142 files
-
Blade Grader Pushed 50in 1986-1989 07-50BM02 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 151.03KB
Fits 300, 400 and 500-Series and C-Series except C-195
1986 Blade Grader Pushed 50in model 07-50BM02
1986 serial numbers that have shown up for the 07-50BM02
03892 - Model year a guess
1987 Blade Grader Pushed 50in model 07-50BM02
1987 serial numbers that have shown up for the 07-50BM02
60286 - Model year a guess
1988 Blade Grader Pushed 50in model 07-50BM02
1988 serial numbers that have shown up for the 07-50BM02
45093 - Model year a guess
45146 - Model year a guess
45193 - Build date 1988 8022 January 22 Friday
45253 - Model year a guess
1989 Blade Grader Pushed 50in model 07-50BM02
109 downloads
Updated
-
Blade Dozer 42in 1961 BD-4271 Short frame OM IPL DNA SN.pdf
By admin-(Admin)
Operator manual #A-7138
IPL
2 pages 413.82KB
Fits early short frame tractors 701 thru 655
No trip springs
Cross-bracing in the A-frame
Foot pedal to trip the angle lock
Mounts ahead of the rear axle
Dozer 1961 42in model BD-4271
1961 serial numbers that have shown up for the BD-4271
11296 - Model and year a guess
11331 - Model and year a guess
Dozer DNA of short tractor frame dozer blades
1961 model BD-4271 - Fits SHORT frame tractors - Mounts ahead of the rear axle - replaced by
1962 model BD-4262 - Fits SHORT frame tractors - Mounts ahead of the rear axle
1963 model BD-4263 - Fits SHORT frame tractors - Mounts ahead of the rear axle
1964 model BD-4264 - Fits SHORT frame tractors - Mounts ahead of the rear axle
1965-1966 model BD-4264A - Fits SHORT frame tractors - Mounts ahead of the rear axle
1967 model BD-4267 - Fits SHORT frame tractors - Mounts ahead of the rear axle - May be identical to 6-2111 - Model number format change
1968 model 6-2111 - Fits SHORT frame tractors - Mounts ahead of the rear axle - May be identical to BD-4267 - Model number format change
-----------------------------------------------------------------------------------------------------------------------------------
1968 model 6-4111 - First to fit LONG & SHORT frame tractors and first to mount under the rear axle - replaced by
1969 model [6-4112 + 6-9621]
1970-73 model [6-4113 + 6-9622]
1973-74 model [6-4113 + 6-9623]
1974 model [6-4114 + 6-9624]
1974 model 6-2131
1975 model 6-2132
1976 model 6-2133 - May be identical to 66-42BC01 - Model number format change
1976 model 66-42BC01 - May be identical to 6-2133 - Model number format change
1977 model 76-42BC01
1978 model 86-42BC01
1979 model 96-42BC01
1980 model 06-42BC01
1981-1984 model 06-42BC02 (Up to here they are 42" wide)
--------------------------------------------------------------------------------
1984-1989 model 06-48BC01 (They are now 48" wide)
1990 model 06-48BC02 (Last blade to have 3 angle positions)
1991-1993 model 06-48BC03 (First blade to have 5 angle positions) - May be identical to 79350 - Model number format change
1993-2001 model 79350 - (105-1502 kit adapts 2001 and older GT Classic-Series blades to fit 2002 and later tractors - May be identical to 06-48BC03 - Model number format change
2002 2004-2009 2012 model 79364 - (105-1501 kit adapts 79364 blade to fit 2001 and older GT Classic-Series)
227 downloads
Updated
-
Blade Grader Pulled 40in 1975 7-1114 OM IPL SN.pdf
By admin-(Admin)
Operator manual #803871
IPL
4 pages 613.2KB
Fits B and C-Series long, short and medium frame tractors
Indexes left and right 20 degrees
1975 Blade Grader Pulled 40in model 7-1114
1975 serial numbers that have shown up for the 7-1114
042713
042989
273 downloads
Updated
-
Blade Dozer 48in 1984-1989 06-48BC01 OM TIPL DNA SN.pdf
By gwest_ca-(File Mod)
Operator manual #810280R1 or 810280 R1
6 pages 1.89MB
Dated 05/83
IPL from Toro Master Parts Viewer
2 pages 144.29
Fits long and short frame tractors except Lawn Rangers and mid-engine models
Dozer 1984 48in model 06-48BC01 Complete (Blade changed to 48in this year)
1984 serial numbers that have shown up for the 06-48BC01 - 5 digits
21857 - Build date 1983 3270 September 27 Tuesday
248165 - Model year a guess or wrong number
Dozer 1985 48in model 06-48BC01 Complete
1985 serial numbers that have shown up for the 06-48BC01 - 5 digits
Dozer 1986 48in model 06-48BC01 Complete
