258 files
-
Free
Tractor 1980 D-250 10-Speed D&A OM Wiring Revised sn.pdf
By gwest_ca-(File Mod)
Operator manual #803647
Wiring
Setup
22 pages 4.89MB
Wiring Color pdf from OM
1 page 614KB
Lube chart SS
Details & Attachments
4 pages 121.45KB
1980 D-250 10-Speed model 91-20RG01
64 downloads
Updated
-
Free
Tractor 1978 D-250 10-Speed SM Wiring Revised #A-1431.pdf
By gwest_ca-(File Mod)
Service manual replaced with a slightly better copy 8-19-2017
Wiring
105 pages 7.3MB
Dated 8/76
Wiring Color pdf from OM
1 page 614KB
Lube chart SS
Tractor 1978 D-250 10-speed model 81-20RG01
87 downloads
Updated
-
Free
Tractor 1979 D-250 10-Speed SM Wiring Revised #A-1431.pdf
By gwest_ca-(File Mod)
Service manual replaced with a slightly better copy 8-19-2017
Wiring
105 pages 7.3MB
Dated 8/76
Wiring Color pdf from OM
1 page 614KB
Lube chart SS
Tractor 1979 D-250 10-speed model 91-20RG01
39 downloads
Updated
-
Free
Tractor 1982 B-115 5-Speed D&A TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
31 pages 2.16MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Tractor drive belt 108427 - (HA/4L x 88" or 1/2" x 88")
Lube chart SS
Details & Attachments
3 pages 115.85KB
1982 B-115 5-Speed model 02-11BP05
1982 serial numbers that have shown up for the 02-11BP05
13005 - Build date 1981 1189 July 08 Wednesday
13388
13732 - Build date 1981 1296 October 23 Friday
14168 - Located in Europe
15004 - Build date 1982 2069 March 10 Wednesday
15208 - Build date 1982 2142 May 22 Saturday
Transmission - PSB #228j lists both 819 and 801-002 transmissions with late production using 822 transmission
Toro lists 801-002 transmission
Original tractor OM #810302R1 - Alternate OM #810262R1
Original tractor IPL #810271R2
Links
For tractor OM and Wiring see
For engine OM and IPL see
For electrical service manual see
For Peerless transmission 801-002 IPL see
For Peerless transmission 819 see
Original muffler supplied by Wheel Horse
60 downloads
Updated
-
Free
Tractor 1983 GT -Series Work Horse OM Wiring Revised.pdf
By David_JH
Operator manual #810321R1 or #810321 R1
Wiring
31 pages 3.38MB
Wiring Color pdf
1 page 399KB
Also written as WorkHorse and Workhorse
Lube chart SS
1983 GT-1142 8-Speed model A1-114202
1983 GT-1642 Twin 8-Speed model A1-164202
1983 GT-1848 Twin Automatic model D1-184801
448 downloads
Updated
-
Free
Tractor 1978 C-121 Auto D&A TIPL Wiring Revised SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
47 pages 3.53MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
1978 to 1981 Wheel Horse C-Series (with Kohler) Wiring Demystification pdf
4 pages 1.4MB
Tractor drive belt # 7478 replaces # 4535 (HB/5L x 84.22" or 5/8" x 84.22")
Oil drain on late models used 1/4" x 2-1/2" nipple # 943314 and pipe cap # 107379
Lube chart SS
Details & Attachments
4 pages 122.75KB
1978 C-121 Auto model 81-12KS01
1978 serial numbers that have shown up for the 81-12KS01
003879 - Build date 1977 7354 December 20 Tuesday
005951
008403 - Located in UK
011654 - Build date 1978 8102 April 12 Wednesday appears to be stamped over 8073 March 14 Tuesday (This ID plate is vertical on the front edge of the hoodstand facing forward and beside the steering gears.)
011672 - Build date 1978 8018 [3018] January 18 Wednesday
011672 - Build date 1978 8103 April 13 Thursday appears to be stamped over
020090
020149 - Build date 1978 8166 June 15 Thursday
Note
Serial 11654 - Build date 1978 8102 April 12 Wednesday appears to be stamped over 8073 March 14 Tuesday (This ID plate is vertical on the left front edge of the hoodstand facing forward and beside the steering gears.)
