104 files

  1. Free

    Engine Tecumseh H60-75063B & H60-75064B IPL.pdf

    I had to buy a photocopy of this from eBay for $13.  That's rediculous.  Hopefully someone can get use of it here.

    Operator manual
    IPL
    Original file 8 pages 79.6MB
    Replaced with 8 pages 3.7MB

    H60-75063B electric start
    H60-75064B recoil start

    Used on
    1964 models 604 and 654
    1964 Lawn Ranger models 34E and 34R


    183 downloads

    Updated

  2. Free

    Engine B&S 16hp VS Twin 303777 OM IPL SM.pdf

    Operator manual - #277107 Dated 3/07
    20 pages 440.12KB

    Operator manual - #MS-3822 Dated 3/07 Multiple languages
    100 pages 1.80 MB

    Operator manual - #MS-5158 Dated 5/03
    76 pages 2.60MB

    IPL - #MS-9727 Dated 11/01/2006 Revised 09/04/2007
    22 pages 2.15MB

    Service manual
    Vanguard V-Twin OHV
    196 pages 12.1MB

    Vertical crankshaft
    B&S 303777-0133-01 used on
    1990 216-H model 32-16BE01

    B&S 303777-0412-01 used on
    1992 246-H model 42-16BE01 Serial 2000001-2999999
    1992 246-He model R2-16BE01 Serial 2000001-2999999
    1993 246-H model 72081 Serial 3900001-3999999
    1993 246-H model 72101 Serial 3900001-3999999

    125 downloads

    Updated

  3. Free

    Engine Clinton 500 - 1200 SM.pdf

    Service manual
    7 pages 1.11MB

    Horizontal crankshaft engines
    500, 650, 700-A, B-700, C-700 - 2" bore
    D-700 - 2-1/8" bore
    800, A-800, 900, A-1100, B-1100, C-1100, D-1100 - 2-3/8" bore
    1200, A-1200, B-1200 - 2-15/32" bore
    494-0000-000, 494-0101-000 - 2-3/8" bore
    498-0000-000, 498-0301-000 - 2-15/32" bore

    Vertical crankshaft engines
    VS-700, VS-750 - 2" bore
    VS-800, VS-900, V-1000, VS-1000 - 2-3/8" bore
    V-1100, VS-1100 - 2-3/8" bore
    V-1200, VS-1200 - 2-15/32" bore
    497-0000-000, 499-0000-000 - 2-15/32" bore

    1958 model RJ-58 used Clinton B1290-1107 or Kohler K91-31307A & K91-31388A
    1959 model RJ-59 used Clinton B1290-1107 or Kohler K91-31307A & K91-31388A

    173 downloads

    Updated

  4. Free

    Engine Clinton Lightweight 4 Cycle OM.pdf

    Operator manual
    16 pages 13.19MB

    Part 1 - Cover to page 5
    5 pages 3.89MB

    Part 2 - page 6 to 10
    5 pages 4.29MB

    Part 3 - page 11 to 14
    4 pages 3.53MB

    Part 4 - page 15-16 Schnacke starter parts list
    2 pages 1.48MB

    VS-100, VS-350, A-300, VS-300, VS-2100
    B-700, VS-700
    800, A-800, VS-800, C-1100, D-1100
    200, VS-200, VS-400


    Clinton 1100 used in some
    1953 Pond Walk-Away
    1954 Pond Walk-Away

    82 downloads

    Updated

  5. Free

    Engine Kawasaki FD620D SM #492-4713.pdf

    Service manual
    138 pages 9.27MB

    Part 1 of 3
    Section 1 - General information
    Section 2 - Fuel system
    Section 3 - Cooling system
    54 pages 4.10MB

    Part 2 of 3
    Section 4 - Engine top end
    Section 5 - Lubrication system
    Section 6 - Camshaft and crankshaft
    50 pages 3.28MB

    Part 3 of 3
    Section 7 - Electrical system
    Section 8 - Trouble shooting
    34 pages 1.89MB

    Kawasaki FD620D-AS17 used on
    1998 520Lxi model 73545 Serial 8900001-8999999
    1998 520Lxi model 73546 Serial 8900001-8999999 - Export model
    1999 520Lxi model 73547 Serial 9900001-9999999
    1999 520Lxi model 73580 Serial 9900001-9999999
    2000 520Lxi model 73547 200000001-200999999
    2000 520Lxi model 73580 200000001-200999999
    2001 520Lxi model 73547 210000001-210999999
    2001 520Lxi model 73580 210000001-210999999