1986 serial numbers that have shown up for the 06-48BC01
04199 - Model year a guess - 4199 could be a 1984 build date 1984 4199 July 17 Tuesday
Dozer 1987 48in model 06-48BC01 Complete
1987 serial numbers that have shown up for the 06-48BC01
28241 - Model year a guess
29335 - Model year a guess
30262 - Model year a guess
31097 - Model year a guess
38741 - Model year a guess
38855 - Model year a guess
39219 - Model year a guess
39366 - Model year a guess
39833 - Model year a guess
45185 - Model year a guess
46893 - Model year a guess
47250 - Model year a guess
47258 - Model year a guess
47524 - Model and year a guess [BC01]
48473 - Model year a guess
Dozer 1988 48in model 06-48BC01 Complete
1988 serial numbers that have shown up for the 06-48BC01
50002 - Build date 1988 8192 July 11 Tuesday [M]
50435 - Model year a guess
50953 - Model year a guess
51721 - Build date 1988 8268 September 24 Saturday
51845 - Build date 1988 8268 September 24 Saturday
Dozer 1989 48in model 06-48BC01 Complete
1989 serial numbers that have shown up for the 06-48BC01
0052547 - Build date 1988 8291 October 17 Monday
0053177 - Model year a guess
Dozer DNA of long tractor frame dozer blades
1966-1967 model BD-426 - Fits LONG frame tractors - Mounts ahead of the rear axle - replaced by
1968 model 6-1111 - Fits LONG frame tractors - Mounts ahead of the rear axle
----------------------------------------------------------------------------------------------------------------------
1968 model 6-4111 - First to fit LONG & SHORT frame tractors and first to mount under the rear axle with a loose A-frame crossbar - replaced by
1969 model [6-4112 + 6-9621]
1970-73 model [6-4113 + 6-9622]
1973-74 model [6-4113 + 6-9623]
1974 model [6-4114 + 6-9624]
1974 model 6-2131
1975 model 6-2132
1976 model 6-2133
1976 model 66-42BC01
1977 model 76-42BC01
1978 model 86-42BC01
1979 model 96-42BC01
1980 model 06-42BC01 - (Last blade to have a loose A-frame crossbar #7701)
1981-1984 model 06-42BC02 (Up to here including this one they are 42" wide) and (First blade to have a welded-in rear A-frame crossbar)
1984-1989 model 06-48BC01 (They are now 48" wide) - replaced by the following
1990 model 06-48BC02 (Last blade to have 3 angle positions)
1991-1993 model 06-48BC03 (First blade to have 5 angle positions)
1993-2001 model 79350 - (105-1502 kit adapts 2001 and older GT Classic-Series blades to fit 2002 and later tractors
2002 2004-2009 2012 model 79364 - (105-1501 kit adapts 79364 blade to fit 2001 and older GT Classic-Series)
1,082 downloads
Updated
-
Blade Dozer 48in 1990 06-48BC02 IPL SN.pdf
By admin-(Admin)
IPL #810748R1 or 810748 R1
3 pages 154.21KB
Fits long and short frame tractors, 300-Series and 400-Series and C-Series except C-195,
520 models require the 81640 kit because of the swept forward front axle
1990 model 06-48BC02 (Last blade to have 3 angle positions)
Dozer 1990 48in model 06-48BC02 Complete
1990 serial numbers that have shown up for the 06-48BC02
0060533
0060725 - Build date 1989 9263 September 20 Wednesday
0060951
0061253 - Build date 1989 9265 September 22 Friday
0061554 - Build date 1989 9268 September 25 Monday - Added 02-25-2019
0061796 - Build date 1989 9269 September 26 Tuesday
0062373 - Build date 1989 9298 October 25 Wednesday
0062758 - Build date 1989 9299 October 26 Thursday
0062778 - Build date 1989 9299 October 26 Thursday
0063133 - Build date 1989 9306 November 02 Thursday
279 downloads
Updated
-
Blade Dozer 42in 1965-1965 BD-4264A OM IPL SN.pdf
By admin-(Admin)
Operator manual #142-A
IPL
4 pages 595.04KB
Fits all short frame tractors and Lawn Ranger except 953 1054 1054A
Complete blade
Dozer 1965 42in model BD-4264A
1965 serial numbers that have shown up for the BD-4264A
004021
Dozer 1966 42in model BD-4264A
1966 serial numbers that have shown up for the BD-4264A
169068 - Posted as a 1964 model BD-4264 but looks like a 1966 serial number. The highest 1965 serial at the moment is 147399
208 downloads
Updated
-
Blade Dozer 54in 1966-67 BD-546 OM IPL SN.pdf
By admin-(Admin)
Operator manual #A-7138
IPL
2 pages 370.76KB
2 pages 462.07KB
Fits 953 1054 1054A
Complete blade
Toro states the BD-546 was formerly the BD-426 but not true. The BD-546 fit the 953, 1054 and 1054A. They did share a parts list.