This tractor has a 2nd ID plate below the dash housing showing model 91-10K802 serial 15223 - Build date 1979 9022 January 22 Monday
Links
For tractor service manual see
For electrical service manual see
For Sundstrand service manual see
For Hydraulic service manual see
For Hydraulic lift service manual #492-4208 see
111 downloads
Updated
-
Free
Tractor 1981 D-160 Auto & D-200 Auto OM Wiring Revised.pdf
By gwest_ca-(File Mod)
Lube chart SS
High resolution
Operator manual #810233R1 or #810233 R1
Wiring
37 pages 23.17MB
Part 1 of 5
9 of 37 pages 4.97MB
Part 2 of 5
7 of 37 pages 4.45MB
Part 3 of 5
7 of 37 pages 4.65MB
Part 4 of 5
6 of 37 pages 4.63MB
Part 5 of 5 has wiring diagrams
8 of 37 pages 4.47MB
Wiring D-160 Auto Color pdf
1 page 481KB
Wiring D-200 Auto Color pdf
1 page 437KB
Low resolution
Operator manual
Wiring
38 pages 3.12MB
1981 D-160 Auto model 01-16OS01 - Not listed @ Toro but in the lube chart - Transmission electric cooling fan standard equipment
1981 D-200 Auto model 01-20KS00 - Last year for D-200 Auto - Transmission electric cooling fan standard equipment
212 downloads
Updated
-
Free
Tractor 1982 D-160 Auto D&A OM Wiring Revised.pdf
By admin-(Admin)
Operator manual - Toro lists 1979 manual #810134R1 for 1982 but the 1981 manual #810233R1 should be closer #810134R1 or #810134 R1
Wiring
37 pages 23.29MB
1980 is the last year Toro has record of the D-160 Auto
See 1980 for TIPL using the same model number
Part 1 of 5
9 of 37 pages 4.97MB
Up to and including page 5
Part 2 of 5
7 of 37 pages 4.45MB
Page 6 to 12
Part 3 of 5
7 of 37 pages 4.65MB
Pages 13 to 19
Part 4 of 5
6 of 37 pages 4.63MB
Pages 20 to 25
Part 5 of 5 has wiring diagrams
8 of 37 pages 4.47MB
Pages 26 to 33
Wiring D-160 Auto Color pdf
1 page 481KB
Lube chart SS
Details & Attachments
3 pages 118.63KB
1982 D-160 Auto model 01-16OS01 - Last year for D-160 Auto
172 downloads
Updated
-
Free
Tractor 1979 D-160 Auto Wiring Revised.pdf
By admin-(Admin)
Wiring Color pdf
1 page 427KB
Tractor 1979 D-160 Auto model 91-16OS01
Tractor 1979 D-160 Auto model 91-16OS02 - Not listed @ Toro and may be an invalid model number
72 downloads
Updated
-
Free
Tractor 1979 D-200 Auto Wiring Revised.pdf
By admin-(Admin)
Early
1979 D-200 Auto model 91-20KS01
Wiring Color pdf
1 page 416KB
Late
1979 D-200 Auto model 91-20KS02
Wiring Color pdf for 91-20KS02 with transmission cooling fan standard equipment
1 page 434KB
47 downloads
Updated
-
Free
Tractor 1979 C-161 Auto D&A OML IPLL SN.pdf
By gwest_ca-(File Mod)
Lube chart SS
Details & Attachments
4 pages 123.59KB
Tractor drive belt # 7478 replaces # 4535 - (HB/5L x 84.22" or 5/8" x 84.22")
1979 C-161 Auto model 91-16KS01
1979 serial numbers that have shown up for the 91-16KS01
003353 - Build date 1978 8301 October 28 Saturday [6301]
007077 - Build date 1978 8324 November 20 Wednesday
007230 - Build date 1978 8356 December 22 Saturday
007417
009165
011912 - Build date 1979 9003 January 03 Wednesday
011934 - Build date 1979 9022 January 22 Monday
011939
012166
014312 - Build date 1979 9161 June 10 Sunday (161)
014449
014483 - Build date 1979 9183 July 02 Monday (6183 looks wrong)
020818 - Build date 1979 9189 July 08 Sunday (8189 looks wrong)
020856
028451 - Build date 1979 9188 July 07 Saturday
1979 C-161 Auto model 91-16KS91 - Stamped 91-16KS-91
1979 serial numbers that have shown up for the 91-16KS91
167207 - Made in Belgium - Located in Holland
167284 - Made in Belgium
Links
For tractor operator manual see
For tractor IPL see