    Kawasaki FD620D-BS15 used on Toro product 1997

    1,842 downloads

    Updated

  6. Free

    Engine Tecumseh HH 80 HH100 HH120 SM.pdf

    Service manual
    5 pages 428.77KB

    Tecumseh HH80-110112D used on
    1971 WorkHorse 800 model 1-0100

    Tecumseh HH100-115095B used on
    1968 Charger 9 model 1-7931
    1968 Charger 9 model 1-7932
    1968 Raider 9 model 1-6931
    1969 Charger 10 model 1-7041
    1969 Raider 10 model 1-6041

    Tecumseh HH100-115145B used on
    1970 Raider 10 model 1-6051

    Tecumseh HH100-115145C used on
    1971 Raider 10 model 1-0300

    Tecumseh HH120-120129C used on
    1970 Charger 12 model 1-7253
    1970 Raider 12 model 1-6253

    Tecumseh HH120-120180D used on
    1974 C-120 Automatic model 1-0495
    1975 C-120 8-Speed model 1-0357
    1975 C-120 8-Speed model 1-0375

    210 downloads

    Updated

  7. Free

    Engine Tecumseh HH100 - OH160 OM.pdf

    Operator manual
    HH100, HH120, OH100, OH120, OH140, OH160, OH180
    6 pages 693.88KB

    Tecumseh HH100-115095B used on
    1968 Charger 9 model 1-7931
    1968 Charger 9 model 1-7932
    1968 Raider 9 model 1-6931
    1969 Charger 10 model 1-7041
    1969 Raider 10 model 1-6041

    Tecumseh HH100-115145B used on
    1970 Raider 10 model 1-6051

    Tecumseh HH100-115145C used on
    1971 Raider 10 model 1-0300

    Tecumseh HH120-120129C used on
    1970 Charger 12 model 1-7253
    1970 Raider 12 model 1-6253

    Tecumseh HH120-120180D used on
    1974 C-120 Automatic model 1-0495
    1975 C-120 8-Speed model 1-0357
    1975 C-120 8-Speed model 1-0375

    Tecumseh HH160-170019 or OH160-170019 used on
    1974 C-160 8-Speed model 1-0385

    116 downloads

    Updated

  8. Free

    Engine Tecumseh HH 70-HH120 SM.pdf

    Service manual
    28 pages 2.09MB

    Includes
    VM70 VM80 VM100
    HM70 HM80 HM100
    VH70 VH80 VH100
    HH70 HH80 HH100 HH120

    Early VH70 and HH70 engines were identified as V70 and H70

    Tecumseh H70-130024 used on
    1969 Trailblazer 7 model 4-2633
    1970 Trailblazer 7 model 4-2651
    1971 Trailblazer 7 model 4-2651
    1972 Trailblazer 7 model 4-2651

    Tecumseh H70-130024A used on
    1973 Trailblazer 7 model 4-2652

    Tecumseh H70-130042 used on
    1969 WorkHorse 700 model 1-3741

    Tecumseh H70-130043 used on
    1969 WorkHorse 700 model 1-3745

    Tecumseh HH80-110112D used on
    1971 WorkHorse 800 model 1-0100

    Tecumseh HH100-115095B used on
    1968 Charger 9 model 1-7931
    1968 Charger 9 model 1-7932
    1968 Raider 9 model 1-6931
    1969 Charger 10 model 1-7041
    1969 Raider 10 model 1-6041

    Tecumseh HH100-115145B used on
    1970 Raider 10 model 1-6051

    Tecumseh HH100-115145C used on
    1971 Raider 10 model 1-0300

    Tecumseh HH120-120129C used on
    1970 Charger 12 model 1-7253
    1970 Raider 12 model 1-6253

    Tecumseh HH120-120180D used on
    1974 C-120 Automatic model 1-0495
    1975 C-120 8-Speed model 1-0357
    1975 C-120 8-Speed model 1-0375

    129 downloads

    Updated

  9. Free

    Engine Tecumseh HH120-120180D IPL.pdf

    IPL
    30 pages 433.70KB

    Tecumseh HH120-120180D used on
    1974 C-120 Auto model 1-0495
    1975 C-120 8-Speed model 1-0357
    1975 C-120 8-Speed model 1-0375