Dozer 1966 54in model BD-546
1966 serial numbers that have shown up for the BD-546
179021
Dozer 1967 54in model BD-546
1967 serial numbers that have shown up for the BD-546
318302
75 downloads
Updated
-
Blade Dozer 48in 1998 79355 5xi OM SN.pdf
By gwest_ca-(File Mod)
Operator manual # 3319-878
16 pages 828.49KB
Fits 5xi tractor
Requires 100-3390 rear Attach-a-matic hitch
Dozer 1998 48in model 79355 Serial 8900001-8999999
1998 serial numbers that have shown up for the 79355
8900229
8900482
8900541
8901302
8901691
94 downloads
Updated
-
Blade Dozer 54in 1969 Blade 6-9611 OM IPL SN.pdf
By admin-(Admin)
Operator manual #A-5191
IPL
3 pages
Fits GT-14
Blade only
Requires 6-4112 A-frame
Mounts ahead of rear axle
Dozer 1969 54in model 6-9611 (Blade only)
1969 serial numbers that have shown up for the 6-9611
555389 - Possibly should be 655389
163 downloads
Updated
-
Blade Grader Pushed 50in 1993-1994 79351 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #3315-418RevA or 3315-418 RevA
8 pages 1.57MB
Fits C-Series and 300, 400 and 500-Series except C-195
IPL #3316-112RevA or 3316-112 RevA
2 pages 339.59KB
1993 Blade Grader 50in model 79351 Serial 3900001-3999999
1993 serial numbers that have shown up for the 79351
3900211
1994 Blade Grader 50in model 79351 Serial 4900001-4999999
1994 serial numbers that have shown up for the 79351
4900180
4900254
4900260
291 downloads
Updated
-
Blade Grader Pushed 50in 1998 79356 5xi OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual # 3319-578
12 pages 795.38KB
IPL #3319-736
8 pages 177.01KB
Fits 5xi tractors
Blade is 7-3/4" high. The only part higher is the vertical bar the lift link connects to by 1/2".
Will fit C-Series and 300, 400 and 500-Series by moving rear bar 5" ahead
1998 Blade Grader 50in model 79356 Serial 8900001-8999999
1998 serial numbers that have shown up for the 79356
8900107 [M]
8900157
8900372
128 downloads
Updated
-
Blade Dozer 42in 1979 96-42BC01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 153.04KB
Fits long and short frame tractors
Dozer 1979 42in model 96-42BC01 Complete
1979 serial numbers that have shown up for the 96-42BC01
003818 - Build date 1978 8157 June 06 Tuesday
003881 - Build date 1978 8158 June 07 Wednesday
004709 - Build date 1978 8167 June 16 Friday a guess [967 Wrong?]