For tractor service manual see
For electrical service manual see
For Sundstrand service manual see
For hydraulic lift service manual see
72 downloads
Updated
-
Free
Tractor 1978 D-200 Auto D&A TIPL Wiring Revised SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
39 pages 3.42MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Wiring Color pdf
1 page 380KB
Lube chart SS
Details & Attachments
4 pages 123.19KB
1978 D-200 Auto model 81-20KS01
1978 serial numbers that have shown up for the 81-20KS01
004663 - Build date 1977 7340 Tuesday December 06 [8340 is wrong]
004672
004711 - Build date 1977 7342 Thursday December 08 [8342 is wrong]
004736
004758 - Build date 1977 7344 Saturday December 10 [8344 is wrong]
004760 - Build date 1977 7344 Saturday December 10 [8344 is wrong] - Located in Norway
00xxxx - Build date 1977 7347 Tuesday December 13 [8347 is wrong]
For tractor service manual see
For Sundstrand service manual see
For Hydraulic service manual see
For Hydraulic lift service manual #492-4208 see
107 downloads
Updated
-
Free
Tractor 1978 D-160 Auto D&A TIPL Wiring Revised SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
55 pages 4.77MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Wiring Color pdf
1 page 457KB
Lube chart SS
Details & Attachments
4 pages 123.95KB
1978 D-160 Auto model 81-16OS01
1978 serial numbers that have shown up for the 81-16OS01
004413
004574
008336
017332 - Build date 1978 8143 May 23 Tuesday
017337 - Build date 1978 8143 May 23 Tuesday
017338 - Build date 1978 8143 May 23 Tuesday
017409 - Build date 1978 8145 May 25 Thursday
For tractor service manual see
For Onan BF service manual see
For Sundstrand service manual see
For Hydraulic service manual see
For Hydraulic lift service manual #492-4208 see
79 downloads
Updated
-
Free
Tractor 1984 C-165 8-Speed D&A TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
44 pages 3.06MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Original OM #810343R1
Original IPL #810349R1
Lube chart SS
Details & Attachments
3 pages 118.14KB
Transmission drive belt 78-7100 replaced by 7473 - HB x 81.9" or 5/8" x 81.9"
1984 C-165 8-Speed model 11-16K801
1984 serial numbers that have shown up for the 11-16K801
21569
28568
28603
28775
28839
Links
For engine operator manual see
For transmission service manual see
Some models use 8048 transmission carrier bearing and 8052 inner race.
For product service bulletin see
171 downloads
Updated
-
Free
Tractor 1980 B-112 3-Speed D&A TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
30 pages 2.39MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
The 8-4321 attachment lift was optional on the 3-Speed models and standard equipment of the 5-Speed models
Lube chart SS
Details & Attachments
3 pages 116.72KB
Transmission drive belt 106518 - (HA/4L x 87.12" or 1/2" x 87-1/8")
1980 B-112 3-Speed model 02-11BX01
1980 serial numbers that have shown up for the 02-11BX01
00001899 - Build date 1979 9305 November 01 Thursday
00002197 - Build date 1979 9324 November 20 Tuesday
00004781 - Build date 1980 0037 February 06 Wednesday
00008942 - Build date 1980 0150 May 29 Thursday
00009347
Links
For Peerless transmission IPL see
For engine OM and IPL see
For detailed wiring see
77 downloads
Updated
-
Free
Tractor 1981 C -Series Kohler powered Wiring Revised Detailed.pdf
By admin-(Admin)
Wiring Detailed 492-4207 Color pdf
4 pages 1.4MB
1981 C-85 8-speed model 01-08K802 - Incorrectly identified at Toro as C-81
1981 C-105 8-speed model 01-10K802