    44 downloads

    Updated

  10. Free

    Engine Lauson Service Bulletins.pdf

    Service bulletin #62
    1 page 84.23KB
    H22-H35
    HB22-HB35
    HR22-HR35
    H45-H55
    HB45-HB55
    HR45-HR55

    Service bulletin #63
    1 page 96.54
    Updraft carburetors

    Lauson H22-15029C used on
    1964 18" reel mower model 418-LR
    1964 21" reel mower model 421-LR
    Lauson H55D-2113 used on
    1961 model 551

    27 downloads

    Updated

  11. Free

    Engine B&S Dating engines by serial number 1921-1965.pdf

    Dating engines by serial number
    19 pages 853KB

    Models
    A - 1933-1948
    B - 1934-1948
    F, FB, FC, FE, FG, FH, FI, FJ-1, FJ-2 - 1921-1937
    H - 1933-1940
    I, IB, INT, IS - 1938-1949
    K - 1933-1940
    L, LA - 1930-1932
    M, MJ - 1930-1934
    N, NP, NS - 1940-1954
    PB, PC-WI-100, PC-200, PC-300, PC-304, PC-WM,  PC-WMB - 1923-1944
    Q - 1925-1933
    R, R1, R2, RA, RC, RH - 1929-1933
    S - 1930-1933
    T - 1930-1931
    U - 1940-1945
    W, WA, WI, WM, WMB, WMG, WMI, WR - 1931-1957
    Y - 1931-1940
    Z, ZZ - 1931-1949
    5, 5S - 1950-1957
    6, 6H, 6S - 1952-1957
    8 - 1949-1957
    9 - 1948-1962
    14 - 1948-1963
    19, 19D - 1957-1965
    23, 23A, 23C, 23D - 1949-1965

    27 downloads

    Updated

  12. Free

    Engine B&S 11hp VS 252707 OM IPL.pdf

    Operator manual - #270862 Dated 7/91
    14 pages 1.05MB


    IPL - #MS6929 Dated 9/1992 Revised 6/2002
    17 pages 1.02MB


    Vertical crankshaft


    B&S 252707-0151-01
    1978 B-111 4-speed model 82-11BP01
    1979 B-111 6-Speed model 92-11BF01
    1979 B-111 4-Speed model 92-11BP01


    B&S 252707-0188-01
    1979 A-111 5-Speed RER model 93-11BP01


    B&S 252707-0206-01
    1980 B-112 3-Speed model 02-11BX01
    1981 B-112 3-Speed model 02-11BX02 - Early


    B&S 252707-0207-01
    1980 A-111 5-Speed RER model 03-11BP01
    1981 A-111 5-Speed RER model 03-11BP02
    1982 A-111 5-Speed RER model 23-11BP01
    1982 A-111 5-Speed RER model 23-11BX01


    B&S 252707-0209-01
    1980 B-115 5-Speed model 02-11BP02
    1981 B-115 5-Speed model 02-11BP03 - Early
    1981 B-115 5-Speed model 02-11BP04 - Late
    1982 B-115 5-Speed model 02-11BP05
    1982 B-115 Auto model 02-11BE01


    B&S 252707-0222-01
    1981 B-112 3-Speed model 02-11BX03 - Late


    B&S 252707-0222-02 1983 mid-year change with point/condenser magneto used in
    1982 LT-1137 5-Speed model A2-113701
    1983 LT-1136 3-Speed model D2-113601 Work Horse WorkHorse
    1983 LT-1137 3-Speed model D2-113701 Work Horse WorkHorse


    B&S 252707-0621-01
    1987 211-3 model 32-11B301


    B&S 252707-0624-01
    1987 211-4 model 32-11B401
    1988 211-4 model 32-11B402
    1989 211-4 model 32-11B403


    B&S 252707-0648-01
    1983 A-111 5-Speed Rear Engine Rider model 23-11BP02
    1984 A-111 5-Speed Rear Engine Rider model 23-11BP03


    B&S 252707-0657-01 1983 mid-year change with breakerless magneto used in
    1983 LT-1136 3-Speed model D2-113601 Work Horse WorkHorse
    1983 LT-1137 3-Speed model D2-113701 Work Horse WorkHorse - Incorrectly named a LT-1136 3-Speed @ Toro
    1984 B-1136 model B2-11BX91
    1984 LT-1100 3-speed model A2-11BX01 Work Horse WorkHorse
    1985 211-3 model 22-11B301
    1985 211-3 model B2-11B301
    1986 211-3 model 22-11B302 - Listed @ Toro as using 253707-0657-01
    1987 211-3 model B2-11B392 - Listed @ Toro as using 253707-0657-01 - Not in PSB #301g