004974 - Build date 1978 8179 June 18 Wednesday
005117 - Build date 1978 8180 June 29 Thursday
005690
005704 - [05704]
005708
005904
006389
006956
007404
007855
014614
015596
016658
016659
016682
017386
017710
017960
018328
166794 - Looks like a Belgium serial
160 downloads
Updated
-
Blade Dozer 42in 1981-1984 06-42BC02 OM TIPL SN.pdf
By Wyattrrp
Operator manual #810280R1
6 pages 1.89MB
IPL from Toro Master Parts Viewer
2 pages 144.29KB
Fits long and short frame tractors
Dozer 1981 42in model 06-42BC02 Complete
1981 serial numbers that have shown up for the 06-42BC02
016249 - Build date 1980 0169 June 17 Tuesday
Dozer 1982 42in model 06-42BC02 Complete
Dozer 1983 42in model 06-42BC02 Complete
Dozer 1984 42in model 06-42BC02 Complete (Last 42" blade - changed to 48" this year)
725 downloads
Updated
-
Blade Dozer 48in 1998-2000 79355 5xi IPL.pdf
By gwest_ca-(File Mod)
IPL # 3319-735
8 pages 250.61KB
Fits 5xi tractors
Requires 100-3390 rear Attach-a-matic hitch
Slotted lift link could be part number 94-7793-03 ($35.92) but more likely 94-7987-03 ($51.03)
Made from 5/16" x 1-1/2" x 8-3/8" long flat bar.
Top hole 3/8" diameter centered 3/4" from end.
Slot 3/8" x 2-1/4" starts 9/16" from the other end.
Dozer 1998 48in model 79355 Serial 8900001-8999999
Dozer 1999 48in model 79355 Serial 9900001-9999999
Dozer 2000 48in model 79355 Serial 200000001-200999999
64 downloads
Updated
-
Blade Dozer 42in 1989 16-42BL01 Snow OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #810454R1 or 810454 R1
4 pages 888.87KB
Dated 05/86
Fits some 200-Series tractors
Dozer 1989 42in model 16-42BL01 Complete
1989 serial numbers that have shown up for the 16-42BL01
0050030
0050509
0050586
0050870 - Build date 1988 8298 October 24 Monday
174 downloads
Updated
-
Blade Dozer 54in 1970-1973 Blade 6-9612 OM IPL SN.pdf
By admin-(Admin)
Operator manual #A-5191
IPL
3 pages 1.02MB
Fits GT-14
Blade only
Requires 6-4113 A-frame
Dozer 1970 54in model 6-9612
Dozer 1971 54in model 6-9612
1971 serial numbers that have shown up for the 6-9612
635967
636002 - Model 6-9612-6
677189
Dozer 1972 54in model 6-9612
1972 serial numbers that have shown up for the 6-9612
836161 - Model 6-9612-7
Dozer 1973 54in model 6-9612
132 downloads
Updated
-
Blade Dozer 48in 1990-1997 520-Series adapter 81640 Dimensions TPL.pdf
By gwest_ca-(File Mod)
Parts list from Toro Master Parts Viewer
1 page 97KB
Required on the 520-Series tractors with the forward swept front axle.
1988-1989 model 8-1630 or 81630 replaced by 8-1640 or 81640
The 1990 model 520-8 requires two 1" x 1-1/2" spacer blocks 119840 to go between the hitch and the axle housing. This spaces the hitch down so the frame clears the drive pulley.