1981 C-125 8-speed model 01-12K802
1981 C-145 8-speed model 01-14K802
1981 C-165 8-speed model 01-16K802
1981 C-175 Twin 8-speed model 01-17K802
1981 C-125 Auto model 01-12KE02
1981 C-145 Auto model 01-14KE02
1981 C-165 Auto model 01-16KE02
1981 C-175 Twin Auto model 01-17KE01
269 downloads
Updated
-
Free
Tractor 1979 C-Series Kohler Powered Wiring Revised Detailed.pdf
By rmaynard
Wiring diagram for 1978 through 1980 C-series tractors with Kohler engines - 492-4207 - Color pdf
4 pages 1.4MB
1979 C-81 8-speed model 91-08K801
1979 C-81 8-speed model 91-08K802
1979 C-101 8-speed model 91-10K801
1979 C-101 8-speed model 91-10K802
1979 C-121 8-speed model 91-12K801
1979 C-121 8-speed model 91-12K802
1979 C-121 8-speed model 91-12K892 - made in Belgium
1979 C-141 8-speed model 91-14K801
1979 C-141 8-speed model 91-14K802
1979 C-161 8-speed model 91-16K801
1979 C-171 8-speed - never built
1979 C-121 Auto model 91-12KS01
1979 C-141 Auto model 91-14KS01
1979 C-161 Auto model 91-16KS01
1979 C-171 Auto model - never built
390 downloads
Updated
-
Free
Tractor 1978 C-161 8-Speed D&A TIPL Wiring Revised SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
43 pages 3.35MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
1978 to 1981 Wheel Horse C-Series (with Kohler) Wiring Demystification pdf
4 pages 1.4MB
Oil drain on late models used 1/4" x 2-1/2" nipple # 943314 and pipe cap # 107379
Transmission drive belt 78-7100 replaced by 7473 - (HB x 81.9" or 5/8" x 81.9")
Lube chart SS
Details & Attachments
4 pages 122.26KB
1978 C-161 8-Speed model 81-16K801
1978 serial numbers that have shown up for the 81-16K801
011574 - Build date 1978 8108 April 18 Tuesday
011756 - Could be a 1979 model - Located in the UK - Does not look like a Belgium serial number
013974 - Build date 1978 8122 May 02 Tuesday
019859 - Build date 1978 8205 July 24 Monday
162474 - Made in Belgium - Located in UK - Stamped 81-16K8-01
Links
For tractor service manual see
For electrical service manual see
For transmission service manual see low resolution
For transmission service manual see high resolution
119 downloads
Updated
-
Free
Tractor 1978 C-141 Auto D&A TIPL Wiring Revised SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
47 pages 3.52MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
1978 to 1981 Wheel Horse C-Series (with Kohler) Wiring Demystification pdf
4 pages 1.4MB
Tractor drive belt # 7478 replaces # 4535 (HB/5L x 84.22" or 5/8" x 84.22")
Oil drain on late models used 1/4" x 2-1/2" nipple # 943314 and pipe cap # 107379
Lube chart SS
Details & Attachments
4 pages 122.84KB
1978 C-141 Auto model 81-14KS01
1978 serial numbers that have shown up for the 81-14KS01
004299 - Build date 1978 8025 January 25 Wednesday
009285 - Build date 1978 8039 February 08 Wednesday
016920
017000 - Build date 1978 8115 April 25 Tuesday
020188 - Build date 1978 8116 April 26 Wednesday
020265 - Build date 1978 8144 May 24 Wednesday
Links
For tractor service manual see
For electrical service manual see
For Sundstrand service manual see
For Hydraulic service manual see
For Hydraulic lift service manual #492-4208 see
126 downloads
Updated
-
Free
Electrical Service Manual #810291R2.pdf
By gwest_ca-(File Mod)
Electrical service manual
1980-1983 A-Series and B-Series tractors
1978-1983 C-Series tractors
Same manual as 492-4207
50 pages
1978 C-81 8-Speed model 81-08K801 [Have TIPL Wiring]
1978 C-101 8-Speed model 81-10K801 [Have TIPL Wiring]
1978 C-121 8-Speed model 81-12K801 [Have TIPL Wiring](One found made in Belgium)