    B&S 252707-0682-01
    1984 A-115 5-Speed Rear Engine Rider model 33-11BP01 - 1985 @ Toro - 1984 model in PSB 228j
    1985 A-115 5-Speed Rear Engine Rider model 33-11BP01 - 1985 @ Toro - 1984 model in PSB 228j


    B&S 252707-0682-02
    1987 111-5 Rear Engine Rider model 33-11B503
    1987 111-5e Rear Engine Rider model B3-11B591

    184 downloads

    Updated

  13. Free

    Engine B&S 11hp VS 253707 OM IPL.pdf

    Operator manual - #270862 Dated 7/91
    14 pages 1.05MB

    IPL - #MS-8177 Dated 9/92 Revised 5/98
    17 pages 868.13KB

    Vertical crankshaft

    B&S 253707-0131-01 used on
    1983 B-115 Automatic model 12-11BE01
    1983 B-115 5-Speed model 12-11BP01
    1984 B-115 5-Speed model 12-11BP02


    B&S 253707-0158-01 used on
    1984 LT-1100 5-Speed model A2-11BP01
    1985 211-5 model 22-11B501
    1985 211-A model 22-11BE01
    1986 211-5 model 22-11B502
    1987 211-5 model B2-11B591


    B&S 253707-0158-03 used on
    1987 211-5 model 32-11B501


    B&S 253707-0170-01 used on
    1985 111-5 Rear Engine Rider model 33-11B501
    1986 111-5 Rear Engine Rider model 33-11B502
    1986 111-5 Rear Engine Rider model B3-11B502
    1987 111-6 Rear Engine Rider model 33-11B601


    B&S 253707-0222-01 used on
    1987 211-5 model 32-11BX01
    1988 211-5 model 32-11BX02


    B&S 253707-0253-01 used on
    1988 111-6 Rear Engine Rider model 33-11B602


    B&S 253707-0406-01 used on
    1989 211-5 model 42-11B501


    B&S 253707-0657-01 @ Toro should be 252707-0657-01

    139 downloads

    Updated

  14. Free

    Mufflers Nelson catalog.pdf

    Muffler catalog
    10 pages


    278 downloads

    Updated

  15. Free

    Mercury-Kiekhaefer Ignition.pdf

    Parts from Standard Motor Products
    1 page 92.64KB

    15 downloads

    Updated

  16. Free

    Champion Spark Plug Catalog

    Small Engine Spark Plug Catalog from Champion. Great Technical info towards the end of the catalog about reading plugs and removal/installation as well as application charts for many small engines. For those that just want a Champion Spark Plug Decoder chart, just download the image instead of the catalog.

    173 downloads

    Updated

  17. Free

    Engine B&S 11hp HS 252417 OM IPL.pdf

    Operator manual - #270861 Dated 7/94
    14 pages 1.09MB

    IPL - #MS-6928 Dated 5/97 Revised 10/97
    25 pages 1.15MB

    Horizontal crankshaft

    B&S 252417-0198-01 used on
    1979 C-111 8-Speed model 91-11B801
    1980 1100 Special model 01-11B803

    B&S 252417-0245-01 used on
    1981 GT-2500 8-Speed model 01-11B804
    1982 SB-421 8-Speed model 01-11BH01
    1982 SB-371 3-Speed model 02-11BH01

    B&S 252417-0259-01 1983 mid-year change with point-condenser magneto used on
    1982 GT-1142 8-Speed model A1-114201
    1983 GT-1142 8-Speed model A1-114202*

    B&S 252417-0664-01 1983 mid-year change with breakerless magneto used on
    1983 GT-1142 8-Speed model A1-114202*
    1984 GT-1100 8-Speed model A1-11B801

    288 downloads

    Updated

  18. Free

    Engine Tecumseh HH 60-105013B IPL.pdf

    IPL
    32 pages 386.70KB

    Tecumseh HH60-105013B used on
    1967 model 657

    47 downloads

    Updated

  19. Free

    Engine Tecumseh H60 rectifier

    Original factory literature supplied with '63 Suburban 653, H60 Lawson equipped.

