 1-0612

1975 D-200 Automatic model 1-0631

1976 D-160 Automatic model 61-16OS01

1976 D-160 Automatic model 61-16OS02

1976 D-200 Automatic model 61-20KS01

1976 D-200 Automatic model 61-20KS02

1977 D-160 Automatic model 71-16OS01

1977 D-200 Automatic model 71-20KS01



Sundstrand 90-1140 used on

1974 C-160 Automatic model 1-0480

1975 C-160 Automatic model 1-0481

1976 C-160 Automatic model 61-16KS01

1976 C-160 Automatic model 61-16KS02

1976 C-160 Automatic model 61-16KS03

1976 C-160 Automatic model 61-16KS04

1977 C-160 Automatic model 71-16KS01

1977 C-160 Automatic model 71-16KS02



Sundstrand 90-1172 used on

1978 C-121 Automatic model 81-12KS01

1979 C-121 Automatic model 91-12KS01

1979 C-121 Automatic model 91-12KS91 - Guess



Sundstrand 90-1173 used on

1978 C-141 Automatic model 81-14KS01

1978 C-161 Automatic model 81-16KS01

1978 C-161 Twin Automatic model 81-16BS01

1978 D-160 Automatic model 81-16OS01 - Guess

1978 D-200 Automatic model 81-20KS01 - Guess

1979 C-141 Automatic model 91-14KS01

1979 C-161 Automatic model 91-16KS01

1979 C-161 Automatic model 91-16KS91 - Guess

1979 C-161 Twin Automatic model 91-16BS01

1979 C-161 Twin Automatic model 91-16BS02

1979 D-160 Automatic model 91-16OS01 - Guess

1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number - Guess

1979 D-200 Automatic model 91-20KS01 - Guess

1979 D-200 Automatic model 91-20KS02 - Guess

1980 C-125 Automatic model 01-12KS01

1980 C-145 Automatic model 01-14KS01

1980 C-165 Automatic model 01-16KS01

1980 C-165 Automatic model 01-16KS91 - Guess

1980 C-175 Twin Automatic model 01-17KS02

1980 D-160 Automatic model 01-16OS01 - Guess

1980 D-200 Automatic model 01-20KS00 - Guess

1981 D-160 Automatic model 01-16OS01 - Not listed @ Toro - Guess

1981 D-200 Automatic model 01-20KS00 - Guess



Sundstrand 90-2046 used on

1968 Charger 9 model 1-7931

1968 Charger 9 model 1-7932

1968 Charger 12 model 1-7231

1968 Electro 12 model 1-7235

1969 Charger 10 model 1-7041

1969 Charger 12 model 1-7241

1969 Electro 12 model 1-7245

1970 Charger 12 model 1-7251

1970 Charger 12 model 1-7252

1970 Charger 12 model 1-7253

1970 Electro 12 model 1-7255

1971 Bronco 14 model 1-0420

1971 Bronco 14 model 1-0421

1971 Charger 12 model 1-0400

1972 Bronco 14 model 1-0422

1972 Bronco 14 model 1-0423

1972 Charger 10 model 1-0410

1972 Charger 12 model 1-0401

1972 Charger 12 model 1-0402

1973 10hp Automatic model 1-0470

1973 12hp Automatic model 1-0460

1973 14hp Automatic model 1-0430

1973 16hp Automatic model 1-0440



Sundstrand 90-2062 used on

1969 GT-14 model 1-7441

1970 GT-14 model 1-7451

1970 GT-14 model 1-7452

1970 GT-14 model 1-7453

1971 GT-14 model 1-0500

1971 GT-14 model 1-0501

1972 GT-14 model 1-0502

1972 GT-14 model 1-0503

1973 GT-14 model 1-0502-8 - Listed in attachment interchange - Not listed at Toro



Sundstrand 3100077 used on

1965 model 875

1965 model 1075



1966 model 876

1966 model 1076 - Not listed @ Toro

1966 model 1276



1967 model 877

1967 model 1077 - Not listed @ Toro

1967 model 1277