1978 C-121 Automatic model 81-12KS01 [Have TIPL Wiring]
1978 C-141 8-Speed model 81-14K801 [Have TIPL Wiring](Two found made in Belgium)
1978 C-141 Automatic model 81-14KS01 [Have TIPL Wiring]
1978 C-161 8-Speed model 81-16K801 [Have TIPL Wiring]
1978 C-161 Automatic model 81-16KS01 [Have TIPL Wiring]
1978 C-161 Twin 8-Speed model 81-16B801 [Have TIPL Wiring]
1978 C-161 Twin Automatic model 81-16BS01 [Have TIPL Wiring]
1979 C-81 8-Speed model 91-08K801 [Have D&A TIPL Wiring detailed]
1979 C-81 8-Speed model 91-08K802 [Have D&A OM IPL Wiring detailed]
1979 C-81 8-Speed model 91-08K891 (Made in Belgium with serial 163175)
1979 C-101 8-Speed model 91-10K801 [Have D&A TIPL Wiring detailed]
1979 C-101 8-Speed model 91-10K802 [Have D&A OM IPL Wiring detailed]
1979 C-101 8-Speed model 91-10K892 (Made in Belgium with serial 183695)
1979 C-111 8-Speed model 91-11B801 [Have D&A IPL Wiring detailed]
1979 C-121 8-Speed model 91-12K801 [Have D&A TIPL Wiring detailed] (Two found made in Belgium)
1979 C-121 8-Speed model 91-12K802 [Have D&A OM IPL Wiring detailed]
1979 C-121 8-Speed model 91-12K891 (Made in Belgium with serials 167136 169593)
1979 C-121 8-Speed model 91-12K892 [Have D&A OM IPL Wiring detailed] - Belgium built with serial 184568
1979 C-121 Automatic model 91-12KS01 *+w
1979 C-121 Automatic model 91-12KS91 (Made in Belgium with serial 16?329)
1979 C-141 8-Speed model 91-14K801 *+w
1979 C-141 8-Speed model 91-14K802 *+w
1979 C-141 Automatic model 91-14KS01 *+w
1979 C-161 8-Speed model 91-16K801 *+w
1979 C-161 Automatic model 91-16KS01 *+w (One found in Holland Made in Belgium)
1979 C-161 Automatic model 91-16KS91 Made in Belgium serial 167284
1979 C-161 Twin 8-Speed model 91-16B801 *
1979 C-161 Twin 8-Speed model 91-16B802 *
1979 C-161 Twin Automatic model 91-16BS01 *
1979 C-161 Twin Automatic model 91-16BS02 *
1979 C-171 A model that was not built
1980 1100 Special model 01-11B803 *
1980 A-51 5-Speed Rear Engine Rider model 03-05BP01 *
1980 A-81 (E) 5-Speed Rear Engine Rider model 03-08BP01 *
1980 A-81 ® 5-Speed Rear Engine Rider model 03-08XP01 *
1980 A-111 5-Speed Rear Engine Rider model 03-11BP01 *+w
1980 B-82 3-Speed model 02-08BP01 *+w
1980 B-112 3-Speed model 02-11BX01 *+w
1980 B-115 5-Speed model 02-11BP02 *+w
1980 B-165 Twin 5-Speed model 02-16BP01 *+w
1980 C-85 8-Speed model 01-08K801 *+w Incorrectly named a C-81 @ Toro (One found made in Belgium)
1980 C-85 8-Speed model 01-08K802 (Listed in PSB #276)
1980 C-105 8-Speed model 01-10K801 *+w (One found made in Belgium)
1980 C-125 8-Speed model 01-12K801 *+w
1980 C-125 Automatic model 01-12KE01 *+w
1980 C-125 Automatic model 01-12KS01 *+w
1980 C-145 8-Speed model 01-14K801 *+w
1980 C-145 8-Speed model 01-14K891 (Made in Belgium with serial 196489)
1980 C-145 Automatic model 01-14KE01 *+w
1980 C-145 Automatic model 01-14KS01 *+w
1980 C-165 8-Speed model 01-16K801 *+w
1980 C-165 Automatic model 01-16KE01 *+w
1980 C-165 Automatic model 01-16KS01 *+w
1980 C-165 Automatic model 01-16KS91 (Made in Belgium with serial 194044)
1980 C-175 Twin 8-Speed model 01-17K801 *+w
1980 C-175 Twin Automatic model 01-17KE01 *+w
1980 C-175 Twin Automatic model 01-17KS02 *+w
1981 A-51 5-Speed Rear Engine Rider model 03-05BP02 *+w
1981 A-81 (E) 5-Speed Rear Engine Rider model 03-08BP02 *
1981 A-81 ® 5-Speed Rear Engine Rider model 03-08XP01 *+w Not listed @ Toro
1981 A-111 5-Speed Rear Engine Rider model 03-11BP02 *+w
1981 B-82 3-Speed model 02-08BP02 *+w
1981 B-82 3-Speed model 02-08BP03 *+w