    129 downloads

    Updated

  20. Free

    Engine Tecumseh 3 amp charging with diodes and fuse SM.pdf

    Service instructions
    1 page 464KB

    6 amp fuse part number 29561
    Diode part number 30842 replaced by 36909 - 2 required

    49 downloads

    Updated

  21. Free

    Engine Robin DY41D OM.pdf

    Operator manual
    34 pages 1.81MB

    Includes DY41B engine

    Diesel used in

    1986 512-D 8-Speed model B1-12R801
    1986 512-De 8-Speed model B1-12R801

    1986 512-D 8-Speed model C1-12R801
    1986 512-De 8-Speed model C1-12R801

    76 downloads

    Updated

  22. Free

    Engine B&S 12hp VS 281707 OM IPL.pdf

    Operator manual - #274787 Dated 7/04
    20 pages 759.71KB
    Operator manual - #MS-6331 Dated 5/03 Multiple languages
    76 pages 2.16MB

    IPL - #MS-8987 Dated 12/91 Revised 9/92
    12 pages 1.08MB

    Vertical crankshaft

    B&S 281707-0175-01 used on
    1988 12-32 Rear Engine Rider Professional model 56175 Serial 8000001-8999999
    1989 12-32 Rear Engine Rider Professional model 56175 Serial 9000001-9999999
    1990 12-32 Rear Engine Rider model 56175 Serial 0000001-0999999 - (Incorrectly listed as 256175-0175-01 in PSB#T05)

    B&S 281707-0190-01 used on
    1989 212-5 model 32-12B501
    1989 212-H model 32-12BE01

    B&S 281707-0217-02 used on
    1990 212-5e model R2-12B501

    B&S 281707-0219-01 used on
    1990 112-6e Rear Engine Rider model R3-12B601

    B&S 281707-0226-01 used on
    1990 212-5 model 32-12B5A1
    1991 212-5 model 32-12B5A2 Serial 1000001-1999999
    1991 212-5 model 32-12B5A3 Serial 1000001-1999999
    1991 212-H model 32-12BEA2 Serial 1000001-1999999
    1991 212-H model 32-12BEA3 Serial 1000001-1999999

    1996 13-38XL model 71185 Serial 6900001-6999999 - Uses B&S 28M707-0127-01 -Same operator manual

    76 downloads

    Updated

  23. Free

    Engine B&S 8hp VS 193707-0148 OM IPL.pdf

    Operator manual #270676 Dated 7/91
    14 pages 1.04MB

    IPL #MS-8522 Dated 4/87 Revised 3/88
    11 pages 619.67KB

    Vertical crankshaft

    B&S 193707-0148-01 used on
    1986 108-5 Rear Engine Rider model 33-08B502
    1987 108-5 Rear Engine Rider model 33-08B503
    1988 108-5 Rear Engine Rider model 33-08B504

    19 downloads

    Updated

  24. Free

    Engine B&S 8hp VS 191707-5821 OM IPL.pdf

    Operator manual #270676 Dated 7/91
    14 pages 1.04MB

    IPL #MS-8161 Dated 1-88
    12 pages 750.05KB

    Vertical crankshaft

    B&S 191707-5821-01 used on
    1983 A-81 5-Speed Rear Engine Rider model 03-08BP03
    1983 A-81 5-Speed Rear Engine Rider model 23-08BP02
    1983 A-81 5-Speed Rear Engine Rider model 23-08BX01
    1983 A-81 5-Speed Rear Engine Rider model 23-08XP01
    1984 A-81 5-Speed Rear Engine Rider model 23-08BP03
    1984 A-81 5-Speed Rear Engine Rider model 23-08BX01 - List as 1983 only @ Toro and 1983-84 in PSB #301e

    10 downloads

    Updated

  25. Free

    Engine B&S 8hp VS 191707-56xx OM IPL.pdf

    Operator manual #270676 Dated 7/91
    14 pages 1.04MB

    IPL #MS-6927 Dated 2/83
    12 pages 308.56KB

    Vertical crankshaft

    B&S 191707-5639-01 used on
    1979 A-81 (E) 5-Speed Rear Engine Rider model 93-08BP01
    1979 A-81 (E) 5-Speed Rear Engine Rider model 93-08BP02

    B&S 191707-5639-02 used on
    1982 RR-832 5-Speed Rear Engine Rider model A3-083201

    B&S 191707-5663-01 used on
    1980 A-81 (E) 5-Speed Rear Engine Rider model 03-08BP01
    1981 A-81 (E) 5-Speed Rear Engine Rider model 03-08BP02
    1982 A-81 5-Speed Rear Engine Rider model 23-08BP01

    21 downloads

    Updated

×