1990 Dozer blade A-frame extension adapter model 81640 or 8-1640
1991 Dozer blade A-frame extension adapter model 81640 or 8-1640
1992 Dozer blade A-frame extension adapter model 81640 or 8-1640
1993 Dozer blade A-frame extension adapter model 81640 or 8-1640
1994 Dozer blade A-frame extension adapter model 81640 or 8-1640
1995 Dozer blade A-frame extension adapter model 81640 or 8-1640
1996 Dozer blade A-frame extension adapter model 81640 or 8-1640
1997 Dozer blade A-frame extension adapter model 81640 or 8-1640
Link to photos with dimensions
355 downloads
Updated
-
Blade Grader Pushed 50in 1990-1993 07-50BM03 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 150.59KB
Fits 300, 400 and 500-Series and C-Series except C-195
1990 Blade Grader Pushed 50in model 07-50BM03
1990 serial numbers that have shown up for the 07-50BM03
0070114
0070222
1991 Blade Grader Pushed 50in model 07-50BM03
1991 serial numbers that have shown up for the 07-50BM03
1070414
1992 Blade Grader Pushed 50in model 07-50BM03
1992 serial numbers that have shown up for the 07-50BM03
2000045
2000153
2000327
2000333
2000423
1993 Blade Grader Pushed 50in model 07-50BM03
164 downloads
Updated
-
Blade Dozer 48in 1991-1993 06-48BC03 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #810746R1 or 810746 R1
8 pages 1.89MB
IPL #3314-685
2 pages 380.01KB
Fits long and short frame tractors, C-Series, 300-Series, 400-Series
520 models require the 81640 kit because of the swept forward front axle
#104338 rod to pivot the blade appears to be 31 3/4'' long center to center with a 1 1/4'' right angle bend on each end and 1/2'' diameter solid rod. - JCM
Dozer 1991 48in model 06-48BC03 Complete
1991 serial numbers that have shown up for the 06-48BC03
1061044
Dozer 1992 48in model 06-48BC03 Complete
1992 serial numbers that have shown up for the 06-48BC03
2000533
2000712
2000732
Dozer 1993 48in model 06-48BC03 Complete
359 downloads
Updated
-
Blade Dozer 42in 1976 66-42BC01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 157.97KB
In late 1975 there was a model 6-2133 but no info available. May be the same as 66-42BC01 as the model number format changed in 1976.
Fits long and short frame tractors
Will fit the Elec-Trak with 8-1610 81610 conversion kit.
Dozer 1976 42in model 6-2133 Complete
1976 serial numbers that have shown up for the 6-2133
053737
Dozer 1976 42in model 66-42BC01 Complete
1976 serial numbers that have shown up for the 66-42BC01
02462x - Build date 1976 6106 April 15 Thursday (2462)
069621
92 downloads
Updated
-
Blade Dozer 48in 1995-1998 79252 Snow 260-Series IPL.pdf
By gwest_ca-(File Mod)
Illustrated parts list #3317-275
4 pages 180.64KB
Blade Snow
Dozer 1995 48in model 79252 Serial 5900001-5999999
Dozer 1996 48in model 79252 Serial 6900001-6999999
Dozer 1997 48in model 79252 Serial 7900001-7999999
Dozer 1998 48in model 79252 Serial 8900001-8999999
82 downloads
Updated
-
Blade Dozer 56in 1979 96-56BA01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
3 pages 268.69KB
Includes PSB #224
Fits 18hp Auto and D-Series Auto
Blade Dozer 1979 56in model 96-56BA01
1979 serial numbers that have shown up for the 96-56BA01
012919
59 downloads
Updated
-
Blade Dozer 42in 1975 6-7123 Snow OM IPL SN.pdf
By admin-(Admin)
Operator manual #803888
IPL
4 pages 1.01MB
Complete blade
Fits vertical shaft A-80 tractor & Commando V7 & V8 and Charger V7 & V8 tractors
This blade replaced 6-7121 and 6-7122
This blade replaced by 6-7124, 66-42BA01, 76-42BA01, 86-42BA01, 96-42BA01 and 06-42BA01
Dozer 1975 42in model 6-7123
1975 serial numbers that have shown up for the 6-7123
089676
089949
140 downloads
Updated
-
Blade Dozer 42in 1978 86-42BC01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 150.80KB
Fits long and short frame tractors
Dozer 1978 42in model 86-42BC01 Complete
1978 serial numbers that have shown up for the 86-42BC01
001135 - Build date 1977 7180 June 29 Wednesday
001367
002037 - Build date 1977 7187 July 06 Wednesday
002606
007871 - Build date 1977 7271 September 28 Wednesday
009143 - Build date 1977 7278 October 05 Wednesday
009251 - Build date 1977 7278 October 05 Wednesday
009762 - Build date 1977 7279 October 06 Thursday
010026 - Build date 1977 7280 October 07 Friday
180 downloads
Updated
-
Blade Dozer 42in 1964 BD-4264 OM IPL SN.pdf
By admin-(Admin)
Operator manual
IPL
4 pages 598.17KB
Fits short frame tractors
Dozer 1964 42in model BD-4264
1964 serial numbers that have shown up for the BD-4264
A-56382
A-65231
031386 - Model and year a guess
032615
032693
032994
033305
033780
033879
034596
035995
037195 - Model a guess
037503
038327
041324
195847
353 downloads
Updated