1981 B-112 3-Speed model 02-11BX02 *+w
1981 B-112 3-Speed model 02-11BX03 *+w
1981 B-115 5-Speed model 02-11BP03 *+w
1981 B-115 5-Speed model 02-11BP04 *+w
1981 B-165 Twin 5-Speed model 02-16BP02 *+w
1981 B-165 Twin 5-Speed model 02-16BP03 *+w
1981 C-85 8-Speed model 01-08K802 *+w Incorrectly named a C-81 @ Toro
1981 C-105 8-Speed model 01-10K802 *+w
1981 C-125 8-Speed model 01-12K802 *+w (One found made in Belgium)
1981 C-125 Automatic model 01-12KE02 *+w
1981 C-145 8-Speed model 01-14K802 *+w
1981 C-145 Automatic model 01-14KE02 *
1981 C-165 8-Speed model 01-16K802 *+w
1981 C-165 Automatic model 01-16KE02 *+w
1981 C-175 Twin 8-Speed model 01-17K802 *+w
1981 C-175 Twin Automatic model 01-17KE01 *+w
1982 A-51 5-Speed Rear Engine Rider model 23-05BP01 *+w
1982 A-81 5-Speed Rear Engine Rider model 23-08BP01 *
1982 A-111 5-Speed Rear Engine Rider model 23-11BP01 *+w
1982 A-111 5-Speed Rear Engine Rider model 23-11BX01 *+w
1982 B-85 5-Speed model 02-08BX01 *+wo
1982 B-115 5-Speed model 02-11BP05 *+wo
1982 B-115 Automatic model 02-11BE01 *+wo
1982 B-165 Twin 5-Speed model 02-16BP04 *+wo
1982 B-165 Twin Automatic model 02-16BE01 *wo
1982 C-85 8-Speed model 01-08K803 *+w
1982 C-105 8-Speed model 01-10K803 *+w
1982 C-125 8-Speed model 01-12K803 *+w
1982 C-145 Automatic model 01-14KE03 *+w
1982 C-175 Twin 8-Speed model 01-17K803 *+wo
1982 C-175 Twin Automatic model 01-17KE02 *+wo
1982 C-195 Twin Automatic model 01-19KE01 *+wo
1982 GT-1142 8-Speed model A1-114201 *+w
1982 GT-1642 Twin 8-Speed model A1-164201 *+w
1982 GT-1848 Twin Automatic model A1-184801 *+w
1982 LT-832 3-Speed model A2-083201 *+w
1982 LT-1032 3-Speed model A2-103201 *+w
1982 LT-1137 5-Speed model A2-113701 *+w
1982 LT-1637 Twin 5-Speed model A2-163701 *+w
1982 LT-1642 Twin 5-Speed model A2-164201 *+w
1982 SB-371 3-Speed model 02-11BH01 *
1982 SB-421 8-Speed model 01-11BH01 *
1982 SK-486 8-Speed model 01-16KH01 - Wired like the 1981 C-Series
1983 A- 81 5-Speed Rear Engine Rider model 03-08BP03
1983 A- 81 5-Speed Rear Engine Rider model 23-08BP02
1983 A- 81 5-Speed Rear Engine Rider model 23-08BX01
1983 A- 81 5-Speed Rear Engine Rider model 23-08XP01
1983 A-111 5-Speed Rear Engine Rider model 23-11BP02
1983 B-85 5-Speed model 02-08BX01 - 1983 in PSB #301e - Listed as 1982 @ Toro
1983 B-115 5-Speed model 12-11BP01
1983 B-115 Automatic model 12-11BE01
1983 B-165 Twin 5-Speed model 12-16BP01
1983 B-165 Twin Automatic model 12-16BE01
1983 C- 85 8-Speed model 11-08K801
1983 C-105 8-Speed model 11-10K801
1983 C-125 8-Speed model 11-12K801
1983 C-145 Automatic model 01-14KE04
1983 C-175 Twin 8-Speed model 11-17K801
1983 C-175 Twin Automatic model 01-17KE03
1983 C-195 Twin Auto model 01-19KE01 - Not listed @ Toro for 1983, 1982 only
1983 GT-1142 8-Speed model A1-114202
1983 GT-1642 Twin 8-Speed model A1-164202
1983 GT-1848 Twin Automatic model D1-184801
1983 LT-832 3-Speed model A2-083202
1983 LT-1136 3-Speed model D2-113601
1983 LT-1137 3-Speed model D2-113701 - Incorrectly named LT-1136 @ Toro
1983 LT-1637 Twin 3-Speed model D2-163701
459 downloads
Updated
-
Free
Tractor 1982 SB -Series Wiring Detailed Revised #492-4207.pdf
By admin-(Admin)
Wiring Detailed Color pdf Revised
3 pages 1.1MB
1982 SB-371 3-speed model 02-11BH01*
1982 SB-421 8-speed model 01-11BH01*
*Although Briggs & Stratton engines have magneto ignition these models are equipped with an ignition relay that allows the use of a standard battery type ignition switch and standard battery ignition interlock circuit.
From A-Series B-Series 1980-83 and C-Series 1978-83 Electrical Service Manual #492-4207
87 downloads
Updated
-
Free
Tractor 1982 GT -Series Work Horse IPL.pdf
By kdeatrick
Illustrated parts list #810286R1
(Original 66 pages 42.5MB)
Revised March 15, 2020 - Removed blank pages and arrange rest in numerical order. Was able to rotate all but one page. Removed mower deck pages.
Now 57 pages 30.7MB
Mower deck ipl's removed
1981-83 42" side discharge model 05-42MS02
1981-83 48" side discharge model 05-48MS02
1982 Work Horse GT-Series
GT-1142 8-Speed model A1-114201
GT-1642 Twin 8-Speed model A1-164201
GT-1848 Twin Automatic model A1-184801
327 downloads
Updated
-
Free
Tractor 1981 C-125 8-Speed D&A TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
48 pages 3.25MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Transmission drive belt 78-7100 replaced by 7473 - HB x 81.9" or 5/8" x 81.9"
Lube chart SS
Details & Attachments
3 pages 118.99KB
1981 C-125 8-Speed model 01-12K802
1981 serial numbers that have shown up for the 01-12K802
021322 - Build date 1980 0351 December 16 Tuesday
021335 - Build date 1980 0351 December 16 Tuesday
021380 - Build date 1980 0351 December 16 Tuesday
021775
021965 - Build date 1981 1167 June 16 Wednesday
193932 - Made in Belgium - Located in the UK
196542 - Made in Belgium model 01-12K8-91 - Located in Padua Italy
267746 - Serial looks wrong - Engine made in 1983
Original OM #810185R1 - This is the 1980 C-Series Auto manual - Possibly should be #810233R1
Original IPL # 810214R1 - This is the 1980 C-Series Auto manual
Links
For tractor operator manual see http://www.wheelhors...ng-810233r1pdf/
For transmission service manual see
For electrical service manual see
174 downloads
Updated
-
Free
Tractor 1981 GT-2500 8-Speed D&A OM Wiring TIPL SN.pdf
By grantave671
Operator manual #810247R1
Wiring
21 pages 4.69MB
IPL from Toro Master Parts Viewer
39 pages 3.25MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Transmission drive belt 78-7100 replaced by 7473 - HB x 81.9" or 5/8" x 81.9"
Lube chart SS
Details & Attachments
3 pages 119.02KB
1981 GT-2500 8-Speed model 01-11B804 - Anniversary Special
1981 serial numbers that have shown up for the 01-11B804
001008
001058
001068
001075
001078
001089
002109
021445 - Build date 1981 1058 February 27 Friday
021792
021935 - Build date 1981 1071 March 12 Thursday
022417 - Build date 1981 1077 March 18 Wednesday
022430 - Build date 1981 1077 March 18 Wednesday
022741 - Build date 1981 1070 March 11 Wednesday - (Serial or date may be wrong)
023189 - Build date 1981 1085 March 26 Thursday
023219
023280 - Build date 1981 1086 March 27 Friday
023468 - Build date 1981 1089 March 30 Monday
023492
Original IPL #810256R1
Links
For transmission service manual see
For electrical service manual see
For engine OM IPL see
25 year silver anniversary model
299 downloads
Updated
-
Free
Tractor 1983 GT-1642 Twin 8-Speed D&A TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
39 pages 2.76MB
This ipl is shared by similar models so each item may have more than one part number but fails to identify what model uses what part.
Tractor drive belt 107939 replaced by 93-9809 - (HB x 83.5" or 5/8" x 83-1/2")
42in SD mower model A5-42MS02 was standard equipment on this tractor
Original OM #810321R1
Original IPL #810327R1
Lube chart SS
Details & Attachments
3 pages 117.64KB
1983 GT-1642 Twin 8-Speed model A1-164202
1983 serial numbers that have shown up for the A1-164202
11258
12460
Links
For tractor operator manual see
For engine OM and IPL see
For transmission service manual see
For electrical service manual see
For pto clutch bearing preload see
88 downloads
Updated
